Inalto IUM75 Manual de usuario

MODEL/IUM75 WWW.INALTO.HOUSE

QUICK START GUIDE

75cm Undermount

Rangehood

FEATURES

Aluminium grease ﬁlters,

750m/hr extraction, Push button controls,

3 speeds, 2 × LED lights

QUICK START GUIDE

SUPPORT

Telephone: 1300 11 4357

Email: support@residentiagroup.com.au

DETAILS

Product Size (W, D, H):

750mm x 280mm x 283mm

Congratulations on your new InAlto

75cm Undermount Rangehood!

MODEL/IUM75 WWW.INALTO.HOUSE

INSTALLATION

Please refer to the dimensions of your rangehood shown in the diagram below.

When positioning the rangehood for installation and use, we advise that the rangehood

is mounted at a height of between 600—800mm above the cooking surface for safety and

performance of your rangehood.

Gas cooktops must have a minimum of height of 650mm from the burner to the underside of

the rangehood.

Electric cooktops must have a minimum height of 600mm from the cooktop surface to the

underside of the rangehood.

For a complete

guide, refer to

your user manual

pages 8—11.

Controls

Off button

Used for turning off the fan.

Low Speed button

This speed is used for basic ventilation on the kitchen. It is suitable

for simmering and cooking which does not make much steam.

Medium Speed button

This is ideal for standard cooking operation.

High Speed button

When a high density of smoke or steam is produced, use this speed for the

highest effective ventilation.

Light button

Pressing this turns the lighting on or off.

OPERATING YOUR RANGEHOOD

Your Esatto Canopy rangehood features push button controls with three speed

levels of extraction.

* Note: If Low / Medium / High speed buttons are press at the same time,

the unit will only operate at the highest speed.

THE CONTROLS

Your Flat Glass Rangehood Controls

1Stop

2Low Fan Speed

3Medium Fan Speed

4High Fan Speed

5Light

For a complete guide on operating your

rangehood refer to user manual on page 12.

1 2 3 4 5

283

255

280

244

520 / 750* / 900**

480 / 710* / 860**
