InFocus LP130 Manual de usuario

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio communi-

cations. Operation of this equipment in a residential area is likely to cause harm-

ful interference in which case the user will be required to correct the interference

at his own expense.

Canada

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Can-

ada.

Safety Certifications

UL, CUL, TÜV, NOM, IRAM

EN 55022 Warning

This is a Class A product. In a domestic environment it may cause radio interfer-

ence, in which case the user may be required to take adequate measures.

Declaration of Conformity

Manufacturer: InFocus Corporation

27700B SW Parkway Ave. Wilsonville, Oregon 97070 USA

European Office: Olympia 1, NL-1213 NS Hilversum, The Netherlands

We declare under our sole responsibility that the LP130 projector conforms to the

following directives and norms:

Directive 89/336/EEC, Amended by 93/68/EEC

EMC: EN 55022

EN 55024

EN 61000-3-2

EN 61000-3-3

Directive 73/23/EEC, Amended by 93/68/EEC

Safety: EN 60950: 1992 + A1 + A2 + A3 + A4: 1997

February, 2001

Australian Certification C-tick mark

Trademarks

Apple, Macintosh, and PowerBook are trademarks or registered trademarks of

Apple Computer, Inc. IBM and PS/2 are trademarks or registered trademarks of

International Business Machines, Inc. Microsoft, PowerPoint, and Windows are

trademarks or registered trademarks of Microsoft Corporation. Digital Light Pro-

cessing is a trademark or registered trademark of Texas Instruments. InFocus and

LP are trademarks or registered trademarks of InFocus Corporation.

TABLE OF CONTENTS

Safety Instructions iii

Introduction 1

Image Resolution 1

Compatibility 1

Unpacking the Projector 1

Usage Guidelines 3

If You Need Assistance 4

Warranty 4

Setting up the Projector 5

Connecting a Computer 7

Connecting a Video Player 8

Powering up the Projector and Adjusting the Image 9

Turning Off the Projector 9

Using the Projector 11

Basic Image Adjustment 11

Adjusting the Projector 11

Using the Remote Control 13

Using the Keypad and Remote Buttons 14

Using the On-Screen Menus 16

Display Menu 17

Image Menu for Computer Sources 19

Image Menu for Video Sources 21

Control Menu 22

Advanced Menu 23

Language Menu 24

Status Menu 25

Maintenance & Troubleshooting 27

Cleaning the Lens 27

Replacing the Projection Lamp 27

Replacing the Batteries in the Remote Control 31

Using the Security Lock 31

Troubleshooting 32

Ta b l e o f C o n t e n t s

Appendix 37

Specifications 37

Accessories 38

Portable and Laptop Activation Chart 40

Using Video Mirroring with a PowerBook Computer 45

Projected Image Size 46

Index 47

iii

SAFETY INSTRUCTIONS

Please read and follow all safety instructions provided BEFORE

using your new projector. Failure to comply with safety instruc-

tions may result in fire, electrical shock, or personal injury and

may damage or impair protection provided by equipment. Please

save all safety instructions.

Safety Definitions:

•Warning: Statements identify conditions or practices that

could result in personal injury.

•Caution: Statements identify conditions or practices that could

result in damage to your equipment.

Safety Symbols:

Attention: For information about usage of a feature, please

refer to the User’s Guide.

Warning: Hot surface. Do not touch.

An arrow pointing to the lamp door on the projector.

Safety Terms:

•Warning: Don’t look directly into the lens when the projector is

turned on.

•Warning: To replace the lamp, turn the projector off

and unplug the power cord. To avoid burns, wait 30 min-

utes before opening the lamp access grill. Follow all instruc-

tions provided in this User’s Guide.

•Warning: Please use the power cord provided.

•Warning: Refer all service to qualified service personnel. Ser-

vicing your own projector will void the warranty. See the fol-

lowing page for the customer service contact information.

•Caution: Don’t block ventilation openings.

Safety Instructions

•Caution: Don’t set liquids on the projector. Spilled liquids may

damage your projector.

•Caution: Don’t place the projector on a hot surface or in direct

sunlight.

•Caution: Do not drop the projector. Transport the projector in

an InFocus-approved case; see page 39 for a list of cases.

Important Operating Considerations

Do not place the projector on a tablecloth or other soft covering

that may block the vents. In the unlikely event of the bulb ruptur-

ing, thoroughly clean the area in front of the projector and dis-

card any edible items placed in that area.

Customer Service

If you need assistance, call InFocus Customer Service directly at

1-800-799-9911. Support is free between 6 a.m. and 6 p.m. PST,

Monday through Friday. Support is available in North America

after hours and weekends for a fee at 1-888-592-6800.

Or, send us an e-mail at techsupport@infocus.com.

In Europe, call InFocus in The Netherlands at (31) 35-6474010.

In Asia, call InFocus in Singapore at (65) 353-9424.

Do not place objects in

this area in front of the projector

2ft(.6m)

INTRODUCTION

The InFocus®LP130™ digital projector is specifically designed

for the mobile presenter. It generates crisp, clear images using

Digital Light Processing™ (DLP) technology, and features an

M1-DA type DVI connector for easy, built-in digital/analog and

USB connectivity. It is easy to connect, easy to use, easy to trans-

port, and easy to maintain.

Image Resolution

NOTE: The LP130 automatically

expands 640x480 and 800x600

images to 1024x768. You can dis-

play these images at their native

resolutions using the Resize option

in the Image menu. See page 19

for more information.

The XGA resolution of the LP130’s projected image is 1024x768.

The projector is compatible with screen resolutions up to

1280x1024. If your computer’s screen resolution is higher than

1280x1024, reset it to a lower resolution before you connect the

projector.

Compatibility

The projector is compatible with a wide variety of computers and

video devices, including:

•IBM-compatible computers, including laptops, up to 1280x1024

resolution.

•Apple®Macintosh®and PowerBook®computers up to

1280x1024 resolution.

NOTE: The projector is compati-

ble with 1080i and 720P HDTV

formats.

•Most standard VCRs, DVD players, HDTV sources, camcord-

ers and laser disc players.

Unpacking the Projector

The projector comes with the items shown in Figure 1. Check to

make sure all are included. Contact your InFocus dealer imme-

diately if anything is missing.

If you are experienced in setting up presentation systems, use the

Quick Start card that was included in the shipping box. For com-

plete details on connecting and operating the projector, refer to

this User’s Guide. Electronic versions of this user’s guide in mul-

tiple languages are available on the included CD and on our web-

site at www.infocus.com.

Introduction

A registration card is included in the box. Register to receive

product updates, announcements, and special offers from

InFocus. Or, register online at www.infocus.com/service/register

and you will be automatically entered to win free merchandise.

FIGURE 1

Shipping box contents

1. LP130 digital projector +

lens cap

5. Remote control

2. Soft carry case 6. Analog computer cable

3. User’s Guide, Quick Start

card, and CD

7. Composite video cable

4. Power cord 8. S-video cable

data

video

keystone

forward

backward

menu/select

FIGURE 2

Side view of projector

Usage Guidelines

•Do not look directly into the projection lens when the projector

is turned on. The bright light may harm your eyes.

•Do not block the grills on the projector. Restricting the air flow

can cause it to overheat and turn off. If this happens, you must

wait a minute before attempting to turn it back on.

•Handle the projector as you would any product with glass

components. Be especially careful not to drop it.

•Avoid leaving the projector in direct sunlight or extreme cold

for extended periods of time. If this happens, allow it to reach

room temperature before use.

•Transport the projector in a vendor-approved hard or soft case.

Part numbers for these cases are listed on page 39.

security lock

power

cord

connector

power

switch

keypad

zoom ring focus ring

computer and video

connectors

Introduction

If You Need Assistance

The first place to look for help is in this manual. Be sure to check

the guidelines in “Troubleshooting” on page 32. Or, check the

Service and Support section of our website at

http://www.infocus.com/service. You’ll find a Technical Library,

FAQs, and support contacts including a technical support e-mail

form.

If those sources don’t answer your question, call your InFocus

dealer. You can also call InFocus Customer Service directly at

1-800-799-9911. Call between 6 a.m. and 6 p.m. PST, Monday

through Friday. Service is available in North America after hours

and on weekends for a fee at 1-888-592-6800.

In Europe, call InFocus in The Netherlands at (31) 35-6474010.

In Asia, call InFocus in Singapore at (65) 353-9424.

Or, send us an e-mail at techsupport@infocus.com

Our World Wide Web address is http://www.infocus.com.

Warranty

This product is backed by a limited two-year warranty. The

details of the warranty are printed at the back of this manual.

Included with the standard warranty is Priority Care* for one full

year and 90 days of free 7x24 Technical Support (after 90 days

there will be a minimal $35/incident fee). An extended warranty

plan may be purchased from your InFocus dealer, any time dur-

ing the original two year warranty period. Refer to page 39 for

the part number.

When sending your projector in for repair, InFocus recommends

shipping the unit in its original packing material, or having a pro-

fessional packaging company pack the unit for shipping. Do not

ship your projector in the enclosed soft case. Please insure your

shipment for its full value.

* Priority Care is currently available in the U.S., Canada, EU coun-

tries, Switzerland and Norway.

Otros manuales para LP130

Tabla de contenidos

Otros manuales de Proyector de InFocus

InFocus

InFocus LP500 Manual de usuario

InFocus

InFocus Quantum Laser Superior Series Manual de usuario

InFocus

InFocus LP335 DRAGONFLY Manual de usuario

InFocus

InFocus IN118HDSTa Manual de usuario

InFocus

InFocus LP 640 Manual de usuario

InFocus

InFocus SP777 Manual de usuario

InFocus

InFocus LASER PROJECTOR LP 540 Manual de usuario

InFocus

InFocus Projector Manual de usuario

InFocus

InFocus Work Big IN35 Manual de usuario

InFocus

InFocus LASER PROJECTOR LP 540 Manual de usuario

InFocus

InFocus IN5555L Manual de usuario

InFocus

InFocus LP790 Instrucciones de instalación

InFocus

InFocus SP5700 Guía del administrador

InFocus

InFocus IN3134a Manual de usuario

InFocus

InFocus LP1200 Manual de usuario

InFocus

InFocus LP400 Manual de usuario

InFocus

InFocus LP280 Manual de usuario

InFocus

InFocus SP5700 Manual de instalación

InFocus

InFocus Work Big IN32 Guía

InFocus

InFocus LP 120 Manual de usuario

InFocus

InFocus Proxima DP2000s Manual de usuario

InFocus

InFocus SP5700 Manual de usuario

InFocus

InFocus X6 Manual de usuario

InFocus

InFocus LP330 Manual de usuario

Manuales populares de Proyector de otras marcas

iEmmet

iEmmet MP-312 Manual de usuario

Epson

Epson VS400 Manual de usuario

Sony

Sony VPL-HS10 Marketing Specifications & Features Manual de usuario

Sony

Sony VPL-HW65ES Manual de servicio

Toshiba

Toshiba TLP-791U Manual de usuario

Philips

Philips LC1341 Guía de referencia

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manual de usuario

NEC

NEC NP600S EDU Manual de usuario

BenQ

BenQ SH753P Manual de usuario

Eiki

Eiki EK-623U series Manual de usuario

Epson

Epson PowerLite Pro Cinema 6020UB Manual de usuario

Epson

Epson PowerLite Home Cinema 705HD Manual de usuario

Christie

Christie LHD700 Manual de usuario

Navitar

Navitar FX Manual de usuario

Sony

Sony SRX-R815P Manual de usuario

Vivitar

Vivitar DP1500 X Manual de usuario

Acer

Acer C20 Series Manual de usuario

Asus

Asus ZenBeam Latte Manual de usuario
