iGenix IG9802 Manual de usuario
Please read these instructions carefully before use and retain for future reference
Before switching on your appliance,
always check for any damage which may have been caused in transit
IG9802
Batch code:
600ml Portable Compact Air Dehumidier
USER MANUAL
2
CONTENTS
Important Safety Instructions...............................................3-4
Intended Use................................................................................5
Specication .................................................................................5
Appliance Overview...................................................................6
Control Panel...............................................................................7
Operating Instructions...............................................................8
Using the Timer ...........................................................................8
Continuous Drainage .................................................................9
Cleaning and Maintenance ..................................................... 10
Trouble Shooting Guide.......................................................... 11
Fuse & Mains Plug Replacement ........................................... 11
Disposal Information............................................................... 12
Terms and Conditions and Warranty Information...... 14-15
3
IMPORTANT SAFETY INSTRUCTIONS
Read and follow all of the instructions even if you feel you are familiar
with the product, and nd a place to keep this manual handy for future
reference.
Important: This appliance is intended for use in a domestic
environment only.Any other use is not recommended by the manufacturer
and may cause re, electrical shocks or other injury to user or property.
When using electrical appliances, basic safety precautions should always be
followed:
• It is recommended that you only use the mains adapter supplied with
this unit.
• Do not operate the appliance with a damaged cord or plug; after it
malfunctions or has been dropped or damaged in any way.All electrical
repairs must be carried out by a qualied electrician. Inadequate
repairs may result in a major source of danger for the user and
invalidate the warranty.
• Ensure hands are not wet when inserting the plug into the power
socket.
• Do not use in the following locations:-
• Next to a source of re.
• An area where oil is likely to splash.
• An area exposed to direct sunlight.
• An area where water is likely to splash.
• Near a bath, shower or a swimming pool.
• In a greenhouse.
• An area where ammable gases or liquids are present.
• Appliance should be placed on a at level surface and should not be
tipped to either side when there is water in the tank.
• This appliance can be used by children aged from 8 years and above if
they have been given supervision or instruction concerning the use of
the appliance in a safe way and understand the hazards involved.
• Cleaning and maintenance shall not be made by children.
• Keep the appliance and its cord out of reach of children.
• Children should not play with the appliance.
4
• This appliance can be used by persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
• Never insert your ngers or any foreign objects into the air outlet.
Take special care to warn children of these dangers.
• Do not cover the unit or place any heavy objects on top of it.
• Do not obstruct the air inlets/outlets of the appliance.
• Ensure that there is at least a 20cm clearance around the appliance
whilst it is in use
• When appliance is not being used for an extended period of time,
unplug from the power socket and ensure the water tank is drained
before storing in a dry and well ventilated area.
5
SPECIFICATION
Model No: IG9802
Dehumidifying Capacity 600ml /Day (30°C RH80%)
Voltage 12V DC
Frequency 50 Hz
Rated Input Power 70W
Water Tank Capacity 1.8L
Operating Temperature 0°C - 40°C
Noise Level ≤30dB(A)
Rated Input Current 0.32A
Product Dimensions (mm) (H)330 x (W)210 x (D)155
This lightweight portable Compact Air Dehumidier helps to prevent build-up
of mould and mildew by removing excessive moisture from the atmosphere.This
dehumidier is ideal for use around the home, kitchen, bedroom, garage or basement,
as well as caravans or other small areas between 1-10m².
Air always contains a certain amount of water in the form of water vapour.This is
known as humidity. The capacity of the air to hold water vapour increases with the
temperature.This is why in our homes, as soon as the temperature decreases, the
vapour contained in the air condenses leaving moisture on the colder surfaces in the
room such as the windows and the walls etc.
The purpose of the dehumidier is to remove the excess moisture from the air to
control the condensation in the home.The optimum environmental conditions for
the home are between 40% and 60% Relative Humidity (RH).
Below these levels the air can feel too dry and may cause skin complaints and create
static.
If temperatures in the home are below 10°C for prolonged periods, low level
heating will be necessary to allow the condensation to evaporate into the air before
dehumidication can take place. The air will however be slightly warmed by the
dehumidier as the dry air leaving the dehumidier is between 1°C to 4°C higher
than ambient room temperature.
INTENDED USE - Purpose of a Dehumidier
6
APPLIANCE OVERVIEW
Water Tank
Control Panel
Air Outlet
Handle
Air Filter
Drainage Plug
Power Interface
7
Control Panel
Illuminating LED Display
Shows Relative Humidity and
time setting
Power Button
Press to turn On/Off
Timer Button
Press to adjust time
until appliance turns on
or off.
Press and hold for
5 seconds to briey
display the current
room temperature
Ioniser Indicator
Lights up to indicate that the
ioniser function is working
Dehumidifying Indicator
Lights up to indicate that the
unit is working
Water Tank Indicator
Lights up to indicate that the
water tank is full
8
OPERATING INSTRUCTIONS
• Plug the mains adaptor in to the back of the appliance and ensure that the
water tank is correctly positioned.
• Insert the plug into a mains socket.
• The LED display will show “- -“ when the unit is in stand-by mode.
• Press the power button to turn on the dehumidier – the dehumidify indicator
and the air purify indicator will light up, and the LED display will show the
humidity level of the room.
Note: If the water tank is not correctly positioned the indicator lights will not
illuminate.
• Once the water tank is full, the water tank indicator will light up and the
dehumidication will stop automatically.
• Turn off the power supply, then take out the water tank and remove the drain
cover to discard the collected water.
• Wipe and dry both the water tank and the dehumidier before inserting the
tank back into the unit to recommence dehumidication.
Using The Timer Function
• When the dehumidier is in stand-by mode, the timer button may be used to
set the desired time before the unit automatically switches on.
• Press the timer button once for each hour until the desired time is shown on
the LED display.The timer can be set between 1-24 hours.
• The dehumidier will automatically turn on and commence dehumidication
once the set time has been reached.
• When the dehumidier is powered on, the timer button may be used to set
the desired time before the unit automatically switches to stand-by mode.
• Press the timer button once for each hour until the desired time is shown on
the LED display.The timer can be set between 1-24 hours.
• The dehumidier will automatically turn to stand-by once the set time has
been reached.
Note: If the water tank reaches full capacity before the set time, the machine
will stop dehumidication automatically.
9
Continuous Drainage
If you would like to use the dehumidier over a long period of time whilst away from
the home, you can use the continuous drainage feature.
• Remove Drainage Plug from the back of the appliance
• Connect the drainage hose (supplied) into the drainage point of the
dehumidier.
• Feed other end of the drainage hose into a suitable drainage point.
Note: When using the continuous drainage feature, the hose must be placed below
the drainage outlet without knots or kinks.
Note: When the continuous drain feature is not being used, remove the drain
hose from the drainage point, insert drainage plug, and ensure water tank is installed
correctly.
10
CLEANING AND MAINTENANCE
Always switch off the unit and unplug from the mains socket before cleaning or
performing any maintenance.When not in use for long periods it is also advisable to
remove the plug from the power socket.
Wipe the outside of the unit with a soft damp cloth.You may use a mild detergent
if necessary. Dry with a cloth. Do not use any harsh abrasives or solvents. Never
immerse this appliance in water or any other liquid.
The water tank should be cleaned every few weeks to prevent growth of mould,
mildew and bacteria. Partially ll the tank with clean water and add a little mild
detergent. Swish it around and then empty the tank and rinse.
Note: After cleaning and drying the tank, it must be reinserted securely into
dehumidier in order to restart operation.
Cleaning The Air Filter
This unit is equipped with an air lter. To ensure longevity and efciency of the
dehumidier, it is recommended that the lter is cleaned regularly
• Turn off the appliance and unplug
from the power supply
• Use the lip below the lter to
remove the lter bracket from the
back of the appliance
• Remove the lter from the bracket
• Clean the lter under a tap using
warm, soapy water. Ensure that
the lter is completely dry after
cleaning
• Place the lter back into the
bracket, ensuring it is securely in
place.
• Replace the lter bracket into the
back of the dehumidier
