INHECO DWP Manual de usuario

Doc ID: 900434-001

March 2018

INHECO Single Position Incubators

Incubator MP / DWP

Part No.: 7300003 / 7300006

Incubator Shaker MP/ Shaker DWP

Part No.: 7300013 / 7300009



INHECO 02

Doc ID: 900434-001

March 2018

INHECO Industrial Heating and Cooling GmbH reserves the right to modify their

products for quality improvement. Please note that such modifications may not be

documented in this manual.

This manual and the information herein have been assembled with due diligence.

INHECO GmbH does not assume liability for any misprints or cases of damage resulting

from misprints in this manual. If there are any uncertainties, please feel free to contact

[email protected]. → How to contact INHECO, page 6.

The brand and product names within this manual are registered trademarks and belong

to the respective titleholders.

INHECO 02

Doc ID: 900434-001

March 2018

Table of Contents

Important Notes ......................................................................................... 03

General Information ..................................................................................... 03

Explanation of symbols................................................................................ 04

Abbriviations and Glossary .......................................................................... 04

Warranty ...................................................................................................... 05

How to contact INHECO .............................................................................. 05

Product Description .................................................................................. 06

Intended Use ............................................................................................... 06

Scope of Supply........................................................................................... 07

Functional Elements .................................................................................... 08

Labels .......................................................................................................... 09

Technical Data............................................................................................. 10

Shaker functionality Incubator Shaker MP / DWP ....................................... 12

Thermal functionality Shaker MP / Shaker DWP ......................................... 13

Safety instructions .................................................................................... 14

Product-specic Risks ................................................................................. 14

Technical Alterations ................................................................................... 15

Malfunctions................................................................................................. 15

Hardware installation ................................................................................ 16

Scope of Supply........................................................................................... 16

Initial Operation............................................................................................ 16

Electrical Details General ............................................................................ 18

Adress Switch .............................................................................................. 19

Connecting devices ..................................................................................... 19

Mechanical Integration................................................................................. 21

Labware Use and Detection ........................................................................ 22

Communication with the Incubator.......................................................... 23

Integration in workstation............................................................................. 23

COM port identication ................................................................................ 23

Example conguration of several Incubators to the USB Host PC .............. 25

Operation.................................................................................................... 26

Typical Process Example for integration in robotic systems........................ 26

 ............................................................................................... 28

Cleaning....................................................................................................... 28

Decontamination.......................................................................................... 28

Servicing ..................................................................................................... 28

Software updates......................................................................................... 28

Calibration and Adjustment.......................................................................... 29

Trouble-Shooting & Support ........................................................................ 29

Return to INHECO only with RMA Number ................................................. 30

Transportation and Storage ......................................................................... 30

Shut Down and Disposal ............................................................................. 30

Assembling the transportation lock.............................................................. 31

Quality......................................................................................................... 32

Final QS Tests ............................................................................................ 32

Calibration and Adjustment.......................................................................... 32

Automatically self test AQS ......................................................................... 32

Failures ....................................................................................................... 33

Drawer failure ............................................................................................... 33

Accessories................................................................................................ 35

Appendix .................................................................................................... 36

INHECO 03

Doc ID: 900434-001

March 2018

1 

1.1. General Information

Read the user instructions completely. The manual explains how to handle the Incubator

DWP, Incubator MP, Incubator Shaker DWP and Incubator Shaker MP (Incubator

devices). For the operation of the Incubator devices a third party workstation software is

strongly recommended. → Communication with Incubator devices®, chapter 5

The manual explains how to handle the INHECO stackable devices.

In case the instructions contained in this manual are not followed, injury or product

damage cannot be excluded.

Missing or insufficient knowledge of the manual leads to loss of liability against

INHECOGmbH.

This manual is part of the Incubator devices and must be retained until the unit is

disposed of and must be passed on with the Incubator device when the unit is taken

over by a new user.

The Incubator devices meet the acknowledged rules of technology and comply with

today‘s standards.

Manual instructions must be followed in order to limit the safety risk during operation of

the unit.

Security-related warnings in this manual are classified into three hazard levels:

- The signal word WARNING indicates hazards which – without precautionary

measures – can result in serious injury or even death.

- The signal word CAUTION is given to indicate hazards which – without precautionary

measures – can result in minor to moderate injuries or could disturb the proper

functioning of the unit.

- The signal word NOTE stands for the general precautionary measures that have to

be taken to avoid damaging the device.

- The signal word NOTICE stands for the general measures that help using the device.

Contact INHECO in case there are any uncertainties of how to operate or how to handle

the Incubator devices.

Your opinion about this manual provides us with valuable insights on how we can

improve this document. Please do not hesitate to direct your comments to

[email protected], → How to contact INHECO, page 6

INHECO 04

Doc ID: 900434-001

March 2018

1.2. Explanation of symbols

Symbol Explanation

A possible danger, leading to serious bodily harm is being pointed out to you.

Caution: hot surface

Excenter within the device

Indication for electrostatic discharge (ESD)

·Bullet points indicates an instruction.

-Hyphens refer to enumeration.

→indicates refer to and are mostly an active link

Blue writing indicates a software button

1.3. Abbriviations and Glossary

The document uses the following terms

CC Communication controller

Controller Microprocessor with on chip peripheral

 Cyclic Redundany Check

FCS Firmware Command Set

Heater Same as Temperature Controller

IVD (D) In vitro diagnostic (directive)

 Micro Plate

 Polymerase Chain Reaction

 Pulse-Width Modulation

Shaker Controller for shaker regulation

TBC To Be Continued

Temperature

Controller

Controller for heat regulatioin

 Universal Serial Bus

CE Conformity Mark

 Nationally Recognized Testing Laboratory

 Dynamic Link Library

PC Personal Computer

 European Union

SBS Society for Biomolecular Screening

DWP Deepwell Plate

IVD In vitro diagnostics

FDA Food and Drug Administration

DIP Dual In line package

N.A. Not Applicable

 Room Temperature

wo without

wwith

INHECO 05

Doc ID: 900434-001

March 2018

1.4. Warranty

The warranty period starts on the date of shipment. Any damage caused by operating

the Incubator device outside the specifications and guidelines leads to the loss of

warranty. Broken seals on INHECO devices lead to the loss of warranty as well.

INHECO will only accept parts / devices for return that do not pose a threat to the health

of our staff. In particular, the devices may not have been used in Biosafety Level 3 and 4

environments, or have been exposed to radioactive or radiation materials. → Cleaning

and Decontamination, page 37.

Devices exposed to Biosafety level 3 and 4 Environments are not accepted by INHECO

for return.

1.5. How to contact INHECO

INHECO GmbH

Address Fraunhoferstr. 11

82152 Martinsried

Germany

Telephone - Sales +49 89 899593 120

Telephone - Techhotline +49 89 899593 121

Fax +49 89 899593 499

E-Mail - Sales [email protected]

E-Mail - Technical -Hotline [email protected]

Website www.inheco.com

Technical Support & Trouble Shooting Instructions:

http://www.inheco.com/service/technical-support.html

INHECO 06

Doc ID: 900434-001

March 2018

2 

2.1. 

INHECO’s Incubators (Incubator MP, Incubator DWP, Incubator Shaker MP and

Incubator Shaker DWP) are automated and compact single incubating positions for the

use in fundamental research, drug discovery, clinical research and diagnostic

applications in automated liquid handling stations.

The incubators can be used as stand-alone devices or stacked to form a tower. The

flexible design of the incubator devices allow even stacking of different devices in one

tower. The unique vibration reduced shaking principle offers free programmable shaking

curves (orbital, linear, eight, elliptic, etc) and amplitudes. The precise automated drawer

system guarantees a direct and easy access by robotic grippers and pipetting heads.

The Incubator devices have a built-in precise temperature and shaker control (only

shaker devices), plate loading sensors, several test routines and an USB interface for

controlling the devices, enabling the use of the Incubator products in FDA, IVD compliant

environments and applications. Software and verification tools are available to form a

complete thermal solution for all kinds of incubation applications.

The Incubator devices are designed specifically for use in Life Science and In Vitro

Diagnostics. The Incubator devices are prepared for easy integration into IVD

applications, but the final IVD validation has to be performed by the first marketer (IVD

application).

When using the devices of the Incubator family in a Biosafety Laboratory Environment,

the user of the device is responsible for labeling the device according to the WHO

Laboratory Biosafety Manual (ISBN 92 4154650 6). The user is furthermore responsible

for operating the devices of the Incubator family depending on the biosafety level

regulations according to the WHO Laboratory Biosafety Manual.

A technical skilled integrator has to install and integrate the Incubator. The Incubator

should be used exclusively by laboratory professionals trained in laboratory techniques

with labautomation systems and having studied the instructions for use of this

instrument.

INHECO 07

Doc ID: 900434-001

March 2018

2.2. Scope of Supply

Before initial operation, make sure that the shipment of your unit and its scope of supply

is complete and no parts are damaged.

In case of parcel or product damages, make photos of the damaged boxes and products

and email them to T[email protected] immediately. Transportation damages must

be reported to INHECO within 7 days of delivery. The following components should be

included in each shipment:

Fig.1: Components

( 1 ) Incubator 1) ( 3 ) 15 - Pole Sub-D-Connector

( 2 ) USB cable ( 4 ) Power cord Europe, UK or US (not scope of supply unless ordered)

( 5 ) Power supply (not scope of supply unless ordered)

1) Image differs depending on which system has been ordered

INHECO 08

Doc ID: 900434-001

March 2018

2.3. Functional Elements

Figure 2 introduces the terminology of the Incubator´s functional elements.

Fig.2: Functional elements

( 1 ) Fan ( 4 ) USB Connnector ( 7 ) 15 pole Sub-D-Connector male.

( 2 ) Loading drawer ( 5 ) Address Switch ( 8 ) 15 pole Sub-D-Connector female.

( 3 ) Front door ( 6 ) Power Connector

INHECO 09

Doc ID: 900434-001

March 2018

2.4. 

The identification label with part number and serial number also contains important

technical indications. The electrical specification on the label must meet your local

situation. The label is placed on the back panel of the Incubator device. The identification

label must not be removed. If it has become illegible or falls off, it has to be replaced by a

new identification label. New labels can be ordered at INHECO. In case the label is

missing and you do not know the part number and serial number, they can also be read

out with the software ( IVDD Incubator software) which can be downloaded from the log

in section of www.inheco.com. → Manual INHECO Incubator Shaker control.

Incubator MP Incubator DWP

1000

INHECO GmbH

82152 Martinsried / Germany

04PN:

SN:

Input: 24V

7300003

Incubator MP

2016-09

Rev.:

30W

Fuse: F3.15A

Incubator Shaker MP Incubator Shaker DWP

Fig.3:

1000

INHECO GmbH

82152 Martinsried / Germany

04PN:

SN:

Input: 24V

7300013

Incubator Shaker MP

2016-09

Rev.:

50W

Fuse: F4.0A

Examples of identication labels

Fig.4: Labels outside device or package

Fig.5: Labels within the device

1000

INHECO GmbH

82152 Martinsried / Germany

05PN:

SN:

Input: 24V

7300006

Incubator DWP

2016-09

Rev.:

45W

Fuse: F3.15A

1000

INHECO GmbH

82152 Martinsried / Germany

05PN:

SN:

Input: 24V

7300009

Incubator Shaker DWP

2016-09

Rev.:

65W

Fuse: F4.0A

Devices are ESD sensible

Transport Lock (3 pieces)!

Always use during

transportation!

Remove transport lock

before use!

Caution Hot Excenter label in shaker

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Accesorios de INHECO

INHECO

INHECO Thermoshake Manual de usuario

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario
