Ice-O-Matic ICE0320A4 Guía
22 INCH WIDE ICE SERIES CUBERS
SERVICE PARTS MANUAL
MODEL-ICE0320A4/W4 and ICE0520A4/W4
Includes 50Hz. Units
Ice-O-Matic
11100 East 45th Ave
Denver, Colorado 80239
Part Number 9081356-02 Date 4/09
SERVICE PARTS MANUAL
22 INCH WIDE ICE SERIES CUBERS
MODEL-ICE0320, ICE0520
Includes 50Hz. Units
ICE-O-Matic
11100 East 45th Ave
Denver, Colorado 80239
Part Number 9081297-01 PD04/02 Rev1/05
ICE0320/0520 Service Parts Table of Contents
This parts list contains the service parts available for the following icemakers:
ICE0320*A4
ICE0320*W4
ICE0325*A4
ICE0520*A4
ICE0520*W4
ICE0525*A4
Check the model number on the data plate and refer to the correct listing for the specific component.
Check carefully that the correct part is identified and ordered.
Table of Contents Page 1
Cabinet Exterior Page 2
ICE0320/ICE0520 Air Cooled Page 3
ICE0320/ICE0520 Water Cooled Page 4
Evaporator Page 5
Control Box Page 6
Fan Assemblies Page 7
Harvest Assist Components Page 8
Water Pump/Float Page 9
Ice-O-Matic
11100 East 45th Ave.
Denver Co. 80239
800-423-3367
Page 1
ICE0320/0520 Series Service Parts Exterior Panels
Page 2
Item
No. ICE0320 ICE0325 ICE0520 ICE0525 Description
1 2101431-01S 2101431-01S 2101431-01S 2101431-01S Top Panel
2 2031511-04S 2031511-04S 2031511-04S 2031511-04S Front Panel
3 9031098-04 9031098-04 9031098-04 9031098-04 Front Panel Screw
4 9051562-06 9051562-06 9051562-06 9051562-06 Front Panel End Cap Left Side
5 9051562-05 9051562-05 9051562-05 9051562-05 Front Panel End Cap Right Side
6 2101436-01 2101436-01 2101436-01 2101436-01 Left Hand Side Panel
7 9051565-06 N/A 9051565-06 N/A Right Hand Side Panel ( Non-Louvered, Water Cooled)
8 2101428-03 2101428-03 2101428-03 2101428-03 Right Hand Side Panel ( Louvered, Air Cooled)
9 3021942-01 3021942-01 3021942-01 3021942-01 Rear Panel (Air Cooled)
9 3021943-01 3021943-01 3021943-01 3021943-01 Rear Panel (Water Cooled)
10 9031046-01 9031046-01 9031046-01 9031046-01 Rear Panel Screws
11 3012974-01 3012974-01 3012974-01 3012974-01 Control Box Cover
12 N/
A
3013107-01 N/
A
3013107-01
A
ccess Panel (50 hz. Only, Not Shown
)
Model Number
Page 2
ICE0320/0520 Series Service Parts Air Cooled
Page 3
Item
No. ICE0320 ICE0325 ICE0520 ICE0525 Description
1 9181121-11 9181122-11 9181121-11 9181127-11 Compressor Kit-- See page 6 for Compressor Components
2 9151004-02 9151004-02 9151004-02 9151004-02 Filter Drier
3 9151154-01 9151154-01 9151149-01 9151149-01 Expansion Valve
4 9151123-01 9151123-01 9151123-01 9151123-01 Hot Gas Valve Body
5 9151123-03 9151123-04 9151123-03 9151123-04 Hot Gas Valve Coil
6 9101124-02 9101124-02 9101124-02 9101124-02 Bin Switch
7 3012965-01 3012965-01 3012965-01 3012965-01 Side Brace
8 3012924-01 3012924-01 3012924-01 3012924-01 Ice Deflector
9 2021690-01 2021690-01 2021690-01 2021690-01 Front Frame Panel
10 9091086-03 9091086-03 9091086-03 9091086-03 Service Valve Cap
11 9091086-02 9091086-02 9091086-02 9091086-02 Service Valve Core
12 9041098-01 9041098-01 9041098-01 9041098-01 High Temperature Safety Control
13 9031161-01 9031161-01 9031161-01 9031161-01 Nylon Wing Nut
14 3012974-01 3012974-01 3012974-01 3012974-01 Control Box Cover
15 9051478-01 9051478-01 9051478-01 9051478-01 Water Pan
16 9041086-04 9041086-05 9041086-04 9041086-05 Purge Valve
17 9041091-01 9041091-01 9041091-01 9041091-01 High Pressure Control
18 9041096-01 9041096-01 9041096-01 9041096-01 Fan Cycle Control
Model Number
Page 3
ICE0320/0520 Series Service Parts Water Cooled
Page 4
Item
No. ICE0320 ICE0325 ICE0520 ICE0525 Description
1 9181121-11 N/A 9181121-11 N/A Compressor Kit-- See page 6 for Compressor Components
2 9151004-02 N/A 9151004-02 N/A Filter Drier
3 9151154-01 N/A 9151149-01 N/A Expansion Valve
4 9151123-01 N/A 9151123-01 N/A Hot Gas Valve Body
5 9151123-03 N/A 9151123-03 N/A Hot Gas Valve Coil
6 9101124-02 N/A 9101124-02 N/A Bin Switch
7 3012965-01 N/A 3012965-01 N/A Side Brace
8 3012924-01 N/A 3012924-01 N/A Ice Deflector
9 2021690-01 N/A 2021690-01 N/A Front Frame panel
10 9091086-03 N/A 9091086-03 N/A Service Valve Cap
11 9091086-02 N/A 9091086-02 N/A Service Valve Core
12 9041098-01 N/A 9041098-01 N/A High Temperature Safety Control
13 9031161-01 N/A 9031161-01 N/A Nylon Wing Nut
14 3012974-01 N/A 3012974-01 N/A Control Box Cover
15 9051478-01 N/A 9051478-01 N/A Water Pan
16 9041086-04 N/A 9041086-04 N/A Purge Valve
17 9041091-01 N/A 9041091-01 N/A High Pressure Control
18 9141121-01 N/A 9141121-01 N/A Water Cooled Condenser
19
9041059
-
01
N/A
9041059
-
01
N/A
Water Regulating Valve
Model Number
19
9041059
-
01
N/A
9041059
-
01
N/A
Water
Regulating
Valve
Page 4
ICE0320/0520 Series Service Parts Evaporator
Page 5
Item
No. ICE0320 ICE0325 ICE0520 ICE0525 Description
1 2051222-01S 2051222-01S 2051232-01S 2051232-01S Evaporator-Full Cube
1 2051222-02S 2051222-02S 2051232-02S 2051232-02S Evaporator-Half Cube
3 2101387-01S 2101387-01S 2101355-04S 2101355-04S Curtain
4 2041338-02 2041338-02 2041338-02 2041338-02 Water Distribution Tube
5 9031122-01 9031122-01 9031122-01 9031122-01 Thumb Screw
6 9031004-19 9031004-19 9031004-19 9031004-19 Washer
7 3012747-01 3012747-01 N/A N/A Curtain Stopper Clip
8 9131413-01 9131413-01 9131413-01 9131413-01 Insulation
9 2021651-01 2021651-01 2021651-01 2021651-01 Divider Panel
10 9051135-05 9051135-05 9051135-05 9051135-05 Evaporator Spillway
11 9051136-08 9051136-08 9051136-06 9051136-06 Evaporator Right Side Mounting Panel
12 9051136-07 9051136-07 9161136-05 9161136-05 Evaporator Left Side Mounting Panel
13
9051135
-
04
9051135
-
04
9051135
-
04
9051135
-
04
Evaporator Water Return
Model Number
13
9051135
-
04
9051135
-
04
9051135
-
04
9051135
-
04
Evaporator
Water
Return
Page 5
ICE0320/0520 Series Service Parts Control Box
Page 6
Item
No. ICE0320 ICE0325 ICE0520 ICE0525 Description
1 9101083-01 9101083-01 9101083-01 9101083-01 Relay Socket
2 9101084-01 9101084-02 9101084-01 9101084-02 Relay
3 9101037-01 9101037-01 9101037-01 9101037-01 Terminal Board
4 9101195-01 9101195-01 9101195-01 9101195-01 On-Off Wash Switch
5 9101139-03 9101139-03 9101139-03 9101139-03 Purge Switch
6 9181003-09 9181003-40 9181003-09 9181003-45 Start Capacitor
7 9181004-27 9181010-26 9181004-27 9181010-30 Compressor Relay
8 9041094-01 9041094-01 9041094-01 9041094-01 Low Pressure Control
9 9101148-01 9101148-01 9101148-01 9101148-01 Timer
10 9101002-07 9101002-06 9101002-07 9101002-06 Contactor
11 N/A 9181009-08 N/A 9181009-08 Run Capacitor
12 9041098-01 9041098-01 9041098-01 9041098-01 High Temp Safety (Not Shown)
13 9101218-11 9101218-11 9101218-11 9101218-11 Water Pump Cord (Not Shown)
ICE0320 ICE0325 ICE0520 ICE0525
9181121-01 9181122-01 9181121-01 9181127-01 Compressor
9181003-39 9181003-40 9181003-39 9181003-45 Start Capacito
r
N/A 9181009-08 N/A 9181009-08 Run Capacitor
9181004 27
9181010 26
9181004 27
9181010 30
Relay
Specific Compressor Components
Model Number
9181004
-
27
9181010
-
26
9181004
-
27
9181010
-
30
R
e
l
a
y
9181005-37 9181005-39 9181005-37 9181005-44 Overload
Page 6
ICE0320/0520 Series Service Parts Fan Assemblies
ICE0320/0325
Page 7
Item
No. ICE0320 ICE0325 ICE0520 ICE0525 Description
1 9141118-01 9141118-01 9141118-01 9141118-01 Air Condenser
2 3013111-01 3013111-01 2021613-01 2021613-01 Fan Shroud
3 9131384-08 9131384-04 9131384-04 9131384-04 Fan Blade
4 3013252-01 3013252-01 3013252-01 3013252-01 Fan Motor Bracket
5 9161078-01 9161078-02 9161112-01 9161078-02 Fan Motor
6 9091140-01 9091140-01 9091140-01 9091140-01 Drain Fitting
7 9091074-01 9091074-01 9091074-01 9091074-01 Drop Adapter
8 9091083-01 9091083-01 9091083-01 9091083-01 Water Inlet Fitting
Model Number
ICE0520/0525
Page 7
ICE0320/0520 Series Service Parts Harvest Assist
Page 8
Item
No. ICE0320 ICE0325 ICE0520 ICE0525 Description
1 3013170-01 3013170-01 3013170-01 3013170-01 Bracket, Probe Motor
2 9161030-01 9161031-01 9161030-01 9161031-01 Gear Motor
3 9131190-01 9131190-01 9131190-01 9131190-01 Clutch Assembly 180 Degree
4 9051001-13 9051001-13 9051001-13 9051001-13 Snap Bushing
5 9051001-03 9051001-03 9051001-03 9051001-03 Snap Bushing
6 9031019-08 9031019-08 9031019-08 9031019-08 #6-32 x 1/2 Fillister Head Screw
7 9051057-01 9051057-01 9051057-01 9051057-01 Connecting Rod
8 9021102-01 9021102-01 9021102-01 9021102-01 Probe, Single Length
9 9031003-03 9031003-03 9031003-03 9031003-03 Plain Flat Washer
10 9031119-01 9031119-01 9031119-01 9031119-01 Shoulder Screw
11 9051519-01 9051519-01 9051519-01 9051519-01 Spacer, Cam Switch
12 9101160-01 9101160-01 9101160-01 9101160-01 Cam Switch
13 3051145-02 3051145-02 3051145-02 3051145-02 Insulator, Switch
14 9031008-44 9031008-44 9031008-44 9031008-44 Pan Head Machine Screw
15 9031120-01 9031120-01 9031120-01 9031120-01 Speed Nut Plate
2061962
-
01S
2061962
-
02S
2061962
-
01S
2061962
-
02S
Complete Assembly
Model Number
2061962
-
01S
2061962
-
02S
2061962
-
01S
2061962
-
02S
Complete
Assembly
Page 8
