ImmediaTV

MVN-XC440 openGear® Broadcast Transcoder

ITV-XC440c Standalone Broadcast Transcoder

User Manual

Version 1.0

Contents of this publication may not be reproduced in any form without the written permission

of ImmediaTV.

Notice

The material in this manual is furnished for informational use only, and it is subject to change

without notice. It must not be construed as a commitment by ImmediaTV. ImmediaTV assumes

no responsibility or liability for errors or inaccuracies that may appear in this manual.

Trademarks

DashBoard Control System™ is a trademark of Ross Video Limited.

openGear™ is a trademark of Ross Video Limited.

Apple® Mac OS®, Leopard®, and Snow Leopard™ are trademarks of Apple Computer,

Inc., registered in the U.S. and other countries.

Microsoft®, Internet Explorer®, and Windows® are either registered trademarks or

trademarks of Microsoft Corporation in the U.S.A. and/or other countries.

Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries.

Dolby® Digital Plus decoder technology on this product is manufactured under license

from Dolby Laboratories. Dolby® and the double-D symbol are registered trademarks of

Dolby Laboratories.

All other product names and any registered and unregistered trademarks mentioned in

this guide are used for identification purposes only and remain the exclusive property of

their respective owners.

Environmental Information

The equipment that you purchased required the extraction and use of natural resources for its

production. It may contain hazardous substances that could impact health and the environment.

To avoid the potential release of those substances into the environment and to diminish the need

for the extraction of natural resources, ImmediaTV encourages you to use the appropriate take-

back systems. These systems will reuse or recycle most of the materials from your end-of-life

equipment in an environmentally friendly and health conscious manner.

If you need more information on the collection, reuse, and recycling systems, please contacts

your local or regional waste administration.

Company Address

ImmediaTV

2005 De La Cruz Boulevard; Suite 150

Santa Clara CA 95050

USA

Telephone +1 408 496 1256

E-mail (Technical Support): [email protected]

E-mail (General Information): [email protected]

Website: http://www.immediatv.com

Contents

Copyright ........................................................................................................................................ 2

Notice.............................................................................................................................................. 2

Trademarks ..................................................................................................................................... 2

Environmental Information............................................................................................................. 2

Company Address........................................................................................................................... 3

Contents .......................................................................................................................................... 4

Safety Instructions for the ITV-XC440c Appliance....................................................................... 6

Electrostatic Discharge (ESD) and ESD Protection ................................................................... 6

Safety Notice and Warnings ....................................................................................................... 6

FCC Notice ............................................................................................................................. 6

Other Certifications................................................................................................................. 6

CE Mark Warning................................................................................................................... 7

Installation Safety Notes............................................................................................................. 7

Introduction..................................................................................................................................... 9

Product Overview ....................................................................................................................... 9

Redundancy Options................................................................................................................. 11

MVN-XC440 Indicators and Switches......................................................................................... 13

Rear I/O Panel Indicators.......................................................................................................... 13

Front Indicators......................................................................................................................... 14

Front Switches .......................................................................................................................... 15

DIP Switches............................................................................................................................. 16

ITV-XC440c Indicators and Switches.......................................................................................... 17

Back Panel ................................................................................................................................ 17

Front Panel Indicators............................................................................................................... 18

Front Panel Default Switch....................................................................................................... 19

MVN-XC440/ITV-XC440c Operation and Management............................................................ 21

Product Tab................................................................................................................................... 23

Network Tab ................................................................................................................................. 25

Network Configuration Tab...................................................................................................... 25

Network Statistics Tab.............................................................................................................. 27

ASI Input Ports ............................................................................................................................. 28

ASI Inputs: Configuration Tab ................................................................................................. 28

ASI Inputs: Configuration..................................................................................................... 28

ASI Inputs: Program Info Tab .............................................................................................. 30

ASI Inputs: Statistics Tab ......................................................................................................... 30

ASI Output Ports........................................................................................................................... 32

ASI Output Ports: Configuration Tab....................................................................................... 32

ASI Ports: Statistics Tab........................................................................................................... 34

IP Inputs........................................................................................................................................ 36

IP Inputs: Configuration Tab.................................................................................................... 36

Common Parameters............................................................................................................. 38

Redundancy Control ............................................................................................................. 38

Addressing Parameters.......................................................................................................... 39

Established Connections....................................................................................................... 41

The Apply/Cancel Buttons.................................................................................................... 41

Active IP Inputs Table .......................................................................................................... 42

IP Inputs: Program Info Tab..................................................................................................... 43

IP Inputs: Statistics Tab............................................................................................................ 44

IP Outputs ..................................................................................................................................... 46

IP Outputs: Configuration Tab.................................................................................................. 46

Active IP Outputs Table........................................................................................................ 51

Managing Unicast MAC Addresses...................................................................................... 52

IP Outputs: Statistics Tab.......................................................................................................... 53

Transcoders................................................................................................................................... 54

Transcoders Configuration Tab ................................................................................................ 54

Transcoder Configuration Parameters .................................................................................. 54

Transcoder Established Connections.................................................................................... 59

Transcoder Add Connections................................................................................................ 59

Transcoder Apply/Cancel Buttons........................................................................................ 60

Transcoder Statistics Tab.......................................................................................................... 60

Connections................................................................................................................................... 62

Connections Configuration Tab................................................................................................ 62

Source Selection.................................................................................................................... 63

Destination Selection............................................................................................................ 65

Establishing the Connection ................................................................................................. 67

The Current Connections Table............................................................................................ 67

Connection Statistics Tab ......................................................................................................... 68

Admin ........................................................................................................................................... 70

Admin General Tab................................................................................................................... 70

Admin Firmware Tab................................................................................................................ 71

Admin Config Files Tab ........................................................................................................... 73

User-Saved Configurations................................................................................................... 74

Pre-defined Templates .......................................................................................................... 75

Clear Current Configuration Button ..................................................................................... 76

Admin Test Packet Generator Tab............................................................................................ 76

Admin License Keys Tab.......................................................................................................... 78

Admin Event Log Tab .............................................................................................................. 79

Support Tab................................................................................................................................... 83

Control Tab................................................................................................................................... 84

Control Port Configuration Tab................................................................................................ 84

Control Port Statistics Tab........................................................................................................ 85

SNMP Configuration Tab......................................................................................................... 86

SNMP Statistics Tab................................................................................................................. 87

Playing Video on a Web Page ...................................................................................................... 88

Web Pages Served by the MVN-XC440 .................................................................................. 89

Web Browser Support........................................................................................................... 91

Safety Instructions for the ITV-XC440c Appliance

The ImmediaTV ITV-XC440c appliance is turned off by using the power switch. Power may

still be present in the appliance. To ensure that the appliance is completely shut down, unplug its

power cord from its power source.

The ImmediaTV ITV-XC440c appliance ships with all required components installed. There is

no need to open the chassis to add or remove components. Please contact ImmediaTV regarding

any malfunction or failure of the ImmediaTV appliance.

Electrostatic Discharge (ESD) and ESD Protection

Static electricity can damage boards, and other components. Before connecting or disconnecting

any device to the ImmediaTV ITV-XC440c appliance, we recommend you discharge static

electricity by first touching a metal part of a grounded PC.

Safety Notice and Warnings

FCC Notice

This device complies with Subpart B of Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

This device may not cause harmful interference.

This device must accept any interference received, including interference that may cause

undesired operation.

No Telecommunications Network Voltage (TNV)-connected PCBs shall be installed.

Other Certifications

This class A digital apparatus complies with Canadian ICES-003, Issue 4.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

This device complies with EN 55022 standards.

This device complies with EN 61000-3-2 standards.

This device complies with EN 61000-4-2 standards.

This device complies with CISPR 22 Edition 6.

This device complies with AS/NZS CISPR 22.

CAUTION: To reduce the risk of electric shock, do not open chassis; do

not defeat or remove the ground pin of the power cord; connect only to

a properly grounded ac power outlet. No user-serviceable parts inside.

Refer servicing to qualified service personnel.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio interference,

in which case the user may be required to take adequate measures.

Installation Safety Notes

Do not place the ImmediaTV ITV-XC440c appliance underneath heavy loads or in an

unstable position.

Do not expose the ImmediaTV ITV-XC440c appliance under direct sunlight, high

humidity or wet conditions.

Do not use or expose the ImmediaTV ITV-XC440c appliance around magnetic fields as

magnetic interference may affect the performance of the device.

Do not block the air vents to this device or impede the airflow in any way.

READ THE FOLLOWING SAFETY INFORMATION THOROUGHLY BEFORE

INSTALLING THIS IMMEDIATV PRODUCT. FAILURE TO FOLLOW THIS SAFETY

INFORMATION MAY LEAD TO PERSONAL INJURY OR DAMAGE TO THE

EQUIPMENT.

Power Supply

This unit must be grounded.

The unit must be connected to a grounded outlet to comply with product safety standards.

The grounded socket-outlet shall be installed near the equipment and shall be easily

accessible.

Do not connect the power supply unit to an AC outlet without a ground connection.

All power cords must be disconnected before servicing.

Power Cords

The plug on the power supply cords is considered to be the equipment disconnect device and

must be approved for the country where it is used.

Important Safety Information! Please note the following:

1. The ImmediaTV ITV-XC440c is intended for indoor use only.

2. In case of emergency, disconnect the power cords.

3. If power cords are not provided:

In the United States, use standard computer power cords (as

specified below).

In Europe, for 230 volt operation, use a cord set marked “HAR”

and consisting of a min 3 core H05VVF3G075 cord that has a

minimum 0.75 square mm diameter conductors, provided with

an IEC 320 receptacle and a male plug for the country of

installation, rated 6A, 250V.

4. Do not block the equipment vents.

For USA and Canada:

The cord set must be UL-approved and CSA-certified.

The attachment plug must be an earth-grounding type with a NEMA 5-15P (15A 125V)

plug and an EN60320/IEC320 receptacle.

Introduction

This manual covers the following products:

The MVN-XC440 openGear™ Broadcast Transcoder card

The ITV-XC440c standalone Broadcast Transcoder appliance

Both products have the same set of features, and essentially the same user interface. Unless

specifically indicated, all features and controls described in this manual apply to both products.

The MVN-XC440 and the ITV-XC440c have the following features:

Multi-Standard transcoder (MPEG-2 and H.264), with support for both SD (Standard

Definition) and HD (High Definition) content. Up to 4 simultaneous transcoding

instances are supported per board.

Resolution resizing support.

Audio pass-through support.

Audio transcoding support: MPEG-1 Layer II, AAC-LC and Dolby AC-3 inputs, and

MPEG-1 Layer II and AAC-LC outputs.

2 ASI input ports and 2 ASI output ports. All ports support the full ASI line rate of 213

Mb/s.

2 Ethernet ports with 100/1000 Mb/s support, capable of transmitting and receiving at

line rate.

Up to 8 simultaneous transmit and receive streams per Ethernet port.

RTP support for Ethernet transmission/reception

Advanced redundancy features.

Internal program replication –individual programs can be routed to multiple outputs.

Internal MPTS (Multi-Program Transport Stream) multiplexing and demultiplexing.

(P)SI parsing and generation; ATSC table parsing.

MPTS to SPTS Splitting support.

Typical application scenarios for the MVN-XC440 are:

Contribution and Distribution: optimizing legacy MPEG-2 equipment for backhaul

transmission.

IPTV ingest of legacy content.

IP and ASI protection switching.

Product Overview

The core of the MVN-XC440 is a switch that can select individual programs from transport

stream inputs and connect these programs to transport stream outputs. This switch works as an

intelligent demultiplexer for transport stream inputs, and an intelligent multiplexer for transport

stream outputs. Additionally, individual programs can be routed to one of 4 transcoder instances

to be processed prior to being connected to an output. A transcoder instance can change the

compression format (between MPEG-2 and H.264), the bit rate, frame rate, and/or resolution of

the stream, as well as change the audio compression format and bit rate.

The following inputs are available:

2 fixed-function ASI inputs

Up to 8 IP inputs per Ethernet port (for a maximum of 16 IP inputs)

2 internal test packet generators (which can be used to generate ASI or IP test streams)

The following outputs are available:

2 fixed-function ASI outputs

Up to 8 IP outputs per Ethernet port (for a maximum of 16 IP outputs)

Additionally, any of the inputs can be routed to one of 4 transcoder instances for processing.

In general terms, configuring the MVN-XC440 is a three-step process:

Step 1: Configure the input.

Step 2: Configure a transcoding instance, if desired. As part of this step, a connection between

the input and the transcoding instance can be established.

Step 3: Configure the output. As part of this step, a connection between the input and the output

can be established.

If you are making one-to-many connections, steps 1 and 2 are performed once, and step 3 is

performed multiple times. It is also possible to configure the output first (without making the

connection to an input), configure the input next, and finally make the connection between the

input and the output.

The overall architecture is depicted below.
