iHome IH-K220CB Manual de usuario
user manual
IH-K220CB
wireless multimedia keyboard &
optical mouse Congratulations on the purchase of your
new wireless multimedia keyboard &
optical mouse. This product comes with a
limited lifetime warranty.
Before using your product, please thoroughly
read and follow the instructions inside this
manual.
If you still need help, see the back page for
other support options.
If you want to know more about our
products, visit us online at
www.life-works.com.
system requirements
Windows• ®2000, XP or Windows Vista®
USB port•
CD-ROM drive•
your package should contain
2
user manual contents
features•2
yournewkeyboard•3
yournewmouse•4
connecthardware•4
installsoftware•6
productoperatingtips•9
troubleshooting•10
features
plug-n-play—no synching needed•
12internetandmedialaunchkeys•
5-button optical mouse•
programmable keyboard and mouse•
buttons
user manual
(in your hands right now)
installation CD
wireless multimedia
keyboard
wireless
optical mouse
mini USB receiver
4 AAA DURACELL®
batteries
user manual
.
3
your new keyboard
application
buttons media
buttons
media player
mute
volume up
volume down
play/pause
stop
sleep
homepage
email
favorites
calculator
my computer
numlock
capslock
scroll lock
LED
indicators
4
your new mouse
scroll
wheel
programmable
buttons
connect hardware
Insert 2 AAA batteries into the keyboard battery1.
compartment.
a. remove battery
compartment cover
b. insert rst battery
and slide all the way
to the left
c. insert second battery
5
Insert 2 AAA batteries into the mouse battery2.
compartment.
remove battery
compartment
cover
bottom view of mouse
b. insert batteries
a.
Connect the mini USB receiver to an available USB3.
port on your computer. The keyboard and mouse
automatically connect to the mini USB receiver.
connect to a
USB port on
your computer
Start using your keyboard and mouse.4.
To set up the advanced functions of your keyboard, install
the supplied software.
6
install software
Insert the installation CD into your computer.1.
On the screen that appears, click2. install.
wireless multimedia keyboard &
optical mouse
www.life-works.com
2008© LifeWorks Technology Group LLC.
iHome™ is a trademark of SDI Technologies Inc.
used under license.
Model # IH-K220CB
exitinstall
An3. InstallShield Wizard dialog box displays. Click Next.
The4. Choose Destination Location dialog box displays.
Click Next to accept the default installation location.
click
Once the installation is complete, restart the computer5.
when prompted.
When the computer restarts, the mouse and keyboard
icons display in the system tray.
With the software installed, you can customize four of the
buttons on your keyboard, or the programmable mouse
buttons on the side of your mouse, or you can change
settings for the scroll wheel.
7
to customize the keyboard
Your keyboard has four programmable application buttons.
application
buttons
programmable
buttons
programmable
button
media
buttons
You can change the functions of the four
notef
programmable buttons on the keyboard to launch
a variety of programs. The remaining multimedia
and applicatiom buttons on your keyboard are pre-
programmed with default settings (shown in “your new
keyboard” on page 3) and cannot be changed.
Double-click the1. keyboard icon in the system tray.
To change the action for a programmable button, click2.
the corresponding icon.
Select3. Choose a function, then select an application from
the drop-down list.
a. click b. select application
c. click
8
To have the button run an application not included in the4.
list, select the Select a program option, then click Browse
to navigate to the desired application.
Click5. OK to accept the changes.
a. click b. browse for program
c. click
to customize the mouse buttons
Double-click the1. mouse icon in the system tray.
This opens a dialog box.
Select the2. Cong of mouse button tab.
Click the drop-down list to select an action for each3.
button. Drag the slider to set the double-click speed (how
fast you have to click to produce a double-click).
Click4. OK to accept the changes and exit.
drop-down
lists
drag speed
slider
9
to customize the mouse scroll wheel
Double-click the1. mouse icon in the system tray.
Select the2. Cong of the mouse wheel tab.
Select3. Speed of wheel scroll and choose how many
lines should scroll when the wheel is rotated one click, or
select For Pages to scroll a whole page with each click.
To set the mouse wheel to adjust the audio volume
instead, select Adjust of the volume and adjust the slider
to determine how fast the volume changes when you
rotate the wheel.
Click4. OK to accept the changes and exit.
audio volume
option
scroll options
product operating tips
Your keyboard and mouse will operate from as far away•
as30ft.(10m)fromyourcomputer.
Customize the programmable buttons on your keyboard•
and mouse for greater functionality.
The scroll wheel is also a button. Press the scroll wheel•
(without rolling it) to automatically scroll a document or
web page, then move your mouse up or down to set the
automatic scroll speed.
10
troubleshooting
situation try this
keyboard or
mouse does
not work at
setup
Ensure the mini USB receiver is connected.•
Move the mouse or keyboard closer to the•
mini USB receiver.
Check that batteries are inserted correctly in•
the battery compartment for the keyboard or
mouse.
Disconnect the mini USB receiver, then•
reconnect it.
Connect the mini USB receiver to a different•
USB port. Try a USB port on the computer,
not a USB hub.
keyboard
or mouse
has stopped
working
Check that the batteries are good. If•
necessary, replace the batteries.
Ensure the optical sensor on the mouse is•
clean.
