Infinity Total Solutions TSS-SAT1200 Manual de usuario

TSS-SAT1200

Owner’sGuide

TOTAL SPEAKER SOLUTIONS

TSS-SAT1200 OM 7/27/06 4:44 PM Page 1

2TSS-SAT1200

3Introduction

3Included

3Planning Your System

3Placement

4Wall-Mounting the Satellites

6Connections

6Maintenance and Service

7Specifications

Table of Contents

TSS-SAT1200 OWNER’SGUIDE

TSS-SAT1200 OM 7/27/06 4:44 PM Page 2

TSS-SAT1200

InfinityTotal Solutions™

Infinity Total Solutions continues Infinity’s longstanding commitment

to accurate sound reproduction.Our high-quality drivers, precision

dividing networks and rigid, well-braced enclosures combine to deliver

uncompromised performance in any multichannel home theater system.

Inaddition, the TSS-SAT1200 is magnetically shielded for safe place-

ment adjacent to a television.

INCLUDED

(1) Speaker (1) Adjustable (1) Fixed wall

wall bracket bracket

INTRODUCTION

Before deciding where to best place your speakers, survey your room and

study Figures 1 and 2.

Figure 1.This overhead view shows a typical home theater plan.

Left/right rear channels are for a 7-channel system. Center rear

channel is for a 6-channel system.

Figure2.This figureshows an alternate layout, which may be

more suitable for some rooms. Left/right rear channels are

for a 7-channel system. Center rear channel is for a 6-channel system.

Left Rear

Channel

Left

Surround

Channel

Right

Surround

Channel

Right Rear

Channel

Center Rear

Channel

Left Front

Channel

Subwoofer Right Front

Channel

Center

Channel

Couch

Left Rear

Channel

Left

Surround

Channel

Right

Surround

Channel

Right Rear

Channel

Center Rear

Channel

Left Front

Channel

Subwoofer

Right Front

Channel

Center

Channel

PLANNING YOUR SYSTEM

PLACEMENT

NOTE: The TSS-SAT1200 can be placed directly on a shelf,

ormounted on a wall using the included wall brackets.

As Left and Right Front Channels

For left and right front channels, place one satellite to the left

and another to the right of the television, as shown in Figure 1.

Since the speakers are magnetically shielded, you can place

them very close to the TV without worrying about the magnetic

field distorting the picture.

As Surround Channels

For left and right surround channels, place one speaker on the

left and another on the right, to the side of or slightly behind the

listening area.The surround speakers should be mounted at a

height of between 5 ft. (1.5m) and 7 ft. (2m).

In 6- or 7-channel configurations, place the rear channel(s)

behind the listening position, as shown in Figures 1 and 2.

NOTE: An Infinity powered subwoofer will add impact and realism

to both music and film soundtracks. Contact your Infinity dealer

for recommendations on subwoofer models for your application.

Mounting on Floor Stands

An optional floor stand is available,should you prefer to place

your TSS-SAT1200 satellites on the floor; see your dealer or visit

www.infinitysystems.com for more information.

keyhole on the back of the speaker to the screwhead on the

TSS-SAT1200 OM 7/27/06 4:44 PM Page 3

4TSS-SAT1200

WALL-MOUNTING THE SATELLITES

TSS-SAT1200 satellites are designed to also be mounted on the

wall.There is a fixed-mount wall bracket and an adjustable wall

bracket provided for each satellite.Each speaker bracket will

require up to four 1-1/2"#10

wood screws; each screw should

be fastened to a wall stud. If a wall stud is unavailable, install an

anchor appropriate for a 1-1/2"

#10 screw.

IMPORTANT SAFETY NOTE: The customer is solely responsible

for proper selection of mounting hardware not included with the

speakers, and for proper assembly and installation of the wall

brackets, including but not limited to the selection of appropriate

weight-bearing supports and proper use of the bracket. Infinity

disclaims any liability for the selection of mounting hardware and/or

bracket installation.Be sure to follow these bracket assembly and

installation instructions carefully. If you have any questions or

doubts about your ability to correctly wall-mount the speakers,

consult with your authorized Infinity dealer or custom installer.

Fixed-Mount Wall Bracket

Step 1. Remove the rear foot by loosening the screw on the

bottom of the satellite.ole

Step 2. Mark the positions on the wall where you would like to

place the mounting screws.

Step 3. Attach the back plate of the bracket to the wall using

three screws (not included).

Step 4. Attach the front plate

(with the spring tab) of the bracket to

the satellite, using the provided screws.

Step 5. Slide the satellite speaker

with attached bracket front plate

onto the back plate of the

bracket until the tab locks

into place.

To removethe speaker from

the wall, simply push in

the locking tab and slide

the speaker up.

back of the speaker to the screwhead on the wall. Once

positioned properly, the speaker should slide down slightly and

become secure.

Adjustable Wall Bracket

Step 1. Remove the rear foot by loosening the screw on the

bottom of the satellite.

Step 2. Mark the positions on the wall where you would like to

place the mounting screws.

Step 3. Place bracket against the wall and fasten four 1-1/2"

#10 wood screws through the bracket’s screw holes into the

wall. If a wall stud is not available, use an appropriate anchor.

Step 4. Unscrew round collar (C) from bracket (A).

TSS-SAT1200 OM 7/27/06 4:44 PM Page 4

TSS-SAT1200

Step 5. Screw the ball and shaft assembly (B) to the lower 1/4"-

20insert on the rear of the satellite, until it is fully seated. Back

out 1/2 of a turn and tighten the nut against the speaker. Securely

tightening this nut against the speaker enclosure is very important;

otherwise, performing Step 7 may dislodge the threaded

insert on

the speaker enclosure, rendering it unusable.

Step 6. Attach speaker wire as shown on page 7.

Step 7. Drop round collar (C) over ball and shaft assembly (B)

that is mounted to the speaker with the finished side of the collar

facing the rear of the speaker.

Step 8. Carefully push the ball straight into the socket mounted

on the wall, angle the speaker as desired and tighten the collar

using the enclosed metal bar.

Figure 3. Bracket on wall.

TSS-SAT1200 OM 7/27/06 4:44 PM Page 5

6TSS-SAT1200

CONNECTIONS

After placing the speakers, you are ready to connect your system.

First, turn off all audio system power. Use high-quality speaker

wire to make your connections; #18-gauge speaker wire with

polarity coding is recommended. For longer distances, #16-

gauge or heavier wire is recommended.The side of the wire with

aridge or other coding is usually considered positive polarity

(i.e., +). Also, consult the owner’s manuals that were included

with your amplifier or receiver to confirm connection procedures.

Observe polarities when making speaker connections,as shown in

Figure 4. Connect each + terminal on the back of the amplifier or

receiver to the respective + (red) terminal on each speaker.

Connect the – (black) terminals in the same way.

Important!

Do not reverse polarities (i.e., + to –, or – to +) when making

connections. Doing so will cause poor imaging and diminished

bass response. Be certain that positive and negative wire strands

are completely isolated to avoid short circuits that may damage

your equipment.

MAINTENANCE AND SERVICE

The TSS-SAT1200 enclosure may be cleaned using a soft cloth

toremove fingerprints or to wipe off dust.

All wiring connections should be inspected and cleaned or

remade periodically.The frequency of maintenance depends on

the metals involved in the connections, atmospheric conditions

and other factors, but once per year is the minimum.

If a problem occurs,make sure that all connections are properly

made and clean. If a problem exists in one loudspeaker, reverse

the connection wires to the left and right system. If the problem

remains in the same speaker, then the fault is with the loud-

speaker. If the problem appears in the opposite speaker, the

cause is in another component or cable. In the event that your

TSS-SAT1200 ever needs service, contact your local Infinity

dealer or distributor, or visit www.infinitysystems.com for a

service center near you.

Figure4. Wiring diagram shows polarity connections

for one channel of a home theater system (rear foot

not shown, for the sake of clarity).

TSS-SAT1200 OM 7/27/06 4:44 PM Page 6

TSS-SAT1200

Frequency Range: 120Hz – 30,000Hz (±3dB)

Recommended

Amplifier Power Range: 10–125 Watts

Sensitivity: 89dB

(2.83V @ 1 meter)

Nominal Impedance: 8Ω

Crossover Frequency: 3.5kHz; 24dB/octave

Midrange Driver(s): Dual 3-1/2" (64mm) MMD®magnetically shielded

High-Frequency Driver: 3/4" (19mm) MMD magnetically shielded

Dimensions (H x W x D): 12-15/16" x 3-15/16" x 3"

(329mm x 100mm x 76mm)

Weight: 3.9 lb (1.8kg)

Infinity continually strives to update and improve existing products, as well as

create newones.The specifications and construction details in this and related

Infinity publications are therefore subject to change without notice.

SPECIFICATIONS

Laurent Rault

Harman Consumer Group International

Château du Loir, France 8/06

Declaration of Conformity

We, Harman Consumer Group International

2, route de Tours

72500 Château du Loir

France

declare in own responsibility that the product described

in this owner’s manual is in compliance with technical

standards:

EN 61000-6-3:2001

EN 61000-6-1:2001

TSS-SAT1200 OM 7/27/06 4:44 PM Page 7

Infinity Systems,250 Crossways Park Drive,Woodbury, NY 11797 USA www.infinitysystems.com

Infinity, Harman International and MMD are trademarks of Harman International Industries,Incorporated, registered in the United States and/or other countries.

Total Solutions is a trademark of Harman International Industries,Incorporated.

Part No. 406-000-05483-E 8/06

TSS-SAT1200 OM 7/27/06 4:44 PM Page b

Tabla de contenidos

Otros manuales de Oradores de Infinity

Infinity

Infinity Overture 1 Manual de usuario

Infinity

Infinity IRS Sigma Manual de usuario

Infinity

Infinity Reference 1021t Manual de usuario

Infinity

Infinity ENTRA POINT FIVE HTS Manual de usuario

Infinity

Infinity ENTRA POINT FIVE HTS Manual de usuario

Infinity

Infinity CLASSIA C255ES Manual de usuario

Infinity

Infinity PRIMUS P142 Manual de usuario

Infinity

Infinity reference series Manual de usuario

Infinity

Infinity Kappa Marine Speaker 62m Manual de usuario

Infinity

Infinity IRS Sigma Manual de usuario

Infinity

Infinity Primus Theater Pack Manual de usuario

Infinity

Infinity Prelude MTS Center Manual de usuario

Infinity

Infinity PRELUDE FORTY Manual de usuario

Infinity

Infinity ERS 110DT Manual de usuario

Infinity

Infinity Omega Manual de usuario

Infinity

Infinity Compositions Overture OVTR 2 Manual de usuario

Infinity

Infinity Sigma Manual de usuario

Infinity

Infinity Intermezzo 3.5c Manual de usuario

Infinity

Infinity Total Solutions TSS-CENTER4000 Manual de usuario

Infinity

Infinity KAPPA 62ix Manual de usuario

Infinity

Infinity Classia C255ES Instrucciones de funcionamiento

Infinity

Infinity Reference R152 Manual de usuario

Infinity

Infinity FUZE Pint Manual de usuario

Infinity

Infinity SAT-750 Manual de usuario

Manuales populares de Oradores de otras marcas

argon audio

argon audio IE20 Manual de usuario

Denon

Denon SC-N7 Manual de usuario

Gemline

Gemline Ace 3952 Manual de usuario

Focal

Focal ON WALL 300 Manual de instrucciones

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manual de usuario

SoundLogic

SoundLogic BCCS-6/6395 Manual de usuario

Peavey

Peavey DTH 218 Manual de usuario

Avantree

Avantree Pluto Air Manual de usuario

Morel

Morel Integra Series INTEGRA OVATION 4 Manual de usuario

Oppo

Oppo SONICA Manual de usuario

Bose

Bose SoundLink Wireless Music System Manual de usuario

Rocksteady

Rocksteady Stadium Manual de usuario

Bowers & Wilkins

Bowers & Wilkins 4 Manual de usuario

Sonance

Sonance SONOS OUTDOOR Series Manual de usuario

Electro-Voice

Electro-Voice EVID FM4.2 Manual de usuario

Pioneer

Pioneer XW-HTD630 Manual de usuario

Onn

Onn BWA16AA002 Manual de usuario

HP GL313AA - USB Speakers PC Multimedia Manual de usuario
