ELECTRICAL SAFETY
The electric motor has been designed for one
voltageonly.Alwayscheckthatthepowersupply
corresponds to the voltage on the rating plate.
YourINGCO toolisdoubleinsulatedin
accordance with EN 60745 ; therefore
no earth wire is required.
REPLACING/
INSERTING THE SAW
BLADE
When mounting the saw blade,
wearprotectivegloves. Dangerof
injury when touching the saw blade.
When changing the saw blade,
take care that the saw blade
holderisfreeofmaterialresidue,
e. g. wood or metal shavings.
INSERTING THE SAW BLADE
•
Turn the locking sleeve 4 approx. 90° in the
direction ofthe arrow and hold. Push the saw
blade into the saw blade holder. Release the
locking sleeve 4 again.
CHECK THE TIGHT SEATING OF THE SAW
BLADE.
•
loose saw blade can fall out and lead to injuries.
Forcertainwork, thesaw blade canalso be turned
through180°(withthe teethpointedupwards)and
re-inserted again.
REMOVING THE SAW BLADE
•
Turn the locking sleeve 4 approx. 90°in the
directionofthe arrow and hold. Removethesaw
blade .
DUST/CHIP EXTRACTION
•
Dusts from materials such as lead-containing
coatings, some wood types, minerals and metal
can be harmful to one’s health.Touching or
breathing-in the dusts can cause allergic reactions
and/orlead torespiratory infectionsof the useror
bystanders.
•
Certain dusts, such as oak or beech dust,
are considered as carcinogenic, especially in
connection with wood-treatment additives
(chromate, wood preservative). Materials
containingasbestosmay onlybe worked by
specialists.
---Provideforgoodventilation oftheworking
place.
--- It isrecommended to wear a P2filter-class
respirator.
Observe the relevant regulations in your country
for the materials to be worked.
•
Prevent dust accumulation at the
workplace.
Dusts can easily ignite.
INSTRUCTIONS FOR
USE
Always observe the safety
instructions and applicable
regulations.
Observe correct mainsvoltage!The
voltage of the power source must
agreewiththevoltagespecifiedon
the nameplate of the machine.
PIVOTING AND RETRACTABLE FOOTPLATE
• Due to its movability, the adjustable footplate
adapts to the required angular position of the
surface.
•
Dependingonthesaw blade being used andthe
application, thefootplate can bemoved inlength
way direction in three steps. Press the release
button for the footplate and slide the footplate
