Dishwasher

Installation and use

DG 6145

1GB

Safety Is a Good Habit to Get Into

NOTICE

Carefully read the instructions contained in this manual, as

they provide important information which is essential to

safe and proper installation, use and maintenance of the

appliance.

This appliance complies with the following

EEC directives:

- 73/23/EEC of 19/02/73 (Low Voltage) and subsequent

modifications;

- 89/336/EEC of 03/05/89 (Electromagnetic

Compatibility) and subsequent modifications.

1.Carefully dispose of the packing material.

2.After removing the packing, check to make sure that the

appliance is not damaged. If in doubt, contact a qualified

professional.

3.The dishwasher must only be used by adults for the

washing of household dishes and cooking utensils.

4.Fundamental rules to follow when using the appliance:

- Never touch the dishwasher when barefoot or with wet

hands or feet;

- We discourage the use of extension cords and multiple

sockets;

Close-up View (control panel)

- During installation, the power supply cord must not be

excessively or dangerously bent or flattened;

- If the appliance is not operating properly or maintenance

must be performed, disconnect the appliance from the

power supply.

5.Keep detergents out of the reach of children, who must

also be kept away from the dishwasher when it is open.

6.This appliance cannot be installed outdoors, not even if

the area in which it is installed is covered by a roof; it is also

verydangeroustoleaveitexposedtotherainandelements.

7.Do not touch the heating element during or after a wash

cycle.

8.Do not lean or sit on the door when it is open, as this

could overturn the dishwasher.

9.If the appliance malfunctions, turn off water supply to

theapplianceand disconnect the plug fromthewallsocket.

Then,consultthesectionentitled,"Troubleshooting." If you

cannot resolve the problem, contact a service centre.

10.Only specialised personnel are authorised to make

repairs.

11.Appliances which are no longer being used must be

made inoperable by cutting the power supply cord and

removing the door lock.

ON - OFF Button

ON - OFF Light

Handle For Opening Door

Knob For Selecting Cycles

Close-up View (Interior)

Upper Rack

Top Sprayer Arm

Rack Height Adjustor

Lower Rack

Bottom Sprayer Arm

Salt Container Cap

Washing Filter

Detergent and Rinse Aid Dispenser

Technical characteristics

Width cm. 44,5

Depth cm. 60

Height cm. 85

Capacity 8 standard place settings

Mains water pressure 0,2 ÷10 bar (20 Kpa÷ 1 MPa)

Power voltage See data plate

Total absorber power See data plate

Fuse See data plate

3GB

Salt...

Salt

The hardness of the water varies from place to place. If

hard water is used in the dishwasher, deposits will form on

the dishes and utensils.

The appliance is equipped with a special softener that uses

a salt specifically designed to eliminate lime and minerals

from the water.

Loading the Salt into the Softener

Always use salt intended for use with dishwashers.

The salt container is

located beneath the

lowerrackandshouldbe

filled as follows:

1.Removethelowerrack

and then unscrew and

remove the cap from the

salt container;

2. If you are filling the

container for the first

time, fill it with water;

3. Place the end of the

funnel(supplied)intothe

hole and introduce about 2 kg of salt. It is normal for a

small amount of water to come out of the salt container.

4. Carefully screw the cap back on.

Thesaltcontainershouldbefilledafteraboutevery30wash

cycles.

To prevent the formation of rust, load the salt just before

beginning a wash cycle.

Adjusting Salt Consumption

The dishwasher is designed to allow for adjusting the

amountofsaltconsumedbasedontheharness of the water

used. This is intended to

optimizeandcustomizethelevel

ofsaltconsumptionsothatitre-

mains at a minimum.

To adjust salt consumption,

proceed as follows:

1)Unscrewthecapfrom the salt

container.

2) There is a ring on the

container with an arrow on it

(see figure to the side), if

necessary,rotatetheringintheanticlockwisedirectionfrom

the "_" setting towards the "+" sign, based on the hard-

ness of the water being used.

Itisrecommendedthatadjustmentsbemadeinaccordance

with the following schema:

Water Hardness

Clarke

degrees °dH mmol/l Selector

position

Salt

consu-

mption

(grams/-

cycle)

Auto-

nomy

(cycle-

s\2kg)

0÷ 14 0 ÷17 0 ÷ 1,7 / 0 /

14÷36 18 ÷44 1,8 ÷4,4 -20 60

36 ÷ 71 45 ÷ 89 4,5 ÷8,9 MED 40 40

>71 > 89 > 8,9 +60 25

Detergent

Detergent specifically intended for use with dishwashers

must be used. The dispenser must be refilled before the

start of each wash cycle following the instructions provided

in the "Wash Cycle Table." The detergent dispenser is

located on the inside panel of the door.

Loading the Detergent

To open the "A" cover on the dispenser, press the "B"

button. The detergent for the wash cycle should be poured

into the "C" compartment.

After the detergent has been placed in the dispenser, close

the cover and press down until it clicks in place.

Notice: To facilitate closing the cover, remove any

excess detergent on the edges of the dispenser.

Rinse Aid

This product makes dishes sparkle and helps them to dry

without spotting. The dispenser is located on the inside

panel of the door and should be filled after every 80 wash

cycles (or when the rinse aid indicator light comes on for

those models with this feature). .

Loading the Rinse Aid

Toopenthedispenser, turnthe"C"cap in theanti-clockwise

direction and then pour in the rinse aid, making sure not to

overfill. The amount of rinse aid used for each cycle can be

regulatedby turningthe"F"doseadjustor, located beneath

the "C" cap, with a screwdriver. There are 6 different

settings; the normal dosage setting is 2.

Important:

Proper dosage of the rinse aid improves drying.

If drops of water remain on the dishes or spotting occurs,

the dosage adjustor should be turned to a higher setting.

If the dishes have white streaks, turn the dosage adjustor

to a lower setting.

Detergent and Rinse Aid....

5GB

Before placing the dishes in the dishwasher, remove the

larger food particles to prevent the filter from becoming

clogged, which results in reduced performance.

Ifthe pots and pans have baked-on foodthat is extremely

hard to remove, we recommend that they be allowed to

soak before they are washed. This will eliminate the need

for extra wash cycles.

Pull out the racks to facilitate loading the dishwasher.

How to Use the Lower Rack

We recommend that you place the most difficult to clean

items on the bottom rack: pots, pans, lids, serving dishes

and bowls, as shown in the figure to the right.

It is preferable to place serving dishes and lids on the

sides of the racks in order to avoid blocking the rotation

of the top spray arm.

- Pots, serving bowls, etc. must always be placed top

down.

- Deep pots should be slanted to allow the water to flow

out.

- Silverware should be placed in the silverware basket

(see figure A) with the handles at the bottom; if the rack

has side baskets the spoons should be loaded individually

in the appropriate slots. Especially long utensils should be

placed in the horizontal position at the front of the upper

rack.

How to use the top rack …

The top rack is designed to hold delicate and light items,

such as glasses, tea and coffee cups, and saucers, as well

asplates,shallowservingbowls, and pans (as long as they

are not too dirty).

- Place these types of items so that they are not moved

around by the spray of water.

How to adjust the top rack ...

The top rack can be adjusted using the two rack heights

(top and bottom). To adjust the rack, open up the tabs

that lock the guides and pull out the rack. Arrange the

rack with the back wheels in either the top or bottom

position and then insert it along the guides until the front

wheels are on as well. Close the tabs to lock the rack in

place (see Fig. F).

Loading the Dishwasher

Load for 8 Standard Settings (For IEC tests : top

rack at top position)

Bottom Rack Upper Rack

Fig.F

Fig. A

Turning on the Appliance

Starting a wash cycle....

1. Make sure that the plug for the appliance is inserted into

the wall socket.

2. Make sure that the water supply is turned on to full

pressure.

3. Load the dishwasher (see the section entitled, "Loading

the Dishwasher").

4. Pour in the detergent (see the section entitled, "Salt,

Detergent and Rinse Aid").

5. Turn the knob located on the right of the control panel in

the clockwise direction until the number or symbol for the

cycle setting is aligned with the reference mark (see the

section entitled, "Wash Cycle Table").

6. Press the ON-OFF botton, and the ON-OFF light will turn

on. At this point, the wash cycle will begin.

Cancelling or modifying a wash cycle setting...

Premise: A cycle that is underway can only be modified if it has

only been running for a short time. Otherwise, the detergent

may have already been used, and the appliance may have already

drained the wash water. If this is the case, the detergent dispenser

must be refilled (see the paragraph entitled, "Loading the

Detergent").

Press the ON-OFF button, and the ON light will turn off.

Rotate the knob in the clockwise direction to the desired

cycle setting (see the section entitled, "Starting a wash

cycle...").Then,turnthedishwasherbackon using the ON-

OFF button.

If you forget to load some of the dishes...

The wash cycle can be interrupted by pressing the ON-OFF

button. You can then load additional dishes and turn the

appliance back on. The cycle will start where it left off.

At the end of the wash cycle...

When the knob stops turning and is aligned with a STOP

mark (see figure), the cycle has finished. Turn off the

applianceusing theON-OFFbutton, turnoffthe watersupply

and open the door of the dishwasher.

Wait a few minutes before unloading the dishwasher to

avoid handling the dishes and utensils while they are still

hot and more susceptible to breakage. They will also dry

better.

STOP

7GB

Wash Cycle Table

Cycle

Selection

Information

De s cription of

Cycle

Detergent Rinse Aid

1) Heavy Duty

Ve r y d ir t y

dishes, pots and

pans (not to be

used with

delicate items).

Pre-wash with hot water

(45°C).

Extended wash at 65°C.

Rinse with cold water.

Rinse with hot water at 70°C.

Drying.

20 gr. *

2) Normal Wash

(IEC-EN 50242)

Normally dirty

dishes, pots and

pans. Standard

daily cycle.

Pre-wash with cold water.

Extended wash a 65°C.

Rinse with cold water.

Rinse with hot water at 70°C.

Drying.

20 gr. *

3) Rapid Wash

Economic, fast

cycle to be used

to on not very

dirty dishes right

after they are

used. No drying

cycle.

Short wash at 65°C.

Cold rinse. 10 gr.

4) Soak

Pre-wash of

dishes, pots and

pans while

waiting for the

loa d to be

completed after

the subsequent

meal.

Short cold wash to prevent

food residue from drying on the

dishes.

Energy Saving Tips

- It is important to try and run the dishwasher when it is

fully loaded in order to save on energy. In order to prevent

odors from forming and food from caking onto the dishes,

you can run the hold cycle.

- Choose the right wash cycle: the choice of cycle depends

on the type of dishware, cookware and utensils being

washed and how dirty they are.

- Use the right amount of detergent: if you use too much

detergent, the result will not be cleaner dishes, but, rather,

a greater negative impact on the environment.

- There is no utility in rinsing dishes, cookware and utensils

before placing them in the dishwasher.

How to Keep Your Dishwasher in Shape

After Every Wash

Aftereverywash, turn offthe water supply to theappliance

and leave the door slightly ajar so that moisture and odors

are not trapped inside.

Remove the Plug

Beforecleaning or performing maintenance, always remove

the plug from the socket. Do not run risks.

No Solvents or Abrasive Cleaning Products

To clean the exterior and rubber parts of the dishwasher,

do not use solvents or abrasive cleaning products. Rather,

use only a cloth and warm soapy water.

To remove spots or stains from the surface of the interior,

use a cloth dampened with water and a little white vinegar,

or a cleaning product made specifically for dishwashers.

When You Go on Holiday

When you go on holiday, it is recommended that you run a

wash cycle with the dishwasher empty and then remove

the plug from the socket, turn off the water supply and

leave the door of the appliance slightly ajar. This will help

the seals last longer and prevent odors from forming within

the appliance.

Moving the Appliance

If the appliance must be moved, try to keep it in the vertical

position. If absolutely necessary, it can be positioned on its

back.

Seals

One of the factors that cause odors to form in the

dishwasheris food that remainstrappedinthe seals. Periodic

cleaning with a damp sponge will prevent this from

occuring.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Lavavajillas de Indesit

Indesit

Indesit Hotpoint HCD662UK Instrucciones de funcionamiento e instalación

Indesit

Indesit DPG15WH Manual de usuario

Indesit

Indesit LFD 11M121 Manual de usuario

Indesit

Indesit FDEF31111 Instrucciones de funcionamiento e instalación

Indesit

Indesit DFC 2B+19 AC Manual de instalación y operación

Indesit

Indesit DFP 27T94 Manual de usuario

Indesit

Indesit DFO 3T133 A F X Manual de usuario

Indesit

Indesit DIF 16B1 Manual de usuario

Indesit

Indesit DIO3T131FEUK Manual de instalación y operación

Indesit

Indesit DFG 262 Manual de usuario

Indesit

Indesit DIFP 68T1 Manual de usuario

Indesit

Indesit DFP2631M Manual de usuario

Indesit

Indesit Idl 507 Manual de usuario

Indesit

Indesit DFG 261 Manual de usuario

Indesit

Indesit DIFP 18B1 Manual de usuario

Indesit

Indesit DIF 04 Manual de usuario

Indesit

Indesit DISR 16M19 Manual de usuario

Indesit

Indesit DSG 2631 Manual de usuario

Indesit

Indesit IDF 125 Manual de usuario

Indesit

Indesit DSR 57M96 Manual de usuario

Indesit

Indesit DSR 57M17 Manual de usuario

Indesit

Indesit DFG 04 Manual de usuario

Indesit

Indesit DISR 14B1 Manual de usuario

Indesit

Indesit ICD 661 UK Instrucciones de funcionamiento e instalación

Manuales populares de Lavavajillas de otras marcas

Electrolux

Electrolux ESI5211LOX Manual de usuario

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

GE GLD8000 Series Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario
