VCM-901

9-Inch Color Monitor

■Description

■Features

The VCM-901 is a 9-inch Color Monitor with 300 TV Lines Resolution. It is suitable for industrial CCTV

surveillance applications. The VCM-901 can be used in desktop or dual rack mounted, using an optional

rack mount kit (RMK-901).

■

9-inch in-line gun, semi-tinted CRT that

produces 300 lines of Horizontal resolution

■

Accepts both NTSC and PAL

■

Accepts Y/C signal

■

Two Video IN connectors

■

Two Audio IN/OUT connectors

and a built-in speaker

■

Durable metal cabinet

■

Adjustable Tint, Color, Contrast

Brightness and Audio volume

■

Ideal for multiple professional

applications such as FCC, cUL,DHHS,

CE and ISO9001

■

Two units fit side by side in a standard EIA rack.

RMK-901 rack mount kit is Optional.

VCM-901

■Specifications

IKEGAMI ELECTRONICS (U.S.A.), INC.

HEADQUARTERS 37 BROOK AVENUE, MAYWOOD, NJ 07607

Phone: (201) 368-9171 Fax: (201) 569-1626

WEST COAST OFFICE 2631 MANHATTAN BEACH BLVD., REDONDO BEACH, CA 90278 Phone: (310)297-1900 Fax (310)536-9550

SOUTHWEST OFFICE 526 BLUEBIRD LANE, RED OAK, TX 75154 Phone: (972)869-2363 Fax: (972)556-1057

MIDWEST OFFICE 747 CHURCH ROAD, UNIT C1, ELMHURST, IL 60126 Phone: (630) 834-9774 Fax: (630) 834-8689

SOUTHEAST OFFICE 5200 N.W. 33RD AVENUE, SUITE 111 FORT LAUDERDALE, FL 33309 Phone: (954) 735-2203 Fax: (954) 735-2227

■ URL http://www.ikegami.com

General

Color System NTSC/PAL

Input/Output Connections Video IN: BNC x2, Y/C x1

Video OUT: BNC x2

Audio IN: RCA x2

Audio OUT: RCA x2

Picture Tube 9" In-Line Gun,

Semi-tinted CRT,

90°Deflection

Resolution 300TV Lines at center

Power Source AC 100 ~ 240V, 50/60Hz

Power Consumption Approx. 45W

Linearity Horizontal: 10%

Vertical:10%

Position Horizontal: ± 8mm

Vertical: ± 8mm

Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)

Operating Humidity 35% ~ 80% (non-condensing)

Net Weight Approx. 7.5kg (16.7 lbs)

Dimensions(WHD) 220 x 223 x 317mm

(8.66 x 8.78 x 12.48 inches)

Enclosure Metal

Video

Input level: 1.0 ± 0.2Vp-p, 75 ohms

Control & Switches

Mechanical Push Button: Power

Soft Touch Button: Tint, (NTSC only)

Color, Brightness,

Contrast, Volume Up,

Volume Down, Video Selector

(Video1, Video2, Y/C)

Indicators Green LED's for Power,

Video1, Video2, Y/C

Accessories Power Cord, Owner's Manual

Approvals FCC Class A, cUL, DHHS,

CE, ISO9001

*These specifications are subject to change without notice.
