IKEA KULINARISK Manual de usuario

KULINARISK

ENGLISH 4

DEUTSCH 17

FRANÇAIS 29

ITALIANO 48

1345

Please refer to the last page

of this manual for the full list

of IKEA appointed Authorized

Service Centre and relative

national phone number

1345

Consultare l’ultima pagina

di questo manuale dove è

riportato l’elenco completo

dei Centri Assistenza IKEA

Autorizzati con i relativi numeri

telefonici nazionali.

1345

Consultez la dernière page

de ce manuel contenant la

liste complète des services

Après-vente agréés IKEA avec

les numéros de téléphone

nationaux correspondants.

Konsultieren Sie die letzte Seite

dieser Bedienungsanleitung,

auf der die vollständige Liste

der nationalen autorisierten

IKEA Kundendienststellen mit

den entsprechenden Telefon-

nummern aufgelistet ist.

ENGLISH

Contents

Safety information 4

Product description 9

Care and cleaning 10

What to do if... 11

Technical data 12

Energy efficiency 13

Environment concerns 14

IKEA GUARANTEE 14

Safety information

For your safety and correct operation of the appliance, read

this manual carefully before installation and use. Always

keep these instructions with the appliance even if you move or

sell it. Users must fully know the operation and safety features

of the appliance.

The wire connection has to be done by specialized

technician.

• The manufacturer will not be held liable for any damages

resulting from incorrect or improper installation.

• The minimum safety distance between the cooker top and

the extractor hood is: for electrical hob 500mm and for gas

hob 650mm.

• If the instructions for installation for the gas hob specify a

greater distance, this must be respected.

• Check that the mains voltage corresponds to that indicated

on the rating plate fixed to the inside of the hood.

• Means for disconnection must be incorporated in the fixed

wiring in accordance with the wiring rules.

• For Class I appliances, check that the domestic power supply

guarantees adequate earthing.

• Connect the extractor to the exhaust flue through a pipe of

minimum diameter 120 mm. The route of the flue must be

as short as possible.

• Do not connect the extractor hood to exhaust ducts carrying

combustion fumes (boilers, fireplaces, etc.).

ENGLISH

• If the extractor is used in conjunction with non-electrical

appliances (e.g. gas burning appliances), a sufficient degree

of aeration must be guaranteed in the room in order to

prevent the backflow of exhaust gas. When the cooker hood

is used in conjunction with appliances supplied with energy

other than electric, the negative pressure in the room must

not exceed 0,04 mbar to prevent fumes being drawn back

into the room by the cooker hood.

• The air must not be discharged into a flue that is used for

exhausting fumes from appliances burning gas or other

fuels.

• If the supply cord is damaged, it must be replaced from the

manufacturer or its service agent.

• Connect the plug to a socket complying with current

regulations, located in an accessible place.

• With regards to the technical and safety measures to be

adopted for fume discharging it is importat to closely follow

the regulations provided by the local authorities.

WARNING: Before installing the Hood, remove the

protective films.

• Use only screws and small parts in support of the hood.

WARNING: Failure to install the screws or fixing device in

accordance with these instructions may result in electrical

hazards.

• Connect the hood to the power net by using a bipolar switch

having a contact gap of at least 3 mm.

• Do not look directly at the light through optical devices

(binoculars, magnifying glasses…).

• Do not flambè under the range hood; risk of fire.

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

ENGLISH

use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

• Children should be supervised to ensure that they do not

play with the appliance.

• The appliance is not to be used by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction

Accessible parts may become hot when used with cooking

appliances.

• Clean and/or replace the Filters after the specified time

period (Fire hazard).

• There shall be adequate ventilation of the room when the

range hood is used at the same time as appliances burning

gas or other fuels (not applicable to appliances that only

discharge the air back into the room)

ENGLISH

Use

• Switch off or unplug the appliance

from the mains supply before

carrying out any maintenance work.

• The top of the hood must not to be used

as a shelf.

• The extractor hood has been

designed exclusively for domestic

use to eliminate kitchen smells.

• Never use the hood for purposes

other than for which it has been

designed.

• Never leave high naked flames under

the hood when it is in operation.

• Adjust the flame intensity to direct

it onto the bottom of the pan only,

making sure that it does not engulf

the sides.

• Deep fat fryers must be continuously

monitored during use: overheated oil

can burst into flames.

Care and cleaning

• Grease filters must be cleaned every

2 months of operation, or more

frequently for particularly heavy

usage, and can be washed in a

dishwasher.

• Clean the hood using a damp cloth

and a neutral liquid detergent.

Care and cleaning long life Charcoal

filter (Green)

• The anti-odour Flter can be washed

and regenerated every 3-4 months

(or more frequently if the hood is

subject to intensive use), up to a

Max. of 8 regeneration cycles (in

case of particularly intensive use it

is recommended that you do not

exceed 5 cycles).

Regeneration procedure:

• Wash in the dishwasher at a MAX

temperature of 70° or hand wash in hot

water without using abrasive sponges

(do not use detergents!)

• Dry in the oven at a MAX temperature

of 70° for 2 hours or dry at room

temperature, standing the Flter in a

vertical position to facilitate drainage.

ENGLISH

Installation modes

The hood has been designed to be installed

and used either as a “Exhaust mode”, or as

a “Recirculation mode”.

Exhaust mode (see symbol

min 471 mm

max 861 mm

min 569 mm

max 861 mm

min 471 mm

max 861 mm

min 569 mm

max 861 mm

installation booklet)

Cooking steam is sucked and

channelled outside the house through

a discharge duct (not supplied), fitted to

the hood steam outlet.

Ensure that the discharge duct is

correctly fitted to the air outlet, unit

using an appropriate connection

system.

Recirculation mode (see symbol

min 471 mm

max 861 mm

min 569 mm

max 861 mm

min 471 mm

max 861 mm

min 569 mm

max 861 mm

in installation booklet)

The air is filtered through one or more

the charcoal filters, and then resent into

room.

Important: Ensure appropriate air

circulation around the hood.

Important: If the hood is supplied

without charcoal filters and installed on

recirculation mode, these must be fitted

before the hood can be used. Filters are

available in shops.

The hood should be installed away from

particularly dirty areas, windows, doors

and heat sources.

The accessories for wall fixing are not

included because wall made of different

materials require different types of

fixing accessories. Use fixing systems

suitable for the walls of your home and

the weight of the appliance. For more

details, contact a specialized dealer.

Keep this booklet for future

consultation.

Filters Alarm.

When the filter alarm is activated, the

following messages will appear over

time:

Grease filter must be cleaned:

“A” key flashes once per second. For

maintenance see paragraph Care and

cleaning.

Anti-odour filter must be cleaned:

“A” key flashes twice per second. For

maintenance see paragraph Care and

cleaning.

Once the filters have been regenerated

reset the alarm signal (see paragraph

Control Panel).

ENGLISH

Product description

Upper chimney

Lower chimney

Hood body

LED Lighting

Grease filter

Control panel

Control Panel

S0614 (170201)

backlight symbols

112

20 20 20 20

S0614 (170201)

backlight symbols

Speed

Turns the motor on/o at speed one.

Attention: the product is with the lter alarm disabled.

Press and hold the button for approximately 2 seconds, with all the loads turned o (Motor+Lights), to turn the grease lter alarm on. LED

(B) ashes twice to conrm.

To turn the alarm o, press the button again and hold for at least 2 seconds. The relevant LED (B) ashes once.

Speed

Turns the motor on at speed two / Activate charcoal lter alarm.

Attention: the product is with the lter alarm disabled.

Press and hold the button for approximately 2 seconds, with all the loads turned o (Motor+Lights), to turn the Activated Charcoal Filter

alarm on. LED (A) ashes twice to conrm.

To turn the alarm o, press the button again and hold for at least 2 seconds.The relevant LED ashes once (A). Only for recirculation mode.

Speed

Turns the Motor on at speed three / Reset alarm lter saturation.

Press and hold the button for approximately 2 seconds, with all the loads turned o (Motor+Lights), to reset the grease lter

saturation alarm or charcoal lter alarm. LED (A) ashes three times.

Speed

Turns the motor on at Booster speed.

This speed is timed to run for 6 minutes. At the end of this time, the system returns automatically to the speed that was set before. If it is

activated with the motor turned o, it will switch to OFF at the end of the time. To deactivate it, press button D or press button A.

Light

Press briey: Turns the lighting system on and o at maximum intensity.

Press and hold to change the lighting intensity up or down.

ENGLISH

Care and cleaning

Switch off or unplug the appliance

from the mains supply before carrying out

any maintenance work.

IMPORTANT Clean the hood using a damp

cloth and a neutral liquid detergent.

Long Life Charcoal Filter

The anti-odour Filter can be washed and

regenerated every 3-4 months (or more

frequently if the hood is subject to inten-

sive use), up to a Max. of 8 regeneration

cycles (in case of particularly intensive use

it is recommended that you do not exceed

5 cycles).

Grease Filters

Clean or replace the filters continuously

according to below time intervals, to main-

tain good performance of the hood and to

prevent a potential fire hazard, caused by

excessive grease build-up.

The grease filters must be cleaned every 2

months of operation, or more frequently

for particularly heavy usage, and can be

washed in a dishwasher.

Replacing the lamps

For Replacement please contact an Au-

thorized Service Center.

• Switch ON the hood at minimum speed when you start cooking and kept it running for

few minutes after cooking is finished.

• Increase the speed only in case of large amount of smoke and vapour and use boost

speed(s) only in extreme situations.

• Replace the charcoal filter(s) when necessary to maintain a good odour reduction ef-

ficiency.

• Clean the grease filter(s) when necessary to maintain a good grease filter efficiency.

• Use the maximum diameter of the ducting system indicated in this manual to optimize

efficiency and minimize noise.

General hints

Otros manuales para KULINARISK

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Campana de ventilación de IKEA

IKEA

IKEA LUFTIG Manual de usuario

IKEA

IKEA Rytmisk Manual de usuario

IKEA

IKEA UTDRAG Manual de usuario

IKEA

IKEA IH6302YS0 Hoja de información del producto

IKEA

IKEA UNDERVERK Manual de usuario

IKEA

IKEA MATTRADITION Manual de usuario

IKEA

IKEA SVÄVANDE Manual de usuario

IKEA

IKEA UDDEN Manual de usuario

IKEA

IKEA EVENTUELL Hoja de información del producto

IKEA

IKEA IHW7303WS0 Manual de usuario

IKEA

IKEA PLANENLIG Manual de usuario

IKEA

IKEA FORTROLLA Manual de usuario

IKEA

IKEA IHI8304WS0 Hoja de información del producto

IKEA

IKEA OMNEJD Manual de usuario

IKEA

IKEA IHW6302YB0 Hoja de información del producto

IKEA

IKEA BEMOTA Manual de usuario

IKEA

IKEA UNDERVERK Series Manual de usuario

IKEA

IKEA KULINARISK 304.432.04 Manual de usuario

IKEA

IKEA LUFTIG Manual de usuario

IKEA

IKEA VINDIG Manual de usuario

IKEA

IKEA IHW53UC0FS2 Hoja de información del producto

IKEA

IKEA KULINARISK Manual de usuario

IKEA

IKEA IH3302WQ0 Manual de usuario

IKEA

IKEA FOLJANDE Manual de usuario

Manuales populares de Campana de ventilación de otras marcas

emmeti

emmeti RECUPA MED A-140 Guía

Nibe

Nibe F135 Manual de usuario

Kuppersberg

Kuppersberg INTRO 60 Instrucciones de instalación y mantenimiento

Zephyr

Zephyr Spruce AK9834BS Guía de instalación

Hisense

Hisense MH6INBG Manual de usuario

Miele

Miele DA 1255 Manual de usuario

Broan

Broan 46000 Manual de usuario

GE Profile PV977 Instrucciones originales

FALMEC

FALMEC FFRIA24W5FS Manual de usuario

Whirlpool

Whirlpool RH2600XL-1 SERIES Manual de usuario

Küppersbusch

Küppersbusch DX ISLA Manual de usuario

ETNA

ETNA AV360RVS Manual de usuario

JUNO

JUNO JDF603E6 Manual de usuario

Miele

Miele DA 6708 D Manual de usuario

Tricity Bendix

Tricity Bendix LE 150 Manual

AEG

AEG X68163BV1 Manual de usuario

AEG

AEG 125 D Manual de usuario

Smeg

Smeg KSEV97X Manual de usuario
