IKEA IRIBT26WA Manual de usuario

Service Manual

INDEX

Sno. Detail Page No.

Model Range

Feature /Technical specification

Controls & Electronic configuration

Wiring Diagram

Controlling the refrigerator temperature

Service Process

Exploded view

Serviceable Parts List

Plug Pin Check Points

1. MODEL RANGE

Commercial Code

IRIBT26WA

IRIBT29MB

12NC

852460153230

852460153240

13EAN AUS

9320921075347

9320921075446

Product Description

IKEA 260LT WHITE TOP MOUNT

REFRIGERATOR

IKEA 290LT STAINLESS TOP

MOUNT REFRIGERATOR

Ikea Details

LAGAN fridge/freezer176/57Lwhite

ENERGISK fridge/freezer

202/57L silver colour AU

Ikea Article #

00275532

20275531

2. TECHNICAL /FEATURE SPECIFICATION

MODEL

260L IRIBT26WA

290L IRIBT29MB

Type

Frost Free

Capacities (L) total net

260 L

290L

Product Dimensions (mm)

Width

569

Height

1587

1714

Depth

640

Gross Weight (kg)

Voltage / Hz

220V /240V/50Hz

Voltage Range

160-260V

Compressor

ADW66AK

Oil Capacity

220 cu.cm

Comp. Run Capacitor

CBB60

PTC Relay

YES

Motor Protector

YES

Fan motor

MI AC MOTOR FOR

DUO 9.8W

MI AC MOTOR FOR

DUO 9.8W

Compressor Wattage

120 W

Split Diffuser

Deodorizer

Yes

Number of Shelves

Type of Shelves

Glass

Humidity Control

RC Illumination

Illumination by Lamp

FC Illumination

Packet Separator

Bottle separator

YES

Defrost tray (Thaw zone)

YES

Can rack

Handle

FLUSH

Egg tray

1 No.

Removable ice twister

YES

Thaw zone shelf

YES

RC Shelf

YES

Freezer Door Bins

Refrigerator Door Bins

FC SHELF

YES

Door lock

Roof Rail

Cabinet Stopper

YES

Beer caddie

YES

Electromechanical Control

in RC compartment

YES

Quick Chill/Fast Forward

Cool Operation

Door Alarm

Auto Power save mode

Health Hygiene Benefit

YES

EGA to celebrate Health

plank

3. Electronic Configuration, Logic & Troubleshooting

GENX Controls & Electronics Configuration

Product Configuration

240/260/290L Dlx

Product Control

RC Controlled

Software

User interface

Auto cool mode

Quick Chill/Fast Forward Ice

Auto Power save mode

Door Alarm

RC Illumination

Yes(Lamp)

Control Board

Defrost heater

Yes (Radiant Heater 180 W)

Fan motor

FAN MOTOR MI

(160-260V)

FC Door grounding

Compressor

ADW66AK

Run Capacitor

Door Reversibility

DELUX: -In this type of refrigerator, there is no user Interface on freezer compartment door for setting

cooling .There is a thermostat in RC compartment to set temp settings.

RATED VOLTAGE : 220-240V,50-60Hz, IPH

VOLTAGE RANGE : 160V –260V

INPUT WATTAGE : 120W

DEFROST WATTAGE : 180W

RATED CURRENT AMPS : 0.7A

4. Wiring Diagram

GENX Dlx

Refrigerant Charging Qty:

Note: -

There is no Service routine provided in this model.

In Dlx models Diagnosis of the Error / Sensor / Pot failure is not of continuous

nature.

In case of any detailed technical information please check with the Dlx technical

specification.

5. Controlling the refrigerator temperature-

Dlx Models:

SETTING

Usage condition

LOW

During Winter condition or when there is not much food stored in the refrigerator

MID

This is the default and recommended setting. Can be used in normal usage.

HIGH

During summers or when there is a lot of food stored in the refrigerator

QUICKCHILL

During extreme summers or when you want faster cooling.

To control the temperature of your refrigerator. Turn the knob

according to your requirement. This control is provided inside the

refrigerator section. Turn knob to the left to reduce the cooling and to

the right to increase the cooling. It is preset to the middle position.

6. Service Process:-

1. Separate FC door from refrigerator

2. Use 8mm round spanner and remove three screws of center hinge

3. Remove Center Hinge

4. Pick the RC door upward and separate from refrigerator

FC PLENUM:-

1. Identify 2 screws of FC Plenum

2. Use Star screw driver and remove 2 screws of FC Plenum

3. Pull plenum down by inserting your fingers in the slot located at top center

4. Disconnect fan motor connectors

5. Separate FC Plenum from refrigerator

6. FC Plenum is mandatory to dismantle for dismantling of Thermal fuse, Bimetal, FC sensor, D heater etc.
