Insignia NS-7DPDVD - DVD Player - 7 Manual de usuario

User Guide

Guide de l’utilisateur

Guía del Usuario

Dual Screen Portable DVD Player

Lecteur de DVD portatif à deux écrans

Reproductor de DVD portátil con dos pantallas

NS-7DPDVD

www.insignia-products.com

Insignia NS-7DPDVD

Dual Screen

Portable DVD Player

Contents

Introduction. . . . . . . . . . . . . . . . . . . . . . . 1

Safety information . . . . . . . . . . . . . . . . . . 2

Features . . . . . . . . . . . . . . . . . . . . . . . . . 6

Using your DVD player . . . . . . . . . . . . . . .12

Setting up your DVD player . . . . . . . . . . . .15

Maintaining. . . . . . . . . . . . . . . . . . . . . . .20

Troubleshooting. . . . . . . . . . . . . . . . . . . .22

Specifications . . . . . . . . . . . . . . . . . . . . .23

Legal notices. . . . . . . . . . . . . . . . . . . . . .24

Warranty. . . . . . . . . . . . . . . . . . . . . . . . .27

Français . . . . . . . . . . . . . . . . . . . 30

Español. . . . . . . . . . . . . . . . . . . . 64

Introduction

Congratulations on your purchase of a high-quality

Insignia product. Your NS-7DPDVD represents the state

of the art in portable DVD players and is designed for

reliable and trouble-free performance.

Read this user guide carefully before using your player,

then keep it with your player for quick reference.

NS-7DPDVD

www.insignia-products.com

Make sure that the box contains:

• DVD player and 7-inch LCD monitor

• Remote control with battery (CR2025)

• AC to DC adapter

• A/V cable

• Car cigarette lighter adapter

• 2 sets of headphones

• Storage case

• Two mounting straps

•DINcable

• User guide

If any item is missing or damaged, contact Insignia at

(877) 467-4289. Keep the box and packing materials so

that you can store or transport your DVD player.

Safety information

Electric shock warning

Warning

To reduce the risk of electric shock, do not remove the cover or

back. There are no user-serviceable parts inside. Refer servicing

to qualified service personnel.

This lightning flash with arrowhead symbol within an

equilateral triangle is intended to alert the user to the

presence of uninsulated dangerous voltage within the

DVD player’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to

persons.

CAUTION

Risk of Electric Shock

Do Not Open

NS-7DPDVD

www.insignia-products.com

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the DVD player.

Warning

To prevent fire or electric shock hazard, do not expose this DVD

player to rain or moisture.

Caution

The DVD player should not be exposed to water (dripping or

splashing) and no objects filled with liquids, such as vases,

should be placed on the DVD player.

Ventilation

Caution

Do not block any ventilation openings. Install in accordance with

these instructions.

Slots and openings in the case are provided for ventilation and to

ensure reliable operation of the DVD player and to protect it from

over-heating.

The openings should never be blocked by placing the DVD player

on a bed, sofa, rug, or other similar surface. This DVD player

should not be placed in a built-in installation, such as a bookcase

or rack, unless proper ventilation is provided or these instructions

have been adhered to.

NS-7DPDVD

www.insignia-products.com

Laser warning

Warning

This DVD player uses a laser system.

To ensure proper use of this DVD player, read this user guide

carefully and retain it for future reference. Should the DVD player

require maintenance, contact authorized service personnel.

Changing controls, making adjustments, or carrying out

procedures other than those specified herein may result in

hazardous radiation exposure.

To prevent direct exposure to the laser beam, do not try to open

the enclosure. There is visible laser radiation when open. Do not

stare into the beam.

Caution

Visible and invisible laser radiation is present when the DVD

player is open and interlocks are defeated.

Important safety instructions

Warning

Read and observe all warnings and instructions in this manual

and those marked on the DVD player. Retain this manual for

future reference. This DVD player has been designed and

manufactured to assure personal safety. Improper use can result

in electric shock or fire hazard. The safeguards incorporated in

this DVD player will protect you if you observe the following

procedures for installation, use, and servicing. This DVD player

does not contain any parts that can be repaired by you. Do not

remove the case or you may be exposed to dangerous voltage.

Refer servicing to qualified service personnel only.

• Make sure that the portable DVD player is installed in

accordance with the instructions and illustrations provided in

this manual.

• To prevent fire or electric shock, do not expose this appliance

to rain or moisture.

• Do not place the set on an unstable cart, stand, tripod, bracket

or table to prevent it from falling.

• Keep the unit away from strong magnets, heat sources, direct

sunlight, excessive dust.

NS-7DPDVD

www.insignia-products.com

• If the unit is brought directly from a cold to a warm location,

moisture may condense inside the unit. When you move it from

a cold to a warm location, wait for about one hour before

operating the unit, or remove the disc and leave the unit turned

on until the moisture evaporates.

• Do not push objects of any kind into the unit through openings.

• Do not spill or spray liquid of any kind on or in the system (this

may result in a fire or electric shock).

• Do not place anything heavy on the unit.

• Do not cover or block openings with a cloth or other material.

• Keep the unit away from an open flame such as fire, candle etc.

• Replace the battery only with the same or equivalent type, in

order to protect the environment. Dispose the battery properly.

• Do not use the unit in temperatures higher than 95 degrees

Fahrenheit or 35 degrees Celsius.

• Do not use irregularly shaped discs such as heart or

star-shaped discs as they may cause the unit to malfunction.

• Do not stick paper, tape or glue on the disc.

• Do not expose the disc to direct sunlight or heat sources.

• Do not touch the surface of disc. Handle the disc by its edge.

• Clean the disc by wiping the disc from the center out with a

cleaning cloth.

• Remove the disc from the unit and store it in its case after

playing.

• Some playback operations of discs may be intentionally fixed

by software producers. Since this unit plays discs according to

the disc contents the software producers designed, some

playback features may not be available. Also refer to the

instructions supplied with the discs.

NS-7DPDVD

www.insignia-products.com

Features

DVD Player

Front

Item Description

1Wide button: Press to switch the LCD between 16:9 and 4:3

displays.

2Prev button: Press to skip to the previous title, chapter, or

track. Note: Press and hold for three seconds to scan

backward at 2, 4, 8, 16, or 32 times normal playback speed.

3Play/Pause button: Press to start playback. Press to pause

when a disc is playing. Press again to resume playback.

4Remote sensor: Receives signals from the remote control.

5Next button: Press to skip to the next title, chapter, or track.

Note: Press and hold for three seconds to scan forward at 2,

4, 8, 16, or 32 times normal playback speed.

6Stop button: Press once to stop playback. The DVD player

remembers the point the playback stopped and resumes

playing at this point. Press twice to totally stop playback.The

DVD player does not remember the stop point.

NS-7DPDVD

www.insignia-products.com

Rear

Left

Item Description

1Stand: Swing away from the chassis to prop the DVD player

upright for viewing.

Item Description

1Strap connector: Attach one end of

a carrying strap here.

2Headphone jack 1: Connect a set of

headphones here. Internal speakers

are disabled with headphones

connected.

3Headphone jack 2: Connect a set of

headphones here. Internal speakers

are disabled with headphones

connected.

NS-7DPDVD

www.insignia-products.com

Right

Top

Item Description

1Power on/off switch: Turn the

DVD player on or off.

2Strap connector: Attach one

end of a carrying strap here.

3A/V in/out switch: Switch the

A/V jack between A/V input and

A/V output.

4A/V jack: Connect to an external

A/V source (A/V in) or player (A/V

out) like a monitor or amplifier.

5Brightness: Adjust the display

brightness.

6DVD port: Connect to a monitor

with a DIN cable.

7Volume: Adjust the volume.

8DC input jack: Connect the

power adapter or car cigarette

lighter adapter.

Item Description

1Open switch: Opens the disc tray.
