Chapter 1 System Overview
1.1 Product Description
V3060 series new-generation network digital video recorder is
integrated multiple advanced IT technologies and manufactured
under strict quality control system. The DVR supports H.264
encoding and partial channel supports up to 4CIF (D1) resolution at
major stream which meets the demand of high level surveillance
system.
V3060 series supports a maximum of 16-ch local video inputs and
16-ch audio inputs. Each video channel supports H.264 dual stream
compression. The recorder supports USB2.0 high speed backup as
well as mouse and keyboard operation. It also supports composite
streams and video stream encoding. Audio and video is
synchronized in composite streams encoding. The DVR also
supports maximum 32-ch video parallel connection.
V3060 series DVR can not only work independently in a local site,
but also build a powerful security surveillance network. This series
has been widely used in finance, public security, military, telecom,
traffic, power station, education and water project.
Features
yEmploy high performance Power PC structure and embedded
Linux operating system
yPAL/NTSC format video signal is supported
yH.264 video compression
yG.711 audio compression
yEach channel supports dual streams, maximum 4CIF (D1) at
major stream and CIF at minor stream
yVideo encoding parameters for each channel is independent
and adjustable
y1-ch VGA and 2-ch BNC outputs
yThe 8-ch device supports 1/4/6/8 split screen playback, while
the 16-ch supports 1/4/6/8/9/10/13/16 split screen preview. The
channel order is adjustable
ySupport live view group switch, manual switch and automatic
cycle, the interval of automatic cycle can be adjusted
ySupport playback electronic zoom
yScreen out designated channel
ySupport motion detection, video loss, video mask detection
and video privacy mask
yCompatible with multiple control protocols of leading encoder,
support preset and pattern
ySupport zoom-in function by mouse operation when control
Infinova second generation dome
y8 SATA hard disks supported
yHard disk standby and formatting function
yThe exported file formats are compatible with Windows. Hard
disk space pre-allocation technology is adopted to avoid disk
patch
yRecording activation mode including manual, scheduled,
alarm
ySwitching value alarm/motion detection pre-record and
delay-record functionality
yRecording time section, and recording activation mode can be
varied for each time section
ySearch recording file via time, channel number and recording
type; forward and backward play modes are available
ySupport playback on two monitors
yBackup via USB port
yBuilt-in SATA writer is optional
y16-ch alarm inputs and 4-ch alarm outputs
ySupport video loss, motion detection and video mask alarm
yProvide various abnormity hand modes, support hard disk full,
hard disk error, unauthorized access and network conflict
alarm
ySend out audible warning, upload to control center, activate
alarm output, and pop out the alarm prompt image once alarm
occurs
ySelf-recovery when system run abnormally
ySupport operations via front panel keys, mouse, remote
controller and keyboards
yTwo-level user access management
ySupport password authentication logon
yLog and search function
yLocal storage
ySupport SNMP
yTwo access modes: Local and network
yLocal or remote control Pan/Tilt or dome
y10M/100M/1000M self-adaptive network port
yBuilt in TCP/IP, UDP, PPPoE, DHCP, etc network protocols,
support ADSL (PPPoE) dialing
ySupport remote search, recording, transmission and live
monitoring can be performed simultaneously while search
ySupport intercom
yPerform almost all functions via client software, including live
view the video of any channel, view device status, set system
parameters, PTZ control, remote search of recording file,
playback and download, system upgrade, reboot and shutdown
yUpdate software through USB
yPower off protection, self-recovery while powering on
