INNOCN 29C1F-D Manual de usuario
29C1F-D User Manual for Art Monitor
English
Contents
Precautions
Package Content
Installation
Adjustment of monitor
Instructions for use
Specification
OSD menu
German Rhine TÜV Low Blue Light Certfication
Common troubleshooting
Warranty Information
Contact us
1
2
3
4
9
4
6
9
10
11
11
English
Precautions Before using this product, please read this User Manual carefully and keep it well
Please use a reliable grounded socket, Do not overload the socket, or it may cause fire or
electric shock.
Do not cover or block the vent hole in the rear casing, and do not use the product on a bed,
sofa, blanket or similar objects.
The range of the supply voltage of the monitor is printed on the label on the rear casing.
If it is impossible to determine the supply voltage, please consult the distributor or local
power company.
If the monitor will not be used for a long period, please cut off the power supply to avoid
electric shock in rainy days and damage due to abnormal supply voltage.
Keep the monitor away from water sources or damp places, such as bath rooms, kitchens,
basements and swimming pools.
Make sure the monitor is placed on a flat surface. If the monitor falls down, it may cause
human injury or device damage.
Store and use the monitor in a cool, dry and well ventilated place, and keep it away from
emission and heat sources.
Do not put foreign matters into the monitor, or it may cause short circuits resulting fire or
electric shock.
Do not disassemble or repair this product by self to avoid electric shock. If faults occur,
please contact the after-sales service directly.
Do not pull or twist the power cable forcedly.
There is a polarizer layer (not a protective film) on the surface of the screen. Do not peel
it off, or the product may be damaged and the warranty will be invalid.
1
English
Package Content
Packing list
Please check that the package of the monitor contains all parts. If any part is lost, please contact
the distributor.
The color and shape of parts may vary with models. Figures in this User Manual are for reference only.
Cables supplied may vary with purchased products. Figures in this User Manual are for reference only.
Display screen Stand Base
Type-C cable
Color calibration report
HDMI Cable
User Manual
Power cable
29C1F User Manual for Art Monitor
2
English
3
Installation of base
Installation
Note: During standing of the monitor, do not take out the monitor from foams, and do not
pinch the liquid crystal screen with hand to avoid damage to the screen.
2. Take off the top cover of Polylong, take out the body bag and put the body back into the
original bottom cover of Baolong.
Lower foam cover
Monitor
3. Take out the bracket and base, and tighten the manual screws on the base after assembly.
Stand
Base
hand screw
1. Open the carton package, take out the upper and lower foam covers and put them flat on the table top.
Lower foam cover
Upper foam cover
4. Insert the hook at the front end of the shaft of the lifting bracket into the bayonet of the rear shell
obliquely, and gently press the tail end perpendicular to the surface of the rear shell, so that the
lock of the lifting bracket can be buckled on the quick release button of the rear shell, and the quick
release button has a return. The snap action indicates that the tail end has also been snapped into
place.
Quick release
button
5. Simply hold the stand with hand to stand the monitor upright.
Do not press the LCD
English
4
Adjustment of monitor
Instructions for use
Cable connection：
* The bottom interface configuration at the back of the monitor varies with products.
* Note: If the power cable or signal cable is damaged, you must replace it with special soft cables or
special components purchased from the manufacture or maintenance department.
Rotation angle
-45° -+45°
Vertical angle
-90° -+90°
Tilting angle
-5.0°- +20°
Height adjustment
0- 120mm
OR
AUDIO OUT
Connect audio outputting
devices such as earphones
to the AUDIO OUT port.
Type-C interface
A Type-C line can be used
to connect to data ports of
machines and external
terminals.
DP interface
Use the DP cable to
connect the DP IN port of
the product to the DP
OUT port of a PC.
HDMI interface
Use the HDMI-DVI cable
(not included) to connect
the HDMI IN port of the
product to the DVI OUT
port of a PC.
Use the HDMI cable to
connect the HDMI IN port
of the product to the
HDMI OUT port of a PC
Please connect the power cable
plug to the corresponding port
of the monitor, and connect the
other end to a properly
grounded power outlet.
AC IN interface
English
5
Description of buttons
Menu button: Press to enter sub-menus/ quickly enter the main menu
Down button: Press to move down in the menu/quickly adjust the brightness
Up button: Press to move up in the menu/quickly adjust the volume
Exit/hot key: Press to return to the previous menu/quickly switch input signals of the port
Power button: Press to turn on/off the monitor
Button Function
1
2
3
4
5
Explanation of indicator light
6. Indicator light: If the white light is normally on, it is indicated that the device is powered on, and that
the monitor is running normally. red light indicates no video signal detected or low voltage. Please
make sure that your computer is turned on and all video cables are fully plugged in and/or connected.
English
6
1 2 3 4 5
OSD menu
Enter the main menu
Adjust the brightness
Adjust the volume
Switch port input signal
Power ON/OFF
1
2
3
4
5
Menu description
The color and shape of the OSD menu of the actual computer may be slightly different from them
shown in the figure.
Specifications of the OSD menu may change with improvements of functions without prior notice.
The screen display (OSD) menu can be used to adjust settings of the monitor and is shown on the
screen after the monitor is powered on and the button is pressed.
1. Press one of the buttons ( ) to activate the browser screen.
When booting for the first time, you need to set the default language of the monitor menu.
Press buttons ( ) to select the language to be set, and press the OK button( ) to confirm.
Portugues do Brasilazil Deutsch Nederland
简体中文English 한국어
Suomi Français Ελληνικά Indonesia
Українська Tiếng Việt繁体中文 Türkçe
Italiano 日本語 Malaysia Polskie
Português Pусский Español ไทย
Please select the default language
请选择默认语言
English
7
2. Press to enter the OSD screen.
3. Press or to scroll through the functions.
- Select the desired function, and press to enter the sub-menu.
- Press or to scroll through sub-menus, and press key to select and confirm the desired function.
- Press or to select one option, and press to confirm settings and exit from the current menu.
4. Press to exit from the menu screen
Functions of the monitor vary with models, and the functions in this manual are for reference only
Professional
Standard Mode N/A
N/A
N/A
N/A
1.6/1.8/2.0/2.2/2.4/2.6/2.8/S.curve
Natural/Design/Warm/Cool/User C.T1/User C.T2/User C.T3
0-5
0-100
0-100
R/G/B/C/M/Y
sRGB Mode
Adobe Mode
Uniformity Mode
Gamma
C.T settings
Sharpness
Shadow Balance
Low blue light
Hue
Saturation R/G/B/C/M/Y
Dynamic Brightness Off/Standard/Expert/Elaboration
Professional
Picture Sttings
Game Settings
Standard Mode
sRGB Mode
Adobe Mode
Uniformity Mode
Gamma
C.T settings
2.2
Natural
PIP/PBP
OSD Settings
Other Settings
English
8
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) this device must accept any interference received, including
interference that may cause undesired operation.
CAN ICES-3 (B)/NMB-3(B)
Game
Settings
Off/On
Off/On
Off/On
Off/On
Off/Normal/Fast/Ultrafast
Off/On/Position
Off/Crosshair 1/Crosshair 2/Crosshair3/Crosshair 4/Crosshair 5/Crosshair6
RTS/RPG Mode
FPS Arena Mode
MOBA Arena Mode
Adaptive-Sync
Response Time
Refresh Rate
Game Crosshair
Sttings
PIP/PBP
OSD
Settings
Other
Settings
Off/Movie mode/Reading mode/Night mode/Care eyes mode
0-100
0-100
Off/On
Wide Screen/4:3/1:1/Auto
Brightness
Contrast
DCR
Contextual model
Aspect ratio
PIP/PBP Mode Off/PIP Mode/PBP 2win 1:1/PBP( Phone1)/PBP( Phone2)
DP/HDMI/Type-C
Auto/DP/HDMI/Type-C
Top Right/Top Left/Bottom Right/Bottom Left
Small/Medium/Large
5-100
0-100
0-100
0-5
0-100
Brightness/Contrast/Volume/Mute/Shadow Balance/
Game Crosshair/Refresh Rate
/
Contextual model/
PIP/PBP Mode/Input Signal/Dynamic Brightness
Sub-Singal Source
Audio source
PIP Position
PIP Size
Window Swap
Language
OSD Time Out
OSD H-Position
OSD V-Position
OSD transparency
Hotkey1 Setting
Hotkey2 Setting
Hotkey3 Setting
Input Sinal Auto/DP/HDMI/Type-C
Volume
Mute Off/On
Off/On
Off/On
Auto Power
Eyeshield Remind
No/YesReset
Input Source: HDMI/ Resolution: 2560x1080@60Hz/Mode: Standard Mode/ SN:0000000000000Information
English/简体中文/한국어/ /Portugues do Brasilazil/ Deutsch/Nederland/ Suomi/
Français/Ελληνικά/Indonesia/Italiano/日本語/Malaysia/Polskie/Português/Pусский/
Español/ไทย/Українська/Tiếng Việt/繁體中文/Türkçe
Functions of the monitor vary with models, and the functions in this manual are for reference only.
