IDTECK Star 100R Manual de usuario

Quick Installation Guide

100R

IP100R

Quick Installation Guide

Table of Contents

1. SAFETY INFORMATION ............................................................................................. 3

2. IDENTIFYING SUPPLIED PARTS ................................................................................... 6

3. WALL MOUNT INSTALLATION ..................................................................................... 7

4. WIRE COLOR TABLE ................................................................................................ 9

5. WIEGAND OUTPUT FUNCTION ..................................................................................10

6. RECOMMENDED CABLE TYPE AND PERMISSIBLE LENGTH..................................................11

7. REVERSE DIODE CONNECTION ..................................................................................11

8. SYSTEM WIRING FOR TYPICAL APPLICATION .................................................................12

9. SYSTEM INITIALIZATION ..........................................................................................16

10. FCC REGISTRATION INFORMATION ...........................................................................18

11. ONLINE RMA POLICY & FREE SERVICE CRITERIA...........................................................19

Quick Installation Guide

1. SAFETY INFORMATION

CAUTION

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER

(OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

WARNING

To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

WARNING

1. Be sure to use only the standard adapter that is specified in the specification sheet. Using any other

adapter could cause fire, electrical shock, or damage to the product.

2. Incorrectly connecting the power supply or replacing battery may cause explosion, fire, electric shock,

or damage to the product.

3. Do not connect multiple controllers to a single adapter. Exceeding the capacity may cause abnormal

heat generation or fire.

4. Securely plug the power cord into the power receptacle. Insecure connection may cause fire.

5. When installing the controller, fasten it securely and firmly. The fall of controller may cause personal

injury.

6. Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers filled with

water on top of the controller. Doing so may cause personal injury due to fire, electric shock, or falling

objects.

7. Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or electric shock.

8. If any unusual smells or smoke come from the unit, stop using the product. In such case, immediately

disconnect the power source and contact the service center. Continued use in such a condition may

cause fire or electric shock.

9. If this product fails to operate normally, contact the nearest service center.

Never disassemble or modify this product in any way. (IDTECK is not liable for problems caused

by unauthorized modifications or attempted repair.)

10. When cleaning, do not spray water directly onto parts of the product. Doing so may cause fire or

electric shock.

Quick Installation Guide

CAUTION

1. Do not drop objects on the product or apply strong blows to it. Keep away from a location subject to

excessive vibration or magnetic interference.

2. Do not install in a location subject to high temperature (over 50°C), low temperature (below -30°C), or

high humidity. Doing so may cause fire or electric shock.

3. If you want to relocate the already installed product, be sure to turn off the power and then move or

reinstall it.

4. Remove the power plug from the outlet when there is a lighting storm. Neglecting to do so may cause

fire or damage to the product.

5. Keep out of direct sunlight and heat radiation sources. It may cause fire.

6. Install it in a place with good ventilation.

7. Avoid aiming the controller directly towards extremely bright objects such as sun.

8. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as

vases, shall be placed on the apparatus.

9. The Mains plug is used as a disconnect device and shall stay readily operable at any time.

Continued on next page.

Quick Installation Guide

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such as radiators, heat registers, or other apparatus

(including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug.

A polarized plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong is provided for your safety.

If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete

outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the

apparatus.

13. Unplug this apparatus when a card is used. Use caution when moving the cart/apparatus combination

to avoid injury from tip-over.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been

damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate

normally, or has been dropped.

Quick Installation Guide

2. IDENTIFYING SUPPLIED PARTS

Check all components in the gift box when purchasing.

Contact the vendor where you purchased the product if any components are missing.

Quick Guide (1copy)

Wall Mount (1ea)

Master Card (1ea)

Main Unit (1ea)

6.0x30mm

Anchor Bolt(4ea)

O-Ring (5ea)

3.5x40mm Screw (4ea)

3.5x12mm Screw (4ea)

10Pin Cable (1ea)

7Pin Cable (1ea)

3Pin Cable (1ea)

2Pin Cable (1ea)

Diode (2ea)

Quick Installation Guide

3. WALL MOUNT INSTALLATION

1. Use the provided template to drill two 6-32 holes and one 1/2" hole on the proper location of the wall

to mount the Wall Mount bracket as shown below.

2. Install wall mount to the wall using 2 screws.

3. Insert 5 O-rings to the wall mount as indicated, then route the cable of the main unit through the center

hole and push the main unit to wall mount to lock the main unit and make sure that the main unit is

locked with wall mount.

Continued on next page.

Quick Installation Guide

※CAUTION

1. Before mounting the 100R unit to the Wall Mount bracket, operational testing of the unit should be

completed, as the locking pins will lock the unit to the Wall Mount. Removing the unit from the Wall

Mount bracket after they have been installed together may cause damages to the bracket and render

its effectiveness.

2. When installing a reader on a metal plate.

The read range may get reduced if the reader is installed on a metal surface.

To prevent such a read range reduction, install standoffs between the metal surface and the reader.

3. When installing more than 2 readers side by side or back to back

The read range may get reduced if more than 2 readers are installed side by side or back to back.

Also, when a card is presented to one of the readers, the other reader may wrongly recognize the card

as well. To prevent such interference, make sure the distance between readers is at least 20cm.

Quick Installation Guide

4. WIRE COLOR TABLE

I/O PORT NAME

SIGNAL NAME

COLOR CODE

2-PIN

Main Power (+12V)

DC +12V

Red

Power Ground

GND

Black

10-PIN

Door Relay (NC)

NC (1)

Blue (White Stripe)

Door Relay (COM)

COM (1)

Gray (Red Stripe)

Door Relay (NO)

NO (1)

White (Red Stripe)

Alarm Relay (NC)

NC (2)

Purple (White Stripe)

Alarm Relay (COM)

COM (2)

White

Alarm Relay (NO)

NO (2)

Purple

Exit Button

EXIT

Orange

Door Sensor

CONTACT

Yellow (Red Stripe)

Aux Input 1

INPUT #1

Green

Aux Input 2

INPUT #2

Green (White Stripe)

7-PIN

Wiegand Data 0

DATA 0

Pink

Wiegand Data 1

DATA 1

Cyan

TTL Output

TTL1 / D0

Orange (White Stripe)

Chime Bell Output

CHI / D1

Brown (White Stripe)

Aux Input 3

INPUT #3

Green (Red Stripe)

Reserved

N/A

Blue (Red Stripe)

Reserved

N/A

Yellow (White Stripe)

3-PIN

CON2

Ground

GND

Black

Reserved

N/A

Reserved

N/A

Quick Installation Guide

5. WIEGAND OUTPUT FUNCTION

The default output format of 100R/IP100R is TTL and Chime Bell output. But, you can configure the

100R/IP100R to generate output in Wiegand format and use it like a reader.

(The 100R/IP100R can output data from card reading, but can’t output data from keypad input.)

If you want to generate Wiegand instead of TTL output format, follow the table below.

Note: This function is only applicable to: 100R v6.00 or later / IP100R v3.00 or later.

SW1 #1

SW1 #2

SW2 #1

SW2 #2

Orange Cable

(White Stripe)

Brown Cable

(White Stripe)

OFF

TTL OUTPUT

Chime Bell Output

OFF

Wiegand Data 0 Out

Wiegand Data 1 Out

Note: When the Wiegand Output function is used, TTL Output wire is changed to Wiegand Data 0 and

Chime Bell Output wire to Wiegand Data 1 Output wire.

Therefore, you can’t use those functions. In addition, because TTL Output wire is changed to Wiegand

Data 0 Output, you can’t initialize the 100W/IP100W using the wires.

(You can use those functions again when setting SW1 and SW2 to the default state.)
