Ikelite 4301.3 Manual de usuario

Thank you for your purchase of Ikelite equipment. Please read this

instruction manual completely before attempting to operate or dive

with this product.

TTL C nverter f r Nik n DSLR with

Ikelite C nnect r (Versi n 2)

Pr duct Number 4301.3

I n s t r u c t i n M a n u a l

Table of Contents

In luded in the Box ..............................................................3

Camera Compatibility............................................................3

General Information ..............................................................4

Strobe Compatability ............................................................5

Conne ting the Adapter ........................................................5 - 6

Swit hing between TTL and Manual ....................................6

Customer Support ................................................................7

Returning Produ ts for Servi e ..........................................7

Spare Parts ............................................................................Ba k Page

Limited Warranty ..................................................................Ba k Page

O-ring

Knurled Ring

Waterproof Bulkhead Cap

Ikelite Connector

Ikelite Bulkhead

IKELITE #0184.1

Silicone Lube

Ikelite Connector

Protector

Silicone Lubricant

In luded in the Box

- ikon D2X, D3, D4

- ikon D40, D50, D60, D70, D70s, D80, D90

- ikon D200, D300, D300s

- ikon D600, D610, D700, D750

- ikon D800, D810

- ikon D5000, D5100, D5200, D5300

- ikon D7000, D7100, D7200

- Fuji S5 Pro

Camera Compatibility

The TTL Converter is equipped with a simple rotating switch that allows

toggling between TTL and manual exposure.

Exposure compensation is OT provided through the Adapter, but may

be accessed through a camera button or the camera's built-in menu.

Proper operation and TTL exposure requires use of a current-model

Ikelite DS strobe - see Strobe Compatibility, Page 5.

Use of this TTL Converter requires an Ikelite 5-pin electrical bulkhead

strobe connector and TTL hotshoe. If you are unsure whether your

housing meets these requirements, please contact the housing

manufacturer. Wiring diagrams for our Ikelite connectors can be found at

ikelite. om.

One or two strobes may be connected to the Converter using an

Ikelite-to-Ikelite single or dual sync cord. Use of two strobes requires a

dual sync cord. Two strobes cannot be controlled by individual separate

Converters even if the housing is equipped with two bulkhead

connectors.

TTL Converters are not usable with non-Ikelite strobes or non-DS series

Ikelite strobes.

Due to hardware changes and risk of cord damage, we are unable to

modify existing 4301, 4301.2, 4302, or 4302.2 Converters to the newest

TTL protocol.

Please also note that strobe serial number requirements differ from the

original ikon TTL Converter - see Strobe Compatibility, Page 5.

The Ikelite TTL Adapter is NOT compatible with the following ikon

Cameras; D-100, D-1X, D-2H.

General Information

Use Adapter with Ikelite DS Strobes O LY. If using an older DS50 or

DS125 strobe, see Strobe Compatibility above.

1. Make sure all components are dry.

2. Remove Waterproof Bulkhead Cap and Connector Protector, Page 3.

3. Clean and lightly lubricate the threads and o-ring on the male Ikelite

connector. Use O LY Ikelite lube. Other brand lubricants can cause the

o-ring to swell and not seat properly. Check o-ring for cracks or nicks.

4 ote the positioning of the receptacles and pins. Properly align the

Ikelite Connector and insert it into the housing’s Ikelite-style bulkhead;

hand-tighten Knurled Ring.

5. Connect your Ikelite Sync Cord to the Adapter Bulkhead. Hand tighten the

Knurled Ring on the Sync Cord until there is no in-out movement

between the Ikelite Sync Cord Connector and Adapter bulkhead.

Hold the adapter’s knurled ring when tightening the syn ord.

CAUTIO : Do not use tools on, or over-tighten Knurled Rings.

Single or Dual Ikelite sync cords can be attached.

Dual strobe use requires dual sync cord.

Two strobes cannot be operated by independent adapters.

Conne ting the Adapter - referen e Diagram A, Page 6

AF35 ......................no

DS50 ......................above serial number 75510 with update

DS51 ......................above serial number 78700

DS160, DS161........all

on-Ikelite ..............no

Strobe Compatibility

The Knurled Ring on the TTL Adapter’s black delrin pod has a White Dot,

Diagram A.

The Knurled Ring can be rotated clockwise or counterclockwise to align

the White Dots for TTL or Manual operation.

The DS Strobe must be set to TTL mode for the Adapter to provide

TTL operation.

Swit hing between TTL and Manual

Ikelite Connector

Knurled Ring

Ikeli te Sync Cord Connector

Knurled Ring

Adapter Knurled Ring

To Housing

Bulkhead

Diagram A

Adapter

Bulkhead

Conne ting the Adapter - ontinued

White Dot

For the separate international customs documentation form that you

complete to accompany the shipment, please state or designate that the

enclosed products were originally manufactured in the USA and are

being returned to the manufacturer for repair service. Value of the

equipment listed for customs purposes should be zero.

Returning Produ ts for Servi e - outside the United States

Returning Produ ts for Servi e

Ikelite is most interested in performing any service to ensure that all

products perform as intended. Evidence of purchase date must be

provided to obtain warranty service.

o prior authorization is required. You may return directly to us or

through your dealer. Please include a brief description of the problem,

any relevant email correspondence, and/or instructions on what you

want us to do. Always include name, shipping address, email address,

and phone number inside of the package. Send postage paid to:

Ikelite Underwater Systems

Attention: Servi e Department

50 West 33 Street

Indianapolis, IN 46208 USA

No reimbursements for postage paid will be issued.

You may also want to insure the package.

Ikelite Underwater Systems

Servi e Department

50 West 33rd St.

Indianapolis, IN 46208 USA

Email: [email protected]

Phone: 317-923-4523

Customer Support

Ikelite Underwater Systems

50 West 33rd Street

Indianapolis, IN 46208 USA

ikelite. om

4301.3_TTL_Converter_ ikon_Ike_to_Ike_Version_2_01-1015

This Ikelite product is warranted against any manufacturing defects for a

period of one (1) year from the original date of purchase. Defective

products should be returned to Ikelite postage paid. Ikelite will, at its sole

discretion, repair or replace such products, and will return to customer

postage paid. All other claims of any nature are not covered. Except as

mentioned above, no other warranty expressed or implied applies to this

Ikelite product.

Limited Warranty

0301.12 ..........Connector Protector for Ikelite plug

9104.5 ............Waterproof Bulkhead Cap

0118 ................O-ring

0184.2 ............silicone lubricant 2cc recloseable tube

Spare Parts
