Intel®Desktop Board

D102GGC2

Specification Update

Release Date: November 2006

Order Number: D59474-003US

The Intel®Desktop Board D102GGC2 may contain design defects or errors known as errata, which

may cause the product to deviate from published specifications. Current characterized errata are

documented in this Specification Update.

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS

GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR

SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR

IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR

WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT

OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT

INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”

or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for

conflicts or incompatibilities arising from future changes to them.

The Intel®Desktop Board D102GGC2 may contain design defects or errors known as errata which may cause

the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your

product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel

literature, may be obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other Countries 708-296-9333

Intel, Pentium, Celeron, and the Intel logo are trademarks or registered trademarks of Intel Corporation or

its subsidiaries in the United States and other countries.

* Other names and brands may be claimed as the property of others.

CONTENTS

REVISION HISTORY..................................................................................................................................... v

PREFACE.........................................................................................................................................................vi

Specification Update for the Intel®Desktop Board D102GGC2

GENERAL INFORMATION ............................................................................................................................3

SPECIFICATION CHANGES.........................................................................................................................5

Intel®Desktop Board D102GGC2 Specification Update

REVISION HISTORY

Date of Revision Version Description

May 8, 2006 -001 This document is the first Specification Update for the

Intel®Desktop Board D102GGC2.

September 2006 -002 Updated AA numbers listed in General Information Table. Added

Specification Change 1.

November 2006 -003 Added Specification Changes 2 and 3.

Intel®Desktop Board D102GGC2 Specification Update

PREFACE

This document is an update to the specifications contained in the Intel®Desktop Board

D102GGC2 Technical Product Specification (Order number D44278). It is intended for hardware

system manufacturers and software developers of applications, operating systems, or tools. It

will contain Specification Changes, Errata, Specification Clarifications, and Documentation

Changes.

Refer to the Intel®Pentium®4 Processor Specification Update (Order number 249199) for

specification updates concerning the Intel Pentium 4 processor and that may apply to the

desktop board D102GGC2. Unless otherwise noted in this document, it should be assumed that

any processor errata for a given stepping are applicable to the Altered Assembly (AA) revision(s)

associated with that stepping.

Refer to the ATI website for product advisories for specification updates concerning the Radeon

Xpress 200 that may apply to the desktop board D101GGC2 . Unless otherwise noted in this

document, it should be assumed that any northbridge or southbridge errata for a given stepping

are applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Nomenclature

Specification Changes are modifications to the current published specifications. These

changes will be incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop board

D102GGC2’s behavior to deviate from published specifications. Hardware and software

designed to be used with any given Altered Assembly (AA) and BIOS revision level must assume

that all errata documented for that AA and BIOS revision level are present on all desktop

boards.

Specification Clarifications describe a specification in greater detail or further highlight a

specification’s impact to a complex design situation. These clarifications will be incorporated in

the next release of the specifications.

Documentation Changes include typos, errors, or omissions from the current published

specifications. These changes will be incorporated in the next release of the specifications.

Specification Update for the

Intel®Desktop Board D102GGC2

Intel®Desktop Board D102GGC2 Specification Update

GENERAL INFORMATION

Basic Desktop Board D102GGC2 Identification Information

AA Revision BIOS Revision Notes

D42788-201 GC11020M.86A.1058 1-2

D42788-202 GC11020M.86A.1065 1-2

D42788-203 GC11020M.86A.1065 1-2

D42789-201 GC11020M.86A.1058 1-2

D42789-202 GC11020M.86A.1065 1-2

D42789-203 GC11020M.86A.1065 1-2

NOTES:

1. The AA number is found on a small label on the component side of the board.

2. The ATi Radeon Xpress 200 Chipset kit used on this AA revision consists of two components as follows:

Device Stepping S-Spec Numbers

RC410 Northbridge A13 N/A

IXP450 Southbridge A13 N/A

Intel®Desktop Board D102GGC2 Specification Update

Summary Table of Changes

The following table indicates the Specification Changes, Errata, Specification Clarifications, or

Documentation Changes that apply to the Intel®Desktop Board D102GGC2. Intel intends to fix

some of the errata in a future revision of the desktop board, and to account for the other

outstanding issues through documentation or specification changes as noted. This table uses

the following notations:

CODES USED IN SUMMARY TABLE

Doc: Document change or update that will be implemented.

PlanFix: This erratum may be fixed in a future revision of the desktop board,

driver, or BIOS.

Fixed: This erratum has been previously fixed.

NoFix: There are no plans to fix this erratum.

Shaded: This erratum is either new or modified from the previous version of the

document.

NO. PLANS SPECIFICATION CHANGES

1 Doc Change Section 1.5.4.1, Parallel ATA IDE Interface

2 Doc Change Section 2.7.1 Back Panel Connectors

3 Doc Change Section 3.3.2 PCI IDE Support

NO. PLANS ERRATA

There is not characterized erratum for this product.
