Infinity PERFECT T Manual de usuario

Thank you

for choosing the Kappa PerfectT.

The PerfectT has been designed to provide smooth

high-frequency reproduction, high power handling

and ease of installation.

This manual includes information that will make your

installation as simple and trouble-free as possible.

Please read this manual thoroughly before you begin

your installation. Don’t forget to send in your warranty

registration card, and keep your sales receipt some-

where safe in case you need warranty service.

perfectT

1"component tweeter

instructions

IMPORTANT

Installation of automotive stereo compo-

nents can require extensive experience per-

forming a variety of mechanical and electri-

cal procedures. Although these instructions

explain how to install a Kappa PerfectT

component system in a general sense, they

do not show the exact installation method

for your particular car. If you feel you may

not have the necessary tools or experience,

ask your authorized Infinity car-audio dealer

about professional installation options.

WARNING

Playing loud music in an automobile can

permanently damage your hearing as well

as hinder your ability to hear traffic. We

recommend listening at a low volume while

driving. Infinity accepts no liability for hear-

ing loss, bodily injury or property damage

resulting from use or misuse of this product.

SPEAKER PLACEMENT

Figures 1 & 2 show possible speaker

placements in the order of more desirable

to less desirable. Kick-panel mounting will

provide the best staging and imaging in

most vehicles.

A NOTE ABOUT CROSSOVER APPLICATION

Passive crossover design involves precise

circuit design and component selection. A

well-designed crossover circuit provides an

electrical response intended to be combined

with the electrical properties of the speaker

to provide a particular acoustic response.

The crossover included with the PerfectT

has been optimized to provide flat response

when used with the PerfectT. Do not use the

PerfectT with a passive crossover intended

for use with another tweeter, or connect

more than one tweeter to the crossover

provided with the PerfectT.

TWEETER INSTALLATION

TWEETER

and

WOOFER

on kick panel

TWEETER

on kick panel

WOOFER

in factory-

door location

Figure 1.

Mounting the woofer and tweeter in

the kick panel

Figure 2.

Mounting the woofer in the door and

the tweeter in the kick panel

Figure 3.

Mounting the tweeter in the doors

–

Figure 4.

Surface-mounting the tweeter Figure 5.

Flush-mounting the tweeter

- 2 -

(+) BIG LUG & RED WIRE

(-) SMALL LUG & BLK WIRE

(+) RED WIRE

(-) BLK WIRE

- 3 -

SPECIFICATIONS

System

Frequency response: 3.5kHz –21kHz, ±3dB

Power handling: 100W RMS, 400W Peak

(with HPF provided)

Nominal impedance: 4 Ohms

Sensitivity: 90dB

Crossover frequency: 3.5kHz

Thiele and Small Parameters

Revc: 3.31 Ohms

Levc: .02mH

Sd: .0005M3

Vas: .0016 liters

Cms: 44 uM/N

Mms: .3064g

Mmd: .3g

Fs: 1370.65Hz

Qms: 5.4

Qes: 2.19

Qts: 1.56

Voice-coil diameter: 1" (25.4mm)

Mounting depth: 1-3/16" (31mm)

Cut-out diameter: 1-3/4" (45mm)

GENERAL CARE

The loudspeaker grilles may be cleaned with

a damp cloth. Do not use any cleaners or

solvents on the grilles or the speaker cones.

Infinity Systems, Inc. •250 Crossways Park Drive, Woodbury, NY 11797 USA

(800) 553-3332 •FAX (516) 682-3523 •www.infinitysystems.com

DECLARATION OF CONFORMITY

We, Harman Consumer International

2, route de Tours

72500 Chateau-du-Loir

France

Lutz Uphoff

Harman Consumer International

France. 2/00

declare in own responsibility, that the product described in this owner’s manual is in compliance with technical standards:

EN 50081-1:1992

EN 50082-1:1992
