Intel®Desktop Boards

D850MD and D850MV

Quick Reference

This guide is written for technically qualified personnel with experience

installing and configuring desktop boards.

#FGPSF:PV#FHJO

Warning and Caution..........................................................................3

Safety and Regulatory Notice ............................................................. 3

%FTLUPQ#PBSE$PNQPOFOUT

D850MD Board Components............................................................. 4

D850MV Board Components............................................................. 6

4VQQPSUFE$PNQPOFOUT

Processors........................................................................................... 8

Memory Module Requirements .......................................................... 8

*OTUBMMBUJPO4UFQT

1 Installing the I/O Shield...............................................................9

2 Installing the Desktop Board ...................................................... 10

3 Installing the Processor Fan Heatsink Base................................12

4 Installing the Processor...............................................................14

5 Installing the Processor Fan Heatsink.........................................14

6 Installing the Memory Modules..................................................15

7 Installing the AGP card Retention Mechanism...........................16

8 Installing an AGP Card............................................................... 18

9 Connecting the Fans to the D850MD Board............................... 19

10 Connecting the Fans to the D850MV Board............................... 20

11 Attaching the IDE Cable.............................................................21

4FUUJOHUIF#*04$POGJHVSBUJPO+VNQFS

...............................22

#*044FUVQ1SPHSBN%FGBVMUT

....................................................23

*UFNTPOUIF*OUFM

&YQSFTT*OTUBMMFS$%30.

x Product warranty

x Intel Express Installer

x Intel®Desktop Boards D850MD and D850MV Product Guide

x Software utilities and drivers

x Software license agreement

x Readme file

Part number: A57862-001

 *OUFM%FTLUPQ#PBSET%.%BOE%.72VJDL3FGFSFODF

(FUUJOH)FMQ

View or download product support information from Intel’s World Wide Web

site:http://support.intel.com/support/motherboards/desktop

Documents on the Web site include:

x Intel®Desktop Board D850MD/D850MV Technical Product Specification

x Intel®Desktop Board D850MD/D850MV Specification Update

If you can’t find the information you need on the Web, contact your point of

purchase. The Intel World Wide Web site also includes telephone numbers and

billing charges, if applicable, for Intel customer support.

Information in this document is provided in connection with Intel®products. No

license, express or implied, by estoppel or otherwise, to any intellectual property

rights is granted by this document. Except as provided in Intel’s Terms and

Conditions of Sale for such products, Intel assumes no liability whatsoever, and

Intel disclaims any express or implied warranty, relating to sale and/or use of Intel

products including liability or warranties relating to fitness for a particular purpose,

merchantability, or infringement of any patent, copyright or other intellectual

property right. Intel products are not intended for use in medical, life saving, or life

sustaining applications. Intel may make changes to specifications and product

descriptions at any time, without notice.

The D850MD and D850MV desktop boards may contain design defects or errors

known as errata which may cause the product to deviate from published

specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest

specifications and before placing your product order.

Copies of documents which have an ordering number and are referenced in this

document, or other Intel literature, may be obtained from Intel Corporation by

going to the World Wide Web site at: http://www.intel.com or by calling

1-800-548-4725.

Intel and Pentium are trademarks or registered trademarks of Intel Corporation or

its subsidiaries in the United States and other countries.

†Other names and brands may be claimed as the property of others.

*OUFM%FTLUPQ#PBSET%.%BOE%.72VJDL3FGFSFODF







#FGPSF:PV#FHJO

8BSOJOHBOE$BVUJPO

 8"3/*/(

%JTDPOOFDUUIFCPBSEhTQPXFSTVQQMZGSPNJUTBDQPXFSTPVSDF

CFGPSFZPVDPOOFDUPSEJTDPOOFDUDBCMFTPSJOTUBMMPSSFNPWFBOZ

CPBSEDPNQPOFOUT'BJMVSFUPEPUIJTDBOSFTVMUJOQFSTPOBMJOKVSZPS

FRVJQNFOUEBNBHF4PNFDJSDVJUSZPOUIFEFTLUPQCPBSEDBO

DPOUJOVFUPPQFSBUFFWFOUIPVHIUIFGSPOUQBOFMQPXFSTXJUDIJTPGG

 $"65*0/

&MFDUSPTUBUJDEJTDIBSHF&4%DBOEBNBHFEFTLUPQCPBSEDPNQPOFOUT

*OTUBMMUIFCPBSEBUBO&4%DPOUSPMMFEXPSLTUBUJPO*GTVDIBXPSLTUBUJPO

JTOPUBWBJMBCMFXFBSBOBOUJTUBUJDXSJTUTUSBQPSUPVDIUIFTVSGBDFPGUIF

BOUJTUBUJDQBDLBHFCFGPSFIBOEMJOHUIFCPBSE

4BGFUZBOE3FHVMBUPSZ/PUJDF

See the Intel®Desktop Boards D850MD and D850MV Product Guide for all

applicable regulatory compliance statements, product certification markings, and

safety and electromagnetic compatibility (EMC) standards and regulations these

desktop boards are compliant with.

Replacement battery warning label provided: Place the label inside the chassis

in an easy-to-see location near the battery but not on the board itself.

Intended uses: This product was evaluated as information technology

equipment (I.T.E.) for home or office use when installed into an appropriate

computer chassis. Other end uses or locations may require further evaluation.

✏

/05&

5IF%.%CPBSEMBZPVUXBTVTFEGPSJMMVTUSBUJPOTVOMFTTPUIFSXJTF

OPUFE

 *OUFM%FTLUPQ#PBSET%.%BOE%.72VJDL3FGFSFODF

%FTLUPQ#PBSE$PNQPOFOUT

%.%#PBSE$PNQPOFOUT

OM11845

QPMT S R NO

B DA

USB

Devices USB

Devices

Line

Ground

Reset

HD LED

Power LED

No Connection

J8J1

+5V

continued

*OUFM%FTLUPQ#PBSET%.%BOE%.72VJDL3FGFSFODF







%.%#PBSE

$PNQPOFOUT

(continued)

A ADI AD1885 audio codec N Diskette drive connector

B Auxiliary line-in connector (ATAPI) O Primary IDE connector

C AGP connector P Secondary IDE connector

D CD-ROM connector (ATAPI) Q Front panel USB connector

E Front panel audio connector R Alternate power/sleep LED

connector

F Chassis intrusion connector S Chassis fan connector (fan 2)

(tachometer input)



G 12 V processor core voltage

connector T Battery

H Processor fan connector

(CPU fan) (tachometer input) U Speaker

I Intel®82850 Memory Controller

Hub (MCH) V BIOS configuration jumper

J Processor socket W SCSI hard drive activity LED

connector

K RIMM sockets X Intel®82801BA I/O Controller

Hub (ICH2)

L RIMM fan connector (fan 1) Y PCI bus add-in card connectors

M Power connector Z Communication and Networking

Riser (CNR) (optional)

 $"65*0/

.BOZPGUIFJOUFSOBMDPOOFDUPSTQSPWJEFPQFSBUJOHWPMUBHF7EDBOE

7EDGPSFYBNQMFUPEFWJDFTJOTJEFUIFDPNQVUFSDIBTTJTTVDIBT

GBOTBOEJOUFSOBMQFSJQIFSBMT5IFTFDPOOFDUPSTBSFOPUPWFSDVSSFOU

QSPUFDUFE%POPUVTFUIFTFDPOOFDUPSTGPSQPXFSJOHEFWJDFTFYUFSOBMUP

UIFDPNQVUFSDIBTTJT"GBVMUJOUIFMPBEQSFTFOUFECZUIFFYUFSOBM

EFWJDFTDPVMEDBVTFEBNBHFUPUIFDPNQVUFSUIFJOUFSDPOOFDUJOHDBCMFT

BOEUIFFYUFSOBMEFWJDFTUIFNTFMWFT



 *OUFM%FTLUPQ#PBSET%.%BOE%.72VJDL3FGFSFODF

%.7#PBSE$PNQPOFOUT

OM12076

QPMT S R NO

B DA

USB

Devices USB

Devices

Line

Ground

Reset

HD LED

Power LED

No Connection

J8J1

+5V

continued

*OUFM%FTLUPQ#PBSET%.%BOE%.72VJDL3FGFSFODF







%.7#PBSE$PNQPOFOUT

(continued)



A ADI AD1885 audio codec O Primary IDE connector

B ATAPI auxiliary line-in connector P Secondary IDE connector

C AGP connector Q Front panel USB connector

D ATAPI CD-ROM connector R Alternate power/sleep LED

connector

E Front panel audio connector S Chassis fan connector (fan 2)

(tachometer input)

F Chassis intrusion connector T Battery

G 12 V processor core voltage

connector U Speaker

H Processor fan connector (CPU

fan) (tachometer input) V BIOS configuration jumper

I Intel 82850 Memory Controller

Hub (MCH) W SCSI hard drive activity LED

connector

J Processor socket X Intel 82801BA I/O Controller

Hub (ICH2)

K RIMM sockets Y PCI bus add-in card connectors

L RIMM fan connector (fan 1) Z Communication and Networking

Riser (CNR) (optional)

M Power connector AA Chassis fan (fan 3)

N Diskette drive connector

 $"65*0/

.BOZPGUIFJOUFSOBMDPOOFDUPSTQSPWJEFPQFSBUJOHWPMUBHF7EDBOE

7EDGPSFYBNQMFUPEFWJDFTJOTJEFUIFDPNQVUFSDIBTTJTTVDIBT

GBOTBOEJOUFSOBMQFSJQIFSBMT5IFTFDPOOFDUPSTBSFOPUPWFSDVSSFOU

QSPUFDUFE%POPUVTFUIFTFDPOOFDUPSTGPSQPXFSJOHEFWJDFTFYUFSOBMUP

UIFDPNQVUFSDIBTTJT"GBVMUJOUIFMPBEQSFTFOUFECZUIFFYUFSOBM

EFWJDFTDPVMEDBVTFEBNBHFUPUIFDPNQVUFSUIFJOUFSDPOOFDUJOHDBCMFT

BOEUIFFYUFSOBMEFWJDFTUIFNTFMWFT

 *OUFM%FTLUPQ#PBSET%.%BOE%.72VJDL3FGFSFODF

4VQQPSUFE$PNQPOFOUT

1SPDFTTPST

 $"65*0/

'BJMVSFUPVTFBO"597QPXFSTVQQMZPSOPUDPOOFDUJOHUIFBEEJUJPOBM

QPXFSTVQQMZMFBEUPUIF%.%PS%.7CPBSENBZSFTVMUJO

EBNBHFUPUIFEFTLUPQCPBSE

'PSNPSFJOGPSNBUJPOPOUIF"597QPXFSTVQQMZSFGFSUPUIF

Intel Desktop Boards D850MD and D850MV Product Guide

POUIF*OUFM

&YQSFTT*OTUBMMFS$%30.

The board supports the following processors:

5ZQF %FTJHOBUJPO 4ZTUFN#VT'SFRVFODZ

Intel®Pentium 4 processor in

an mPGA-478 package 1.4, 1.5, 1.6, 1.7,

and 1.8 GHz 400 MHz

For the latest information on processors supported by the D850MD and

D850MV boards, refer to the Intel World Wide Web site at:

http://support.intel.com/support/motherboards/desktop

.FNPSZ.PEVMF3FRVJSFNFOUT

The board has four 2.5 V memory module sockets that support RIMMs

containing Direct Rambus DRAM (RDRAM) devices.

The board supports the following memory features:

x Maximum of 32 RDRAM devices per channel

x Memory configurations from 128 MB (minimum) to 2 GB (maximum)

using 128/144 Mbit or 256/288 Mbit technology

x PC600 or PC800 compliant RDRAM

x Single or double-sided RIMM modules

x Serial Presence Detect (SPD) memory only

x ECC and non-ECC support

✏

/05&

'PSJOGPSNBUJPOBCPVUWFOEPSTUIBUTVQQPSUUIFTFNFNPSZSFRVJSFNFOUT

SFGFSUPUIF%.%PS%.7MJOLPOUIJT*OUFM8PSME8JEF8FCTJUF

http://support.intel.com/support/motherboards/desktop

*OUFM%FTLUPQ#PBSET%.%BOE%.72VJDL3FGFSFODF







*OTUBMMBUJPO4UFQT

 *OTUBMMJOHUIF*04IJFME

The board comes with an I/O shield. When installed in the chassis, the shield

blocks radio frequency transmissions, necessary to pass emissions (EMI)

certification testing, protects internal components from dust and foreign objects,

and promotes correct airflow within the chassis.

Install the I/O shield before installing the board in the chassis. Place the shield

inside the chassis as shown in the following figure. Press the shield into place

so that it fits tightly and securely. If the shield doesn’t fit, obtain a properly

sized shield from the chassis supplier.

OM12116



 *OUFM%FTLUPQ#PBSET%.%BOE%.72VJDL3FGFSFODF

 *OTUBMMJOHUIF%FTLUPQ#PBSE

 $"65*0/

'BJMVSFUPVTFBO"597QPXFSTVQQMZPSOPUDPOOFDUJOHUIFBEEJUJPOBM

QPXFSTVQQMZMFBEUPUIF%.7PS%.%CPBSENBZSFTVMUJO

EBNBHFUPUIFEFTLUPQCPBSE

'PSNPSFJOGPSNBUJPOPOUIF"597QPXFSTVQQMZSFGFSUPUIF

Intel Desktop Boards D850MD and D850MV Product Guide

POUIF*OUFM

&YQSFTT*OTUBMMFS$%30.

Refer to your chassis manual for specific instructions on installing and removing

the board. The D850MD board is secured to the chassis by eight screws and the

D850MV board by 11 screws. See the two illustrations below for mounting

hole locations of the two boards.

OM11831

%.%#PBSE.PVOUJOH)PMFT
