Integral Technologies FlashPoint 128 Lite Manual de usuario
FlashPoint® 128 User’s Guide
July 1998
Information in this document is subject to change without notice.
© Copyright 1998, Integral Technologies, Inc. All rights reserved.
FlashPoint 128 and Integral Technologies are trademarks of Integral Technologies, Inc. Other
trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Integral Technologies, Inc., disclaims any proprietary
interest in trademarks and trade names other than its own.
Integral Technologies makes no warranty of any kind with regard to this material, including, but not
limited to, the implied warranties of merchantability and fitness for a particular purpose. Integral
Technologies shall not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this manual.
2
3
Contents
Introduction ......................................................................................................... 7
What’s included with FlashPoint 128 ...........................................................................8
System Requirements.................................................................................................8
OptionalEquipment.....................................................................................................9
Hardware Installation........................................................................................ 11
Before Installation......................................................................................................12
Installing the FlashPoint 128 Board ...........................................................................12
Software Installation......................................................................................... 17
Quick Start for Windows 95/98 ..................................................................................18
Quick Start for Windows NT 4.0 ................................................................................19
Windows 95 Display Driver Installation......................................................................20
Windows 95 OSR2 Display Driver Installation ...........................................................22
Windows NT Display Driver Installation.....................................................................23
Windows 98 Display Driver Installation......................................................................27
FlashPoint FPG Setup forWindows 3.1, 95, 98, NT .................................................29
FlashPoint FPG Setup for MS DOS...........................................................................37
FlashPoint FPG Setup for OS/2.................................................................................38
FlashPoint 128 Cables ......................................................................................39
Basic Cable ...............................................................................................................40
Expanded Cable........................................................................................................41
Dual Composite Cable ..............................................................................................42
RGB Cable ................................................................................................................43
Composite Cable.......................................................................................................44
S-video Cable............................................................................................................44
Flash Sync Cable ......................................................................................................44
4
FlashPoint FPG Application............................................................................. 45
System Requirements for FlashPoint FPG ................................................................46
Installation.................................................................................................................46
Starting FlashPoint FPG............................................................................................46
FPG Features ...........................................................................................................47
FPG Main Window ..............................................................................................47
File Menu............................................................................................................48
Edit Menu ...........................................................................................................52
Tools Menu .........................................................................................................53
ConfigurationSetup ............................................................................................54
Advanced Configuration Setup ...........................................................................55
Setup Menu ........................................................................................................57
Video Setup Menu ..............................................................................................57
Grab Setup Menu ...............................................................................................58
Examples of using ScaleVideo .................................................................................59
Examples of using Keep Aspect................................................................................60
Special Drivers .................................................................................................. 61
FlashPoint 128 TWAIN Driver....................................................................................62
FlashPoint 128 MCI Overlay Driver ...........................................................................63
MCI Commands and Syntax ...............................................................................66
FlashPoint 128 ImagePro Plus™ Driver ....................................................................72
Installation for ImagePro 3.0 ...............................................................................72
Installation for ImagePro 2.0 ...............................................................................73
Installation for ImagePro 1.3 ...............................................................................74
FlashPoint 128Video for WindowsVidCap Driver .....................................................75
Troubleshooting ................................................................................................ 77
Verifying Hardware and Software Setup....................................................................78
How to Contact IntegralTechnologies’Customer Support .........................................80
5
Appendix A ........................................................................................................ 81
FlashPoint 128 and FlashPoint 128 CPCI Specifications...........................................82
FlashPoint 128 and FlashPoint 128 CPCI Jumper Settings .......................................83
FlashPoint 128 and FlashPoint 128 CPCI Output Connector.....................................84
FlashPoint 128 Lite Specifications.............................................................................85
FlashPoint 128 Lite Jumper Settings .........................................................................86
FlashPoint 128 Lite Output Connector.......................................................................87
LTE with the Cohu 4910 ............................................................................................88
LTE with the Sony DXC-930 or DXC-950 ..................................................................89
LTE with the Dage DC-330 in Index Mode.................................................................90
LTE with the Dage Single Line Gating Cameras........................................................91
Appendix B ........................................................................................................ 93
FCC Radio Frequency Interference Statement..........................................................94
CE Notice..................................................................................................................95
OneYear Limited Warranty ........................................................................................96
Introduction
Chapter 1
Congratulations! You have just purchased one of the most advanced, single-slot, VGA/frame
grabbing videographics cards available on the market today - one of the members of the FlashPoint
128 family.
FlashPoint 128, FlashPoint 128 Lite and FlashPoint 128 CPCI provide a variety of multiple video
inputs including composite, S-video, RGB and Betacam (this option must be requested at order time,)
plus a range of output color resolutions up to 16.7 million colors. The FlashPoint 128 CPCI is
essentially the FlashPoint 128 in CompactCPCI format.
FlashPoint 128 enables you to capture video images while triggering an external strobe flash for the
highest quality results. All FlashPoint 128 models allow you to capture true-color images from either
an NTSC or PAL source. All of this functionality is available through FlashPoint FPG, an easy-to-use
image capture application which is included with this product.
In keeping with Integrals character, this manual is designed to be user friendly. Each page features
margins wide enough for your personal notations. If you have any suggestions on improving the
manual, feel free to contact Integral with your ideas.
Thank you for choosing an Integral Technologies product. We are confident that the FlashPoint 128 -
- whichever version you have purchased -- will meet your stringent requirements.
8
What’s included with FlashPoint 128
Your FlashPoint 128 card comes with the following:
· FlashPoint 128 Setup installation disk(s) with FPG software and
display drivers
· FlashPoint 128 Users Manual
· FlashPoint 128 Product Registration Card
System Requirements
The minimum computer configuration needed to properly run the
FlashPoint 128 frame grabber:
· At least one available PCI 32-bit expansion slot
· Intel Pentium computer or greater
· 8 MB RAM (ideally, it should have 16 MB or more)
· MS DOS 3.3 or greater
· Microsoft Windows 3.1, NT, 95 or OS/2 Warp 4
FlashPoint 128,
FlashPoint 128 CPCI and
FlashPoint Lite 128 are
compatible with the newest
Pentium II processor-based
PCs.
9
Optional Equipment
To fully utilize the capabilities of your FlashPoint 128 board, you may
wish to use some or all of the following optional components:
Inputs and Outputs
· Video input device (camera, VCR, etc.)
· Photographic Flash Unit (Vivitar 283 or 285 are preferred models)
Cables available from Integral Technologies
· Standard Cable (part #3620)
· Expanded Cable (part #3610)
· RGB Cable (part #3615)
· Dual Composite Cable (part #3625)
· Composite Video Cable (part #3651)
· S-video Cable (part #3652)
· Flash Sync Cable (part #3653)
· 9 Composite Input Cable (part #3660)
· 4 Composite Input with Triggers Cable (part #3661)
Software
· FlashPoint 128 Software Developers Kit (part #3410)
There are any number of
packages with optional
equipment available.
Some cables are not
compatible with the
FlashPoint 128 Lite board.
Contact Integral or your
Integral representative.
Hardware Installation
Chapter 2
This chapter covers the installation of the FlashPoint 128 boards into the PCI bus of a computer.
Though the installation is simple, it is recommended that the steps outlined in this chapter be followed
precisely. This will ensure the units proper working condition.
Static electricity can damage sensitive electronic components. Thats why the FlashPoint 128 board is
shipped in a static-free container. Before you perform a hardware installation procedure, make sure
you discharge any static electricity by touching any non-painted metal area of the chassis.
Integral Technologies assumes no liability for any damage, caused directly or indirectly, by improper
installation of any components by unauthorized service personnel. If you do not feel comfortable
performing the installation, consult a qualified computer technician.
12
Before Installation
1. Register your FlashPoint 128 board - First, before you proceed,
please ensure your access to Integral Technologies Customer Support.
Become a registered user by completing and returning the product
registration card.
2. Make Backup Disks - Please make backup copies of your FlashPoint
128 setup disks. You should then store the original disks and use the
backups for the software installation.
Installing the FlashPoint 128 Board
Step 1 - Set the FlashPoint 128 Jumper Switches (only if necessary)
There are jumpers on the various FlashPoint 128 boards that may need to
be changed from the factory default setting, depending on your particular
situation. Most of the time, you will not need to make any changes.
Changes from the factory default settings are only needed for special
features. Always try the default settings first.
More information on jumper settings can be found in Appendix A.
The installation of
FlashPoint 128 is simple
and straightforward. The
areas of which you must be
aware are (1) whether you
have a VGA or other video
device already active in
your PC and (2) whether
you need to set any of the
FlashPoint 128 jumpers
(applicable only in rare
instances).
The FlashPoint 128
operates as your system’s
VGA. Therefore, any other
VGA device must be
removed from your system
in order for Intrigue to
function.
The default refresh
resolution for the
FlashPoint 128 boards is
75Hz, 640x480.
