Ikelite DS160 Manual de usuario

Product Registration

Please register your product at www.ikelite.com within 15 days of

purchase. Our product registration database is the best way for us to

get a hold of you in the event of a product update or recall.

DS160 Strobe

Product Numbers 4060US • 4060EU • 4060AU • 4060UK

DS161 Strobe

Product Numbers 4061US • 4061EU • 4061AU • 4061UK

About this Product

Thank you for your purchase of Ikelite equipment. Please read this

instruction manual completely before attempting to operate or dive

with this product. Please visit ikelite.com to register your product to

receive information on any updates, notices, or recalls pertaining to

your equipment.

Included in the Box

• DS160 Strobe Front # 4060.2 or DS161 Strobe Front # 4061.2

• Rechargeable NiMH Battery Pack # 4066.5

• Battery Pack Cover # 0591.4

• Smart Charger for NiMH Battery Pack # 0083.92 US / 0083.93

European / 0083.94 United Kingdom / 0083.95 Australian

• Diffuser # 0591.3

• 1” Ball Mount # 4081.4

• Waterproof Bulkhead Cap # 9104.5

• Silicone Lubricant # 0184.1

Important Notices

»The battery pack is NOT waterproof when removed from the

strobe front.

»NEVER use, ship, or travel with a water damaged battery pack.

Use of a water damaged battery pack is a safety risk and can

cause damage to the strobe electronics.

»Store strobe front and battery pack in a cool, dry location

when not in use.

Contents

Product Registration 1

About this Product 2

Included in the Box 2

Important Notices 3

Getting to Know Your Strobe 6

Setting Up Your Strobe 8

Removing the Battery Pack 8

Attaching the Battery Pack 8

Using the Diffuser 9

Attaching the Diffuser 9

Choosing an Arm System 10

Attaching a Sync Connector 11

Using Your Strobe 12

Checking Battery Level 12

Turning the Strobe On 12

Using the Exposure Control 13

Positioning the Strobe 14

Firing the Strobe 14

Maintenance 15

Post-Dive 15

Travel and Storage 15

Troubleshooting 16

Photo Tips 18

Limited Warranty 19

Service and Repairs 19

Getting to Know Your Strobe

Batt

w/Lite

Off

w/Lite

TTL

Full

Fuel

Guage

Ready Light

-2

-3

-4

-1

SOS

Battery

Pack

Shroud

Flashtube

Reﬂ ector

DS161 Video Light

DS160 Modeling

Light

BulkheadMount

Toggle Lock

BACK

Mount

TTL Full

-2

-1

-3

-4

Fuel

Gauge

SOS

Batt

w/Lite

Off

w/Lite

SIDE

Exposure Switch

Fuel

Gauge

Ready

Light

Power

Switch

Lock

Setting Up Your Strobe

Removing the Battery Pack

»The battery pack is NOT waterproof when detached from the

strobe front.

1. Turn the Power Switch to the OFF position and place the strobe

face down on a ﬂ at surface.

2. Slide the toggle lock out and ﬂ ip up.

3. Rotate the toggle lock counter-clockwise 90 degrees.

4. Remove the Battery Pack from the strobe front.

OP

NO

Attaching the Battery Pack

»Never attach a water damaged battery pack to a strobe. Use of

a water damaged battery pack is a safety risk and can cause

damage to the strobe electronics.

1. Turn the Power Switch to the OFF Position and place the strobe

face down on a ﬂ at surface.

2. Check that the o-ring is in place and that the sealing surfaces are

clean. It is not necessary to lubricate the o-ring.

3. Place the toggle lock in the open position by sliding out, ﬂ ipping up,

and rotating 90 degrees counter-clockwise.

4. Align the battery pack with the front of the strobe. The switches on

the side of the strobe and battery pack will line up when properly

oriented.

5. Press the battery pack down gently but ﬁ rmly until it is ﬂ ush with the

strobe front.

6. Press ﬁ rmly on the toggle lock and rotate clockwise 90 degrees

until it stops.

7. Flip the toggle lock down and slide in to the locked position.

Using the Diffuser

The standard diffuser may be attached to further soften and spread

the edges of the strobe’s light output. The addition of a diffuser to any

strobe or light will reduce the effective power of the light.

The standard diffuser reduces the effective guide number of the ﬂ ash

by approximately one f/stop.

An optional Dome Diffuser is available separately to spread out the

light even more when shooting wide angle or macro.

Attaching the Diffuser

1. We recommend attaching the diffuser to the strobe with a string

or lanyard using the two holes in the diffuser. This will prevent

accidental loss when not in use.

2. Align the notches in the diffuser with the Diffuser Mounts on the

front of the strobe.

3. Press the diffuser down and rotate counter-clockwise until it stops.

Choosing an Arm System

• An aluminum ball socket arm system is recommended to

adequately support the strobe while allowing the most ﬂ exible

positioning options.

• Most arm systems are designed for underwater use and may not

fully support the strobe above water. Be careful when transporting

the system above water.

• The mounting point is located on the bottom of the strobe. Slide the

mount into the strobe until it stops. Be careful not to cross-thread

the screw when installing.

• Although not necessary, you may apply a small amount of Ikelite

silicone lubricant to the screw prior to attaching the strobe mount

to avoid seizing up with long term use. DO NOT apply Loc-tite or

any other thread locking product as this may cause damage to the

strobe’s plastic components.

Diffuser mount Notch
