Induction Dynamics SolidDrive SD1 Desktop Manual de usuario











Experience Audio Perfection

SolidDrive SD1 is a cutting-edge, innovative, power-

ful sound transducer that transmits acoustical energy

through almost any solid surface. The entire surface

with which SolidDrive comes in contact becomes

a speaker, delivering high-quality sound and the

frequency response of conventional diaphragm

speakers.

SolidDrive works with rigid surfaces including glass,

drywall, wood, ceramics, laminates, composites and

metal. Because SolidDrive utilizes existing structures

in the room, it is ideal for residential and com-

mercial applications. Experience sound in ways you

never thought possible.



SolidDrive utilizes patent-pending technology

with very high-powered neodymium magnets and

dual symmetrically opposed motors to convert

audio signals into powerful vibrations. Those

vibrations are transferred into solid surfaces

through direct contact. High-quality, full-range

sound is then radiated from the entire surface with

a frequency response of 60 Hz to 15 kHz.

SolidDrive delivers excellent sound to problem

areas, transforming walls, ceilings, floors, win-

dows, mirrors, counter tops, conference room

tables and other furniture into high-quality sound

sources. Sound generated from a large surface

area immerses the listener in omni directional

sound, producing a stunning and impressive

experience.





For portable use on top of any

horizontal surface including glass,

granite, metal, wood, ceramics,

laminates and composites. Special

silicone rubber pad “grips” any

non-porous surface.



For use vertically or horizontally on

glass or other smooth, non-porous

materials. The SD1g is attached with

a double-sided adhesive disc.



For use attached to drywall and similar

surfaces for "in-wall" and "in-ceiling"

applications. The SD1 includes our

dual cantilever mounting bracket.







For use attached to wood and other

porous surfaces, such as under wood

desks and other furniture.

Experience Audio Perfection





The SolidDrive mounts “in-wall” and “in-ceiling”

by attaching directly to the drywall with a patent-

pending balanced cantilever spring bracket. The

bracket spans the studs, providing strength, stability

and vibration-free operation.

SolidDrive delivers sound to problem areas trans-

forming walls, ceilings, floors, windows, mirrors,

counter tops, conference room tables and other

furniture into high-quality sound sources. Perfect for

homes, retail stores, restaurants or anywhere audio is

wanted but without visible speakers.





The surface material plays a key role in the system’s

sound quality. To ensure an optimal listening experi-

ence, the SolidDrive SD1 system is equalized with

the SolidDrive Passive Equalization Module. One EQ

module is used with each SolidDrive. EQ Modules

are available for drywall, wood and glass surfaces.

SolidDrive SD1 drywall installation during new construction

View from behind





A truly hidden speaker, SolidDrive installs directly behind

walls, in ceilings, under floors and on most all other solid

surfaces. The unit turns an entire structure’s surface into

a high-quality sound source while remaining completely

hidden from view.





Efficiency is very important for inside-wall applications

due to potential heat build up. The highly efficient

SolidDrive answers this need with its ability to generate

sound from an entire flat surface with very little power.

In fact, SolidDrive can generate sound from solid

surfaces by utilizing only 5 to 20 watts. SolidDrive is

thermally protected, so can also be used in high-output

applications with power levels up to 100 watts.

The SD1 operates in a virtually friction-free environment

with no parts that will wear or require lubrication. Parts

subject to fatigue are fabricated from high strength materials

and engineered for infinite life. SolidDrive carries a 7-year

warranty.



• Hometheaters

 • Distributedaudio

 • Restaurants

 • Retailstores

 • Hotels

 • Conferenceroomtables

 • Digitalsignage

 • Storefrontwindows

 • Kiosks



Passive EQ Module

SolidDrive and SolidDrive subwoofers carry a seven-year warranty.

60 -15,000 Hz Nominal w/o EQ – depends on substrate

100 Watts, with 100 Hz 12 dB / oct high-pass

25 Watts

2.30" / 58 mm

3.50" / 89 mm

2.13” / 54 mm

2.05" / 51 mm

10.50" W x 9.00" H x 3.25" D / 266.70 mm W x 228.60 mm H x 82.55 mm D

1.2 lb / 0.54 kg per drive











SD1&SD1sm

SD1g&SD1 Desktop









Induction Dynamics and SolidDrive are members of MSE Audio Group.


