IHome IZBT5 Manual de usuario

Model iZBT5

Portable Sound + Light

Therapy Bluetooth Speaker

QUESTIONS? Visit www.ihome.com

CHARGE

BEFORE

USE

1. iZBT5 speaker

3. USB charging cable 4. Carry strap 5. Aux-in audio Cable

WELCOME

Thank you for choosing the iZBT5 from iHome. This user guide will

get you up and running quickly. For more information about this and

other iHome products, please visit www.ihome.com

GETTING STARTED

This unit ships with the following items. Please check to see that all

items are present.

1. iZBT5 speaker

2. 100-240V Universal USB AC power adaptor

3. USB charging cable

4. Carry strap

5. Aux-in audio cable

2. USB AC adapter

FEATURES & FUNCTIONS

iHOME ZENERGY™ APP

Sound Therapy

Mode Button

Power On/O

Button

Sleep Indicators

(in minutes)

Mode Indicator Lights

(Light Therapy (blue)

or Sound Therapy (red)

modes)

Bluetooth Pairing

Button

Back panel

Light Therapy Mode

Button

Carry strap channel

Sleep Mode Button

Reset Port

Volume

Buttons

Brightness

Up/Down

Buttons

Aux-in jack

Mic

USB In

charging port

(to charge unit)

Travel Lock switch

Move to Lock position during

travel to prevent accidental

button presses

Play Pause/Speakerphone Button

• Press to play/pause Bluetooth audio

• Press to answer/end Bluetooth calls

Solid RED when ON

Flashing RED when battery is low

Pulsing RED while charging

Download the free iHome Zenergy™ App from the

Apple App Store or Google Play to extend and enhance

the Light Therapy and Sound Therapy experience, including

setting up alarms. See App for details.

TRAVEL LOCK

The Travel Lock Switch located on the back of the unit prevents

unwanted button activation when in the Locked position .

To operate the unit, make sure switch is in the Unlocked position .

BATTERY CHARGE INDICATOR

The battery charge level is indicated by the Power Button. The indication

changes depending on whether or not the unit is charging (connected via

USB to AC) or operating on the battery.

CHARGING THE iZBT5

This unit operates on an internal

rechargeable battery. While the

battery was fully charged at the

factory, the battery may discharge

during shipment. MAKE SURE TO

FULLY CHARGE THE BATTERY

BEFORE USE.

Plug the small plug end of the

included USB charging cable into

the USB charging port located on

the left side of the unit and plug

the other end into the included

USB AC adapter. Plug the adapter

into a working outlet not controlled

by a light switch. The Power Button

will glow red. Once fully charged,

the unit should operate for up to

6.5 hours at moderate volume.

Pulsing red light

Solid red light

Blinking red light

Connected via USB

Yes

Not connected

Power Button Battery Status

Charging

Charged

Battery is good

Battery needs charge

TIP: On some iOS (Apple)

devices, you can view the

iZBT5 battery status on

your device’s screen. When

device is paired and

connected, look for a

vertical battery icon next to

the Bluetooth icon on the

upper right corner of the

device’s screen.

AC USB Adaptor

BLUETOOTH

PAIRING

Pairing establishes a unique communication connection between the unit and

your Bluetooth device. Once paired, you will be able to stream audio

wirelessly to the iZBT5.

1. Turn on your Bluetooth device and make it

“discoverable” by turning on Bluetooth mode

(check in Options or Settings).

2. Press and release the Power Button to turn

on the iZBT5.

3. Press and hold the

Bluetooth

Button (located

on back of the unit) for 2 seconds. 2 beep tones

will sound and the indicator light on the

Bluetooth button will ﬂash red while the unit

attempts to pair. “iHome iZBT5” should appear

on your device’s menu. Select “iHome iZBT5” on

device to begin/complete pairing. If your device

asks for a password, enter 1234 on the keyboard

of your device. A tone will sound and the red

indicator will glow solid. If no device is paired

within 3 minutes, the unit will revert to its

previous state.

The next time you power on the unit it will

automatically link with the previously paired device

as long as that device is still within range (about 33

feet). To clear/reset Bluetooth, press and hold the

Bluetooth button for 10 seconds until you hear a

long beep. Note: Reset is disabled in Sound Therapy

mode.

TIP: The iHome Zenergy™ App works over Bluetooth

using the Bluetooth Low Energy protocol. In use, it

it will appear on your device’s Bluetooth menu as

iZBT5-app. Download it for an enhanced

experience.

iHome iZBT5

PLAYING AUDIO VIA BLUETOOTH

1. Press and release the Power Button to turn on the iZBT5.

2. Press and release the Play/Pause/Call Button to play or pause

audio. Press 2x to skip to the next song, press 3x to return to the start of

the current track or go to the previous track (depending on where you are

in the track).

3. Press and release the or Volume Buttons to adjust speaker volume.

You can also adjust the output volume on your Bluetooth device.

4. When done listening, press and release the Power Button to power o the

unit.

NOTE: To save battery life the unit will automatically power o if there is no

audio or light detected for 15 minutes.

USING THE SPEAKERPHONE

Unit must be powered ON and paired with a Bluetooth-enabled phone to

use the speakerphone feature. When a call is received, current audio is

paused.

1. Press and release the Play/Pause/Call Button to answer a call.

Press and hold to ignore or end a call.

2. Press and release the Play/Pause/Call Button to place a current

call on hold and answer a new call (call waiting) and to switch between 2

calls.

LIGHT & SOUND THERAPY MODES

LIGHT THERAPY MODE

Circadian rhythms, or our internal clocks, are linked to changing wavelengths

of light throughout the day. Color Light Therapy simulates these wavelengths,

triggering subtle biological responses that can help improve sleep, energy,

and mood. Light Therapy mode includes 6 separate Light Therapy patterns to

help you feel great.

1. Press the Light Therapy Button to access Light Therapy mode. Continue

to press to cycle to each mode:

Breath: Inhale and hold with the amber light and exhale with

the red, matching your breath to this timed pattern

can lower your heart rate and calm your mind

Calm: Red-toned lights calm the mind at night and

stimulate the production of melatonin, helping to

prepare the body for sleep

Energy: Swirling blue-toned lights inhibit melatonin, increase

morning alertness, and energize the mind

Aurora: A swirling spectrum of colors creates a beautiful

atmosphere for day or night mood lighting

(not recommended before sleep)

Glow: A gentle fading spectrum of solid colors creates a

beautiful atmosphere for day or night mood lighting

(not recommended before sleep)

One Color: Select the current color

O: Turn Light Therapy OFF

The current light mode is shown by the blue lit indicator beside its name.

2. Press the Brightness Buttons to adjust the intensity of the light to

suit your mood and room conditions

3. Press and hold the Light Therapy Button for 2 seconds to exit light

therapy mode. Press the Light Therapy Mode Button again to resume

mode at the last used light pattern.

SOUND THERAPY MODE

Distracting noises or a racing mind can make it hard to sleep at night or

focus during the day. Sound Therapy uses specially recorded and

engineered sounds to cancel out these distractions and allow your mind to

calm. Sound Therapy mode includes 6 separate Sound Therapy presets to

help you feel great.

1. Press the Sound Therapy Button to access Sound Therapy mode.

Continue to press to cycle to each mode:

Zen: A tonal melody in frequencies that mimic the Delta

brainwaves of a mind in meditation or healing

sleep

Heartbeat: Listening to a relaxed heart beat encourages your

own heart beat to slow to match it

Ocean: Authentic, digitally recorded ocean sounds

Storm: Authentic, digitally recorded storm and rainfall

sounds

Nature: Authentic, digitally recorded springtime woodland

sounds

White Noise: The standard white noise repeating frequency, like

a fan, which helps to actively negate distracting

environmental noises

O: Turn Sound Therapy OFF.

The current sound mode is shown by the red lit indicator beside its name.

2. Press and release the or Volume Buttons to adjust speaker

volume.

3. Press and hold the Sound Therapy Button for 2 seconds to exit sound

therapy mode. Press the Sound Therapy Button again to resume at the

last used sound preset.

LISTENING TO AUX DEVICES

1. Connect a standard audio cable with 3.5mm plug to the headphone or

line-out jack on your AUX device and the other end to the AUX IN jack

located on the right back of the iZBT5.

2. Press and release the Power Button to turn on the unit.

3. Turn on your AUX device and use its controls to play, pause and navigate

audio tracks. Adjust the volume on your AUX device to maximum output.

4. Press and release the or Volume Buttons to adjust speaker volume.

5. Press and release the Power Button to turn o the unit when through

listening. Remember to turn o your AUX device, too.

Mobile Phone Game Devices iPod Laptop

PC/Tablet MP3/MP4

SLEEP MODE

Sleep mode lets you sleep to any combination of light and sound therapy

or Bluetooth audio for the set sleep duration. The light and sound levels

will be gradually decreased over time until the unit shuts o.

Press the Sleep Button as needed to cycle to the desired sleep duration:

90, 60, or 30 minutes shown by the lit sleep indicators on the back of the

unit. Sleep mode is inactive when no sleep indicator is lit.

RESET PORT

The Reset Port is located on the back of the unit. If the unit is “frozen”,

or does not respond properly, insert the end of a paper clip or similar into

the port. This will reset the unit to factory default settings and you will

need to re-pair any Bluetooth devices.

Attaching the Carry Strap

A carrying strap is included with the iZBT5

for easy carrying or attaching to a backpack, etc.

To attach the strap, insert the small loop

through the strap channel on top of the unit

then pull the large loop through the small loop.

Tabla de contenidos

Otros manuales de Oradores de iHome

iHome

iHome iAVS16 Manual de usuario

iHome

iHome iDM3 Manual de usuario

iHome

iHome iBT76 Manual de usuario

iHome

iHome iBN24 Manual de usuario

iHome

iHome iBT69 Manual de usuario

iHome

iHome iBT90 Manual de usuario

iHome

iHome iM71 Manual de usuario

iHome

iHome iW1 air series Manual de usuario

iHome

iHome iBT61 Manual de usuario

iHome

iHome iBN10 Manual de usuario

iHome

iHome PLAYGLOW MINI iBT800 Manual de usuario

iHome

iHome iBN19 Manual de usuario

iHome

iHome iDM15 Manual de usuario

iHome

iHome iHRK-500S-PR Manual de usuario

iHome

iHome iDM14 Manual de usuario

iHome

iHome iBT16 Manual de usuario

iHome

iHome iBT84 Manual de usuario

iHome

iHome iBT371 Manual de usuario

iHome

iHome Baby iZ44 Manual de usuario

iHome

iHome iH8 Manual de usuario

iHome

iHome iBT374 Manual de usuario

iHome

iHome iWBT1 Manual de usuario

iHome

iHome TIMEBOOST iBTW41 Manual de usuario

iHome

iHome iBT16 Manual de usuario

Manuales populares de Oradores de otras marcas

argon audio

argon audio IE20 Manual de usuario

Denon

Denon SC-N7 Manual de usuario

Gemline

Gemline Ace 3952 Manual de usuario

Focal

Focal ON WALL 300 Manual de instrucciones

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manual de usuario

SoundLogic

SoundLogic BCCS-6/6395 Manual de usuario

Peavey

Peavey DTH 218 Manual de usuario

Avantree

Avantree Pluto Air Manual de usuario

Morel

Morel Integra Series INTEGRA OVATION 4 Manual de usuario

Oppo

Oppo SONICA Manual de usuario

Bose

Bose SoundLink Wireless Music System Manual de usuario

Rocksteady

Rocksteady Stadium Manual de usuario

Bowers & Wilkins

Bowers & Wilkins 4 Manual de usuario

Sonance

Sonance SONOS OUTDOOR Series Manual de usuario

Electro-Voice

Electro-Voice EVID FM4.2 Manual de usuario

Pioneer

Pioneer XW-HTD630 Manual de usuario

Onn

Onn BWA16AA002 Manual de usuario

HP GL313AA - USB Speakers PC Multimedia Manual de usuario

iHome iZBT5 Manual de usuario

Manuales populares de Oradores de otras marcas
