Technical Bulletin No. 48

December 2012

Wayne®IBM®SureMark™4610-TF6 printer

Troubleshooting Checklist

Printers gather paper dust and debris through normal use. Continued accumulation will eventually

cause erratic operation or prevent operation of the printer. It is important to blow out the dust

and debris. Canned compressed air is available at most computer stores such as Staples. Using

good quality paper (not recycled) will greatly reduce dust and extend the life of the printer. Paper

size: width 79.5 mm- outside roll diameter 80 mm.

The thermal print head will not print on paper that has glue on it. If your new paper roll is sealed

with glue, tear off 6 to 8 inches of paper before loading.

Printer ready indicator light is off. (See Figure 1)

Check that the printer power switch, which is located under the top cover, is set to “ON”

(see Figure 2).

Check all electrical connections and that the Point of Sale system is “ON”.

Printer ready indicator light is blinking

Check that the paper is loaded correctly. Close the cover and push the paper feed button.

Caution: Do not pull the receipt paper

Do not pull the receipt paper out of the printer with the top cover closed. This disengages

the paper feed. The paper feed motor must then catch up before the printer can feed the

paper, which causes missing lines or partial lines to print. Always use the paper feed button

on the outside of the case (see Figure 1) to advance the receipt and all lines will print.

Figure 1- Paper Feed Button

Paper feed button (blue triangle)

Use the button- Do Not Pull Paper!

Printer ready indicator light

Perform an Offline Printer Test

Performing an Offline Printer Test will help ensure the printer is operating correctly.

1. Open the top cover.

2. Press and hold the small blue or black paper feed button (see Figure 2) for 5 seconds.

The printer ready indicator light will make one quick flash followed by a pause. A beeper

may make a short single tone periodically.

3. Release the paper feed button.

4. Close the top cover.

5. The printer will print an Offline Printer Test (see Figure 3)

6. Check that the information printed is correct for your model and configuration.

7. To return to operation mode: lift the cover, turn the printer OFF and back ON by cycling

the power switch.

8. The printer ready indicator light should now be on continuously and ready for operation.

All manufacturers’ numbers, names, trade names, trademarks and descriptions used here are for reference purposes

only. None of the remanufactured items listed here are the products of the identified manufacturers. All registered

names and trademarks are the property of the manufacturer.

PMP CORPORATION Local: 860-677-9656

P.O. Box 422 • 25 Security Drive Toll Free: 800-243-6628

Avon, CT 06001 Toll Free Fax: 888-674-0196

E-mail: sales@pmp-corp.com Web: www.pmp-corp.com © PMP CORP.

Figure 2 – Location of Paper Feed

Button and Power Switch under cover.

Figure 3 – Offline Printer Test

Power Switch

Paper Feed

Button
