Owner’s Manual

Flat-Panel Loudspeaker

FPS-1000

BOUT

HIS

RODUCT

...

MPORTANT

OSITION

ITHIN

A R

OOM

ILL

TRONGLY

NFLUENCE

ERFORMANCE

...

INTRODUCTION

The Infinity FPS-1000 has been designed to offer the look of a custom-

designed, in-wall speaker system in an easy-to-install on-wall product.

Installation simply entails properly mounting your FPS-1000 to any flat wall

surface.

Note that the FPS-1000 must be mounted using proper anchoring hardware

(not included). You should ask an installation professional for help if you’re

unsure about the safety of your mounting location.

UNPACKING THE SPEAKERS

Check your FPS-1000’s carefully. If they have been damaged in transit, report

the damage immediately by calling your dealer and/or the trucking firm that

delivered them.

POSITIONING

Since the location of the FPS-1000’s will affect performance, it is essential you

read this section very carefully prior to mounting the speakers. Should you

have any questions relating to their installation, it’s advisable that you call either

your dealer or Infinity’s Customer Service Department for advice.

Positioning tips:

When possible, mount your FPS-1000’s where there is an unobstructed view of

them from your listening area.

For the best possible stereo-sound presentation, mount your FPS-1000’s on the

same wall, about 6–8 feet apart.

Position the high-frequency drivers (tweeters) as close to ear level as

possible. When this is not possible, you can improve the performance of your

FPS-1000’s by aiming the rotatable tweeters toward your main listening area.

◆FPS-1000 – Owner’s Manual

Figure 1.

NOTE: This

wire is flat

and about 5/8" wide.

Figure 2.

HOOKUP

Your FPS-1000’s are packaged with special flat speaker wire. When connecting

your FPS-1000’s with this wire, make sure to use correct polarity for the

+ and – connections. We suggest using the ribbed conductor for the positive

terminal. See Figure 1.

The flat speaker wire allows you to neatly run the wire down/up the wall to

your speakers (see Figure 2). The wires can be painted to better blend in with

your decor.

MOUNTING FPS-1000’S

Your FPS-1000’s come with four keyhole mounting locations at the rear corners

of the enclosures.

NOTE: The customer is responsible for the correct selection and use of mounting

hardware (available through hardware stores) that is necessary for the safe and

proper wall mounting of the speakers.

FRONT OF FPS-1000

–

+–

RIGHTLEFT

Receiver/Amplifier

– L + – R +

Ribbed conductor

REAR OF FPS-1000

–

+–

RIGHTLEFT

Receiver/Amplifier

– L + – R +

Ribbed conductor

FPS-1000 – Owner’s Manual ◆

SPECIFICATIONS

ERFORMANCE

ATA

RIVE

NITS

INISH

IMENSIONS

EIGHT

FPS-1000

Recommended Amplifier Power: 15 ~ 75W

Frequency Response (±3dB): 75 ~ 20,000Hz

Low-Frequency: 5-1/4" with 5-1/4" passive radiator

High-Frequency: 1" dome (rotating)

Crossover Frequency: 3,800Hz

Nominal Impedance: 6 Ohms

Sensitivity (2.83V @ 1 m): 88dB

Enclosure Finish: White

Height, Width, Depth: 25-1/4 x 11-1/2 x 1-1/2"

641 x 292 x 38mm

12 lbs (5.5 kg)

Declaration of Conformity

We, Infinity Systems A/S

Kongevejen 194B

DK-3460 Birkerød

DENMARK

declare in own responsibility, that the product described

in this owner’s manual is in compliance with technical

standards:

EN 50081-1:1992

EN 50082-1:1992

Steen Michaelsen

Infinity Systems A/S

Birkerød. DENMARK. 10/98

Infinity continually strives to update and improve existing products, as well as create new ones.

The specifications and construction details in this and related Infinity publications are therefore

subject to change without notice.

(800) 553-3332 (USA Only) Fax: (516) 682-3523

www.infinitysystems.com

Infinity is a registered trademark of Infinity Systems, Inc. Part No. FPS1000OM
