V3000
Userʼs Manual
3” Color LCD Monitor
Dear Customers
Thank you for purchasing the ikan V3000 3” LCD TFT Monitor.
This product employs new integrate circuitry, and a high quality TFT LCD
panel. It has low power consumption, high quality, and no radiation. The V3000
is compact and portable. ikan displays are suitable for all video applications
including professional video, desktop computing, mobile entertainment and
security. We know you will enjoy your new ikan monitor and itʼs many capabilities.
To insure best use of this unit, please read
this userʼs manual carefully before hand.
Important Safeguards and Precautions
1. To prevent unecessary damage to your monitor, do not remove the cover or
take a part this unit by yourself. If in need of service please call ikan or a
qualified technician.
2. Do not insert anything into the case, avoid spilling water in the case.
Keep away from children.
3. Avoid direct light to maintain the clearest and most colorful picture.
4. Avoid heavy impacts, do not drop as this may damage the display.
5. Do not use chemical solutions to clean this product. Simply wipe
with a clean soft cloth to keep the brightness of the surface.
When not in use for long periods
disconnect the power as a safety precaution.
1
Model V3000
Display Screen
Color System
Video Input
Audio Output
Input Voltage
Size
Weight
3.0” TFT 93600 pixels
PAL, NTSC, SECAM
1V p-p IMPEDANCE: 75 Ω
>100mW
DC 8V or 12V
3.46”(L) X 3.18”(W) X 1.18”(H) inches
5.5 oz
Main Specifications
Accessories
Included
-A/V input plug 1 piece
-AC Adapter 1 piece
-Userʼs Manual 1 piece
2
Power Consumption <6W
Appearance
1. POW: Power Switch
2. BRI: Brightness Adjuster
3. VOL: Volume Adjuster
4. CON: Contrast Adjuster
5. COL: Colour Adjuster
6. A/V: Audio/Video input cord
Figure 1. (V3000)
3
Operation
1. POWER SOURCE
ATTENTION: The electric poles of the power cord are as follows:
inner”+” and outer “-”. The input voltage is DC 8V or DC 12V
To turn the power on or off use the “POWER SWITCH” (POW).
2. PICTURE AND AUDIO ADJUSTMENT:
To adjust the volume use the “VOLUME ADJUSTER” (VOL).
To adjust the brighness use the “BRIGHTNESS ADJUSTER” (BRI).
The fine adjustments of contrast and color of the picture can be
done using the “CONTRAST ADJUSTER” (CON) & the
“COLOUR ADJUSTER” (COL)
3. AV INPUT:
When this monitor is connected to a camera, deck, or other device
the “AUDIO/VIDEO” (A/V) input will be used to input the signal.
4
Contact Information
Our Street Address is:
ikan corporation
10515 Harwin Suite 100
Houston, Tx 77036
Find us on the Web at:
http://www.ikancorp.com
Email us at:
By Telephone:
1-713-272-8822
5
CORPORATION © 2004
