Before using your new product, please read these instructions to prevent any damage.

Important Information

FINDYOUR USER GUIDE ONLINE!

We are going green so a copy of your User Guide

is not provided in the box but is available online.

To find your manual, touch the ?icon on your

tablet or go to www.insigniaproducts.com

on your computer, then click Support & Service.

Enter NS-P08A7100 in the box under

Manual, Firmware, Drivers &Product Information,

then click ►.

8" Flex™ Tablet

For Android™

NS-P08A7100

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this product near water. Do not touch your device with wet

hands.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer's instructions.

8. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not expose the device to direct sunlight.

10. Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and the point where they exit from the

product.

11. Only use attachments/accessories specified by the manufacturer.

12. Unplug this device during lightning storms or when unused for long

periods of time.

13. To reduce the risk of fire or electric shock, do not expose this device to rain,

moisture, dripping, or splashing.

14. Do not crush or puncture the product. Avoid exposing the device to high

external pressure. Do not operate the device in a very cold or very hot

temperature, such as in cold weather or in an un-air-conditioned motor

vehicle during intense heat.

15. Do not remove the cover or back to reduce the risk of electric shock. There

are no user-serviceable parts inside. Refer servicing to qualified

personnel.

16. Do not place the device on an unstable cart, stand, tripod, bracket, or table.

The unit may fall, resulting in possible damage or injury.

17. To prevent hearing damage, do not use the headphones at a high volume.

18. Never place heavy or sharp objects on the LCD panel or device.

19. Only use the AC adapter included with the device. Using any other adapter

will void your warranty.

www.insigniaproducts.com

NS-P08A7100

Troubleshooting

What should I do if I cannot turn on my tablet?

lConnect the charger to check the battery level on the screen. If the battery

is too low, your tablet will not turn on. Fully charge the battery.

Can I open Microsoft Office and PDF files on my tablet?

lYou can purchase and download third-party applications to read these

files.

What should I do if my tablet won’t recognize the microSD card?

lMake sure that you have inserted the memory card correctly and securely.

The memory card should click into place.

lWith the microSD card inserted, turn off your tablet, then turn it back on.

lMake sure that you are attempting to view your files in the correct location

on your tablet.

What should I do if I can’t access the Internet?

lLook for a wireless signal indicator ( ) in the status bar at the top of the

screen. If there is no icon, you are not connected.

lMake sure that Wi-Fi is turned on.

lMake sure that you select the right network and enter the correct password.

lTurn your tablet off, then back on.

lReset your Wi-Fi router/modem.

What should I do if there is no sound coming from my tablet?

lIf listening through headphones, unplug and reconnect your headphones.

Make sure that the connector is pushed in all the way.

lIf listening through your tablet's speakers, unplug any devices connected

to the headphone jack.

lIf you are connected to a Bluetooth device, turn off Bluetooth on your tablet.

lThe volume may be muted or set too low. Increase the volume setting.

lOpen Apps >Settings >Sound &notification to check your tablet's

sound settings.

Why is the actual storage less than storage in the specification?

lYour tablet has the full amount of storage listed in the specification.

However, some of this space is used for system applications and data files.

www.insigniaproducts.com

8" Flex™ Tablet

How do Ireset my tablet to factory defaults?

Caution:Resetting your tablet to factory defaults will delete all personal apps

and data from your tablet.

1. Tap Apps >Settings >Backup & reset.

2. Tap Factory data reset, then RESETTABLET.

How do Iset a screen lock?

1. Tap Apps >Settings >Security >Screen lock.

2. Select a screen lock type, then follow the on-screen prompts to set it up.

What should I do if the display freezes or does not respond?

lPress and hold the (power) button for 10 seconds to turn off your tablet,

then turn your tablet back on.

www.insigniaproducts.com

NS-P08A7100

Specifications

Specifications are subject to change without notice.

Operating system Android 6.0 (Marshmallow)

CPU Intel Quad-Core

Display

8" diagonal panel (20.3 cm)

800 × 1280 IPS

Capacitive 5-point touch panel

Wireless/Connectivity

Wi-Fi 802.11 b/g/n

Bluetooth 4.0

GPS

Storage 16GB internal memory

Camera 2 MP front-facing (fixed focus)

2 MP rear-facing (auto focus)

Sensors G-Sensor/Accelerometer

Audio Internal Speaker, MP3, AAC

Battery and power 4500mAh lithium battery

Up to 4.7 hours video playback

Power supply 5V/2A

Video H.264, MPEG4

Input and output

MicroSD slot (up to 128GB)

3.5 mm headphone jack

Micro USB

Dimensions (W×H×D) 8.5 × 4.9 × 0.4 in. (21.5 × 12.5 × 1.1

cm)

Weight 0.75 lbs. (0.35 kg)

www.insigniaproducts.com

8" Flex™ Tablet

Legal notices

Android, Google, Google Play and other marks are trademarks of Google Inc.

All other products and brand names are trademarks of their respective owners.

FCC Warning

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

FCC Part 15

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

lReorient or relocate the receiving antenna.

lIncrease the separation between the equipment and receiver.

lConnect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

lConsult the dealer or an experienced radio/TV technician for help.

Warning:

Changes or modifications not expressly approved by the party responsible for

compliance with the FCC Rules could void the user’s authority to operate this

equipment.

Note:

The manufacturer is not responsible for any radio or TV interference caused by

unauthorized modifications to this equipment. Such modifications could void the

user's authority to operate the equipment.

www.insigniaproducts.com

NS-P08A7100

IC RSSStatement

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) this device may not

cause interference, and (2) this device must accept any interference, including

interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux

appareils radio exempts de licence. L'exploitation est autorisée aux deux

conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2)

l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même

si le brouillage est susceptible d'en compromettre le fonctionnement.

RSS-102 Statement

This equipment complies with Industry Canada radiation exposure limits set

forth for an uncontrolled environment.

Cet équipement est conforme à l'exposition aux rayonnements Industry Canada

limites établies pour un environnement non contrôlé.

Specific Absorption Rate (SAR) Certification Information

Your wireless mobile device is a radio transmitter and receiver. It is designed

and manufactured not to exceed the exposure limits for Radio Frequency (RF)

energy set by the Federal Communications Commission (FCC) of the U. S.

Government.

These FCC RF exposure limits are derived from the recommendations of two

expert organizations: The National Council on Radiation Protection and

Measurement (NCRP) and the Institute of Electrical and Electronics Engineers

(IEEE). In both cases, the recommendations were developed by scientific and

engineering experts drawn from industry, government, and academia after

extensive reviews of the scientific literature related to the biological effects of RF

energy.

The RF exposure limit set by the FCC for wireless mobile devices employs a unit

of measurement known as the Specific Absorption Rate (SAR). The SAR is a

measure of the rate of absorption of RF energy by the human body expressed in

units of watts per kilogram (W/kg). The FCC requires wireless devices to comply

with a safety limit of 1.6 watts per kilogram (1.6 W/kg).

The FCC SAR limit incorporates a substantial margin of safety to give additional

protection to the public and to account for any variations in measurements.

www.insigniaproducts.com

8" Flex™ Tablet

SAR tests are conducted using standard operating positions accepted by the

FCC with the mobile device transmitting at its highest certified power level in all

tested frequency bands. Although the SAR is determined at the highest certified

power level, the actual SAR level of the mobile device while operating can be

well below the maximum reported value. This is because the mobile device is

designed to operate at multiple power levels so as to use only the power

required to reach the network. In general, the closer you are to a wireless base

station antenna, the lower the power output of the mobile device.

Before a new model mobile device is available for sale to the public, it must be

tested and certified to the FCC that it does not exceed the SAR limit established

by the FCC. Tests for each model mobile device are performed in positions and

locations (e.g. near the body) as required by the FCC.

By typical operations, this mobile device has been tested and meets FCC SAR

guidelines.

Use of other accessories may not ensure compliance with FCC RF exposure

guidelines. The FCC has granted an Equipment Authorization for this mobile

device with all reported SAR levels evaluated as in compliance with the FCC RF

exposure guidelines.

SAR information on this and other model mobile devices can be accessed

online on the FCC’s website through http://transition.fcc.gov/oet/rfsafety/sar.html.

To find information that pertains to a particular model mobile device, this site

uses the mobile device FCC ID number, which is usually printed somewhere on

the case of the mobile device.

Once you have the FCC ID number for a particular mobile device, follow the

instructions on the website and it should provide values for typical or maximum

SAR for a particular mobile device. Additional SAR information can also be

obtained at http://www.fcc.gov/encyclopedia/specific-absorption-rate-sar-

cellular-telephones.

IFETEL Statement

La operación de este equipo está sujeta a las siguientes dos condiciones:

1) es posible que este equipo o dispositivo no cause interferencia perjudicial y

2) este equipo debe aceptar cualquier interferencia, incluyendo la que pueda

causar su propia operación no deseada.

www.insigniaproducts.com

NS-P08A7100

ONE-YEAR LIMITED WARRANTY - INSIGNIA

DEFINITIONS:

The Distributor* of Insignia branded products warrants to you, the original

purchaser of this new Insignia-branded product (“Product”), that the Product

shall be free of defects in the original manufacturer of the material or

workmanship for a period of one (1) year from the date of your purchase of the

Product (“Warranty Period”).

For this warranty to apply, your Product must be purchased in the United States

or Canada from a Best Buy branded retail store or online at www.bestbuy.com or

www.bestbuy.ca and is packaged with this warranty statement.

HOW LONG DOES THE COVERAGE LAST?

The Warranty Period lasts for 1 year (365 days) from the date you purchased the

Product. Your purchase date is printed on the receipt you received with the

Product.

WHAT DOES THIS WARRANTY COVER?

During the Warranty Period, if the original manufacture of the material or

workmanship of the Product is determined to be defective by an authorized

Insignia repair center or store personnel, Insignia will (at its sole option): (1)

repair the Product with new or rebuilt parts; or (2) replace the Product at no

charge with new or rebuilt comparable products or parts. Products and parts

replaced under this warranty become the property of Insignia and are not

returned to you. If service of Products or parts are required after the Warranty

Period expires, you must pay all labor and parts charges. This warranty lasts as

long as you own your Insignia Product during the Warranty Period. Warranty

coverage terminates if you sell or otherwise transfer the Product.

HOW TO OBTAIN WARRANTY SERVICE?

If you purchased the Product at a Best Buy retail store location, please take your

original receipt and the Product to any Best Buy store. Make sure that you place

the Product in its original packaging or packaging that provides the same

amount of protection as the original packaging. If you purchased the Product

from a Best Buy online web site (www.bestbuy.com or www.bestbuy.ca), mail

your original receipt and the Product to the address listed on the web site. Make

sure that you put the Product in its original packaging or packaging that provides

the same amount of protection as the original packaging.

www.insigniaproducts.com

8" Flex™ Tablet

To obtain warranty service, in the United States call 1-888-BESTBUY or in

Canada call 1-866-BESTBUY. Call agents may diagnose and correct the issue

over the phone.

WHERE IS THE WARRANTY VALID?

This warranty is valid only in the United States and Canada at Best Buy branded

retail stores or websites to the original purchaser of the product in the county

where the original purchase was made.

WHAT DOES THE WARRANTY NOT COVER?

This warranty does not cover:

lCustomer instruction/education

lInstallation

lSet up adjustments

lCosmetic damage

lDamage due to weather, lightning, and other acts of God, such as power

surges

lAccidental damage

lMisuse

lAbuse

lNegligence

lCommercial purposes/use, including but not limited to use in a place of

business or in communal areas of a multiple dwelling condominium or

apartment complex, or otherwise used in a place of other than a private

home.

lModification of any part of the Product, including the antenna

lDisplay panel damaged by static (non-moving) images applied for lengthy

periods (burn-in).

lDamage due to incorrect operation or maintenance

lConnection to an incorrect voltage or power supply

lAttempted repair by any person not authorized by Insignia to service the

Product

lProducts sold “as is” or “with all faults”

lConsumables, including but not limited to batteries (i.e. AA, AAA, C etc.)

lProducts where the factory applied serial number has been altered or

removed

lLoss or Theft of this product or any part of the product

www.insigniaproducts.com

NS-P08A7100

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Tableta de Insignia

Insignia

Insignia NS-P10W8100 Manual de funcionamiento

Insignia

Insignia NS-15MS0832 Manual de usuario

Insignia

Insignia 1010 WIN Manual de usuario

Insignia

Insignia Flex Series NS-P10A7100-C Manual de usuario

Insignia

Insignia Flex NS-14T004 Manual de usuario

Insignia

Insignia NS-15AT07 Manual de usuario

Insignia

Insignia NS-P89W6100 Manual de usuario

Insignia

Insignia NS-P11W7100-C Manual de usuario

Insignia

Insignia NS-P11W7100 Manual de usuario

Insignia

Insignia FLEX Series NS-P10A8100 Manual de usuario

Insignia

Insignia Flex Series NS-P10A7100 Manual de usuario

Insignia

Insignia Flex Series NS-P10A7100 Manual de usuario

Insignia

Insignia NS-15MS08 Manual de funcionamiento

Insignia

Insignia flex NS-15MS0832B-10-C Manual de usuario

Insignia

Insignia NS-15AT08 Manual de usuario

Insignia

Insignia Flex NS-P10A8100K Manual de usuario

Insignia

Insignia NS-P10W8100 Manual de usuario

Insignia

Insignia NS-P10A6100 Manual de usuario

Insignia

Insignia NS-15AT10 Manual de usuario

Insignia

Insignia FLEX NS-14T002 Manual de funcionamiento

Insignia

Insignia Flex NS-13T001 Manual de usuario

Insignia

Insignia NS-P10A6100 Manual de usuario

Insignia

Insignia Flex NS-14T004 Manual de usuario

Insignia

Insignia Flex NS-13T001 Manual de usuario

Manuales populares de Tableta de otras marcas

Laser

Laser MID-1060 Guía del usuario

MUNBYN

MUNBYN IRT09J Guía de inicio rápido

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manual de usuario

Dell

Dell Latitude ST Manual del propietario

Lenovo

Lenovo IdeaTab S6000L Manual del propietario

Venturer

Venturer WT9L11 Manual de usuario

EDUGEAR

EDUGEAR UnoBook Manual de usuario

Philips

Philips PI3210G/58 Manual de usuario

ADLINK Technology

ADLINK Technology IMT-BT Manual de usuario

TwinMOS

TwinMOS TwinTAB-T102D1 Manual de usuario

Archos

Archos 9.7 xenon Manual de usuario

Getac

Getac E100 Manual de usuario

HANNspree

HANNspree HANNspad SN70T3 Manual de usuario

Philips

Philips PI3105W2/55 Manual de usuario

LG LG-V935 Manual de usuario

Zeki

Zeki TBDB763B Manual de usuario

Ricoh

Ricoh eQuill Manual de usuario

DT Research

DT Research DT365CT Instrucciones de montaje
