Insignia NS-P5113 Manual de usuario

User Guide

Portable CD/MP3 Player and Digital FM Tuner

NS-P5113

NS-P5113_08-1893_MAN_V1_ENGLISH.fm Page 1 Monday, March 30, 2009 1:09 PM

NS-P5113_08-1893_MAN_V1_ENGLISH.fm Page 2 Monday, March 30, 2009 1:09 PM

www.insigniaproducts.com 3

Insignia NS-P5113

Portable CD/MP3 Player and

Digital FM Tuner

Portable CD Player with FM Tuner

Contents

Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Setting up your CD player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Using your CD player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

90-day limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Safety information

Warning

To reduce the risk of electric shock, do not remove the cover

or back. There are no user-serviceable parts inside. Refer

all servicing to qualified service personnel.

The lightning flash with the arrowhead inside an

equilateral triangle is intended to alert you to the

presence of un-insulated, dangerous voltage within

your CD player’s enclosure. This voltage may be of

sufficient magnitude to constitute a risk of electrical

shock.

The exclamation point within an equilateral triangle is

intended to alert you to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying your CD player.

NS-P5113_08-1893_MAN_V1_ENGLISH.fm Page 3 Monday, March 30, 2009 1:09 PM

Insignia NS-P5113 Portable CD/MP3 Player and Digital FM

www.insigniaproducts.com

Important safety information

• The apparatus and AC adapter shall not be exposed to

dripping or splashing and no objects filled with liquids, such as

vases, shall be placed on the apparatus.

• To completely disconnect the apparatus from the mains power,

the mains plug of theAC adapter shall be disconnected from

the mains outlet.

• The mains plug of the AC adapter should not be obstructed OR

should be easily accessed during intended use.

• Excessively high sound pressure could harm or damage

hearing.

• Battery shall not be exposed to excessive heat such as

sunshine, fire or the like.

• Minimum distances of 4 inches (10 cm) around the apparatus

and AC adapter shall be available for sufficient ventilation.

• The ventilation should not be impeded by covering the

ventilation openings with items such as newspapers,

tablecloths, curtains, etc.

• No naked flame sources such as lighted candles should be

placed on the apparatus and AC adapter.

• Attention should be drawn to the environmental aspects of

battery disposal.

• The apparatus and AC adapter should be used in moderate

climates.

Surge protectors:

We recommend that you use a surge protector when you connect

your CD player to AC power. A surge protector will help protect your

CD player from lightning and power surges, which are not covered by

your warranty.

Follow these safety precautions:

• Read and retain all instructions.

• Do not open the CD door while the CD is spinning.

• Always keep the CD door closed when not in use.

• Keep all foreign objects out of the CD compartment.

This product utilizes a Class 1 laser to read CDs. Your

CD player is equipped with safety switches to avoid

exposure when the CD compartment door is open

and the safety interlocks are defeated. Invisible and

hazardous laser radiation exist when the door is open

and interlocks are failed or defeated. Avoid direct

exposure to the laser beam. Do not attempt to defeat

or bypass the safety switches.

NS-P5113_08-1893_MAN_V1_ENGLISH.fm Page 4 Monday, March 30, 2009 1:09 PM

Insignia NS-P5113 Portable CD/MP3 Player and Digital FM

www.insigniaproducts.com

• Place your CD player on a stable surface.

• Avoid installing your CD player in any of the following locations:

• Places exposed to direct sunlight or close to heat radiating

appliances, such as electric heaters.

• On top of other stereo equipment that radiates too much

heat.

• Places that lack correct ventilation or dusty places.

• Places subject to constant vibration.

• Humid or moist places.

Features

Caution

Do not expose your CD player to dripping or splashing and

do not set objects filled with liquid, such as vases, on top of

your CD player.

No. Component Description

1 / • When playing an audio CD, press to

skip or fast-search forward.

• When playing an MP3 CD, press to

search right.

• When playing the radio, press to tune

to a higher frequency station.

2 / / POWER ON • When playing an audio CD or MP3 CD,

press to start or pause playback.

• When an MP3 CD is paused, press to

search up.

NS-P5113_08-1893_MAN_V1_ENGLISH.fm Page 5 Monday, March 30, 2009 1:09 PM

Insignia NS-P5113 Portable CD/MP3 Player and Digital FM

www.insigniaproducts.com

3 PLAY MODE Press to select the playback mode. You can

select REPEAT1, ALL, DIR., INTRO, or

RANDOM.

4 Hold switch Slide to lock button controls so you do not

accidently press a button.

5 LINE OUT jack Plug an audio cable into this jack and into

the CD/AUX jack on an external audio

system.

6 PHONE jack Plug headphones into this jack.

7 Volume control switch Slide to adjust the volume.

8 DBBS switch Slide to the ON position to turn on bass

boost. Slide to the OFF position to turn off

bass boost.

9 DC INPUT jack Plug the AC/DC power adapter (not

supplied) into this jack and into an AC outlet.

10 LCD display Displays information about the currently

playing disc and various functions of your

CD player.

11 MEMORY/ENTER When playing the radio, press to store the

station in memory.

12 MENU/ESP/PRESET • When playing an audio CD, press to

turn the anti-shock feature on or off.

• When playing an MP3 CD, press to

start the search function.

13 / / POWER OFF • Press to stop audio CD playback.

• Press to cancel a playback list.

• Press to search down on an MP3 CD.

14 FUNCTION Slide to select CD or radio mode.

15 OPEN switch Press to open the CD compartment door.

16 / • When playing an audio CD, press to

skip or fast-search backward.

• When playing an MP3 CD, press to

search left.

• When playing the radio, press to tune

to a lower frequency station.

No. Component Description

NS-P5113_08-1893_MAN_V1_ENGLISH.fm Page 6 Monday, March 30, 2009 1:09 PM

Insignia NS-P5113 Portable CD/MP3 Player and Digital FM

www.insigniaproducts.com

Remote Control

No. Button Description

1 VOLUME • Slide to adjust the volume.

2 • When playing an audio CD, press to

skip or fast-search backward.

• When playing an MP3 CD, press to

skip or search left.

• When playing the radio, press to tune

to a lower frequency station.

3 • When playing an audio CD, press to

skip or fast-search forward.

• When playing an MP3 CD, press to

skip or search right.

• When playing the radio, press to tune

to a higher frequency station.

4 • When playing an audio CD or MP3 CD,

press to start or pause playback.

• When an MP3 CD is paused, press to

search up.

5 • Press to stop audio CD playback.

• Press to cancel a playback list.

• Press to search down on an MP3 CD.

SKI

NS-P5113_08-1893_MAN_V1_ENGLISH.fm Page 7 Monday, March 30, 2009 1:09 PM

Insignia NS-P5113 Portable CD/MP3 Player and Digital FM

www.insigniaproducts.com

Setting up your CD player

Installing batteries

To install batteries:

1Lift the battery compartment door on the bottom of your CD player.

Do not remove the door.

2Insert two AA alkaline batteries into the battery compartment.

Make sure that the + and – symbols on the batteries match the +

and – symbols inside the battery compartment.

3Close the battery compartment door.

Caution

Use only the size and type of batteries specified.

Make sure that you match the + and – symbols on the

batteries with the + and – symbols inside the battery

compartment. If you insert the batteries backwards, your CD

player may be damaged.

Do not mix different types of batteries together (such as,

alkaline, rechargeable, and carbon/zinc).

Do not mix old batteries and new batteries.

When you do not plan to use your CD player for a long

period of time, remove the batteries to prevent damage or

injury from possible battery leakage.

Do not try to recharge batteries not intended to be

recharged. They can overheat and rupture.

Note

If the symbol “LOW BATTERY” appears on the display,

batteries are weak and should be replaced.

NS-P5113_08-1893_MAN_V1_ENGLISH.fm Page 8 Monday, March 30, 2009 1:09 PM

Insignia NS-P5113 Portable CD/MP3 Player and Digital FM

www.insigniaproducts.com

Using the AC/DC power adapter (not supplied)

To use the AC/DC power adapter:

1Plug one end of the AC/DC power adapter (not supplied) into the

DC INPUT jack on the back of your CD player.

2Plug the other end of the AC/DC power adapter into a AC outlet.

Connecting to an external audio system

To connect your CD player to an external audio system:

1Make sure that your CD player is turned off and unplugged (if you

are using the AC/DC power adapter).

2Plug one end of an audio cable into the LINE OUT jack on your

CD player.

3Plug the other end of the audio cable into the CD/AUX jack on the

external audio system. Do not plug the cable into an amplifier

PHONE jack.

Connecting the headphones

To connect the headphones directly to the CD player:

• Plug the headphone cable into the PHONE jack on your CD

player.

Note

The AC/DC power adapter (not supplied) is an optional

accessory.

If the AC adapter is connected when regular batteries are

installed, the power supply automatically switches to the AC

power source.

Use only the optional AC/DC power adapter.

Make sure that the AC/DC power adapter matches with your

household voltage before connecting it into an outlet.

When you are not using AC power, unplug the AC/DC power

adapter.

Do not touch the AC/DC power adapter with wet hands

when it is connected to AC power.

NS-P5113_08-1893_MAN_V1_ENGLISH.fm Page 9 Monday, March 30, 2009 1:09 PM

Insignia NS-P5113 Portable CD/MP3 Player and Digital FM

www.insigniaproducts.com

To connect the headphones through the remote control:

• Plug the headphone cable into the green jack on the remote

control, then plug the remote control into the phone jack on

your CD player.

Using your CD player

Playing a CD

To play a CD:

1Connect the headphones (included) or optional earphones into

the PHONE jack on your CD player.

2Press the OPEN button to open the CD compartment door, insert

a disc with the label side facing up, then press down on the CD

compartment door until you hear a click.

3Set the VOLUME control to minimum.

4Press the / / POWER ON button. Your CD player turns on

and starts playing the disc. Now Reading appears on the display,

then the total number tracks and total playing time appear. After

the disc begins to play, the total number tracks and elapsed time

appear.

Caution

Your CD player is designed to play audio CDs. Do not try to

play any other type of discs.

NS-P5113_08-1893_MAN_V1_ENGLISH.fm Page 10 Monday, March 30, 2009 1:09 PM

Otros manuales para NS-P5113

Tabla de contenidos

Otros manuales de Reproductor de CD de Insignia

Insignia

Insignia NS-P3113 Manual de usuario

Insignia

Insignia NS-CD512 Guía de inicio rápido

Insignia

Insignia NS-CD512 Manual de usuario

Insignia

Insignia 09-0398 Manual de usuario

Insignia

Insignia NS-P5113 Manual de usuario

Insignia

Insignia NS-P4112 Manual de usuario

Insignia

Insignia NS-P3112 Manual de usuario

Insignia

Insignia NS-B4111 - CD Boombox With AM/FM Tuner Manual de usuario

Insignia

Insignia IS-PA040718 Manual de usuario

Insignia

Insignia NS-CD512 Manual de usuario

Insignia

Insignia NS-CD512 Manual de instalación y operación

Insignia

Insignia NS-CD512 Guía de inicio rápido

Insignia

Insignia IS-PA040717 Manual de usuario

Insignia

Insignia NS-P3114 Manual de usuario

Insignia

Insignia IS-DA1802 Manual de usuario

Insignia

Insignia IS-PA040720 Manual de usuario

Insignia

Insignia NS-P5113 Manual de usuario

Insignia

Insignia NS-P3111 Manual de usuario

Insignia

Insignia NS-DA1902 Manual de usuario

Insignia

Insignia NS-B4111 - CD Boombox With AM/FM Tuner Manual de usuario

Insignia

Insignia IS-PA040722 Manual de usuario

Insignia

Insignia NS-CD512 Manual de lista de piezas

Insignia

Insignia IS-PA040719 Manual de usuario

Insignia

Insignia NS-ES6113 - Micro System Manual de usuario

Manuales populares de Reproductor de CD de otras marcas

RCA

RCA RP-7923 Manual de usuario

Pioneer

Pioneer DEH-P3550MP XM Manual de usuario

Philips

Philips AZ1207 Manual de usuario

Philips

Philips CD582 Manual de usuario

Philips

Philips AZ 6821 Manual de usuario

Lasonic

Lasonic MSU-2020 Manual de usuario

THOMSON

THOMSON RCD150 Manual de usuario

Denon

Denon DCD-1420 Manual de usuario

Panasonic

Panasonic SJ-MR100 Manual de usuario

Onkyo

Onkyo DX-7210 Manual de usuario

Sony

Sony MZ-R3 Manual de usuario

Denon

Denon DVM-4800 Manual de usuario

JBL

JBL MR-32 Manual de usuario

RCA

RCA RCD152 Manual de usuario

Technics

Technics SL-PS770A Manual de usuario

Clarion

Clarion compact disc Manual de usuario

Sony

Sony MZ-M10 Manual de usuario

Philips

Philips Expanium AZ 1538 Manual de usuario
