ICOP Technology Vega86-6240 Manual de usuario
Vega86-6240
VIA Mark CoreFusion 533MHz
EBX CPU Module
with 6S/2USB/GPIO/VGA/LCD/AUDIO/2LAN/CF
256MB SDRAM Onboard
User’s Manual
(Revision 1.1A)
ii
Copyright
The information in this manual is subject to change without notice for continuous improvement in
the product. All rights are reserved. The manufacturer assumes no responsibility for any
inaccuracies that may be contained in this document. And makes no commitment to update or to
keep current the information contained in this manual.
No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part,
in any form or by any means without the prior written permission of the ICOP Technology Inc.
Copyright 2007 ICOPTechnology Inc.
Manual No. IUM6240000-01 Ver.1.0A April, 2007
Manual No. IUM6240000-01 Ver.1.1A December, 2007
Trademarks Acknowledgment
Vega86is the registered trademark of ICOP Technology Inc.
Other brand names or product names appearing in this document are the properties
and registered trademarks of their respective owners. All names mentioned herewith
are served for identification purpose only.
iii
T a b l e o f C o n t e n t s
T ab l e o f C o n t e nt s.............................................................iii
C h a p t e r 1 Introduction……………………………………………1
1.1 Packing List............................................................1
1.2 Product Description................................................2
1.3 Specification...........................................................3
1.4 Board Dimension....................................................5
C h a p t e r 2 Installation……………………………………………..6
2.1 Board Outline.........................................................6
2.2 Connectors & Jumpers Location............................8
2.3 Connectors & Jumpers Summary...........................9
2.4 PinAssignments &Jumper Settings......................11
2.5 System Mapping...................................................23
C h a p t e r 3 Driver Installation……………………………………25
Appendix ………………………………………………………………..26
A. STN Flat Panel Data Output......................................26
B. TFT Flat Panel DataOutput.........................................27
C. Flat Panel BIOS Setting............................................29
D. Flat Panel Wiring and lighting………………………….31
Warranty............................................................................................32
Vega86-6240 Vega86EBX CPU Module 1
C h a p t e r 1
Introduction
1.1 Packing List
Product Name Package
Vega86-6240
Embedded Vega86 CPU All-in-One Board
Manual & Drivers CD x 1
RS232 cable x6
VGA cable x1
PRINTER cable x1
AUDIO cable x 3
FDD cable x 1
IDE cable x 1
USB cable x 1 (USB port x 2)
PS/2 Mouse cable x 1
PS/2 Keyboard cable x 1
Vega86-6240 Vega86EBX CPU Module 2
1.2 Product Description
The Vega86 Single-Board-Computer series (powered by VIA Mark CoreFusion processor) offers
high performance, cost-effectiveand energy efficient processor with integrated ProSavage4 SA
graphics controller, which is the powerful embedded x86 platform for Windows XP Embedded,
WEPOS, and embedded Linux application.
The complete board consists of the Mark CoreFusion processor and the VT82C686B PCI-ISA
South Bridge, Realtek RTL8100B 10/100 Fast Ethernet Controller, etc. The processor integrates
VIA’s high-performance ProSavage4 3D / 2D graphics controller, LCD and Flat Panel display
interfaces, with further superior performance between the CPU, SDRAM and PCI bus with
pipelined, burst, and concurrent operation. The South Bridge is PC98 / PC99 compliant with
integrated UltraDMA-100/ 66 / 33 IDE, 2 (or 3) USB (1.1) ports, Super-I/O functions (floppy disk
drive interface and serial / parallel ports), and AC-97 link supporting digital audio functions.
The Vega86 SBC supports SDRAM up to 256MB. As to the DRAM controller, it meets the
standard PC133 Synchronous DRAM (SDRAM). The Synchronous DRAM interface allows zero
wait state bursting between the SDRAM and the data buffers at 133MHz.
The Vega86 SBC integrates S3 Graphics and 128-bit ProSavage4 graphics accelerators that
bring mainstream graphics performance to the Value PC with leading-edge 2D, 3D and DVD
video acceleration into a cost effective package.Vega86 SBC also combines the industry’s first
integrated AGP 4X solution with Microsoft Direct-X texture compression and massive 2Kx2K
textures to deliver unprecedented 3D performance and image quality for the Value PC mobile
market.
Vega86 SBC’s South Bridge supports four levels (doubleword) of line buffers, DMA transfers and
delay transaction to allow efficient PCI bus utilization and (PCI-2.2 compliant). The VT82C686B
also includes anintegrated Super I/O, integrated DS12885 style real time clock with extended
256 byte CMOS RAM, integrated master mode enhanced IDE controller with full scatter / gather
capability, integrated two (or three) USB (1.1) interface with root hub and two function ports with
built-in physical layer transceivers, Distributed DMA support and integrated AC-97 link for basic
audio functions.
Regarding the network architecture application, Vega86 SBC equips with the Realtek RTL8100B,
which is a highly integrated, cost-effective single-chip Fast Ethernet controller able to provide
32-bit performance, PCI bus master capability, and full compliance with IEEE 802.3u
10/100Base-T specifications and IEEE 802.3x Full Duplex Flow Control.
Vega86-6240 Vega86EBX CPU Module 3
1.3 Specification
Features Vega86-6240
CPU VIA Mark CoreFusion 533MHz
Chipset VIA VT82C686B
BIOS AMI BIOS
System Memory 256 MB SDRAM onboard
Cache L1:64KB L2:64KB
Bus Interface PC/104 Standard Compliant (Optional: PCI-104)
Watchdog Timer None
VGA
Integrated 2D/3D AGP4X graphics with MPEG2
Accelerator, Shared system memory 8M/16M/32M
VGA, SVGA, XGA, SXGA and DSTN/TFT Flat Panel
interface support
LAN
Realtek 8100B 10/100Mbps Ethernet Controller
Half/Full duplex capability
Audio
VIA VT1612A AC97 Codec
Full compatible with AC97 2.2 version
I /O Interface Enhanced IDE port (UltraDMA-100/66/33) x1
RS232 port x4
RS232/485 port x2 (RS485 with Auto Direction)
Parallel port x1
FDD port x1
USB port x2 (USB 1.1 version)
16-bit GPIO port x1
10/100Mbps Ethernet port x2
Vega86-6240 Vega86EBX CPU Module 4
Connectors
2.54mm 40-pin box header for IDE x1
2.54mm 34-pin box header for FDD x1
2.54mm 26-pin box header for Printer x1
2.54mm 10-pin box header for RS-232 x6
2.54mm 3-pin header for RS-485 x2
2.54mm 2-pin header for Reset x1
2.54mm 10-pin box header for USB (2 USB ports) x1
2.54mm 20-pin box header for 16-bit GPIO x1
2.54mm 5-pin box header for keyboard x1
2.54mm 5-pin header for Mouse x1
2.0mm 44-pin box header for LCD x1
2.0mm 4-pin wafer for Line-in/Line-out/MIC-in x3
3.96mm 7-pin Male Power Connector x1
0.8mm 124-pin MiNi PCI connector x1
External RJ-45 LAN connector x2
Type I/II Compact Flash slot x1
Flash Disk Support
40-pin IDE Flash Disk( EmbedDisk 16MB or above)
Type I/II CF Card
Power Requirement Single Voltage +5V @2.5A
Dimension 146 X 203mm (5.75 x 8 inches)
Weight 310g
Operating
Temperature -20oC ~ +60oC
Vega86-6240 Vega86EBX CPU Module 5
1.4 Board Dimension
Vega86-6240 Vega86EBX CPU Module 6
C h a p t e r 2
Installation
2.1 Board Outline
Vega86-6240 Vega86EBX CPU Module 7
To guarantee the stability & maximum performance of original design, Vega86-6240
must be used with the manufacturer designated passive heat sink shown as below
photo.
(Note1: PCI-104 Connector is optional)
