User's Guide

OPTIONS

UltraslimBay DVD Drive

First Edition (August 1998)

The following paragraph does not apply to the United Kingdom or any country where such provisions are inconsistent with local law:

INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT ANY WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE LIMITED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. Some states do not allow disclaimers or express or implied warranties in certain transactions; therefore, this statement may not apply

to you.

This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be

incorporated in new editions of the publication. IBM may make improvements or changes in the products or the programs described in this publication at any

time.

It is possible that this publication may contain reference to, or information about, IBM products (machines and programs), programming, or services that are not

announced in your country. Such references or information must not be construed to mean that IBM intends to announce such IBM products, programming, or

services in your country.

Requests for technical information about IBM products should be made to your IBM authorized dealer or your IBM marketing representative.

Note to U.S. Government Users — Documentation related to restricted rights — Use, duplication or disclosure is subject to restrictions set forth in GSA ADP

Schedule Contract with IBM Corp.

Contents

Part 1. Using the DVD Drive ................................................... 1-1

Installing the DVD Drive in the UltraslimBay ......... 1-2

Installing the Hot/Warm Swap Driver (ThinkPad 600 Only) .. 1-3

Installing the Display Driver (ThinkPad 600 Only) ....... 1-4

Installing Programs . . . . . . . . . . . . . . . . . . . . . . 1-6

Viewing a DVD Movie .................... 1-8

Part 2. Appendixes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Appendix A. Help and Service Information ......... 2-1

Step 1. Problem Solving . . . . . . . . . . . . . . . . . . . 2-1

Step 2. Preparing for the Call ................. 2-2

Step 3. Placing the Call to IBM ................ 2-2

Appendix B. Product Warranty . . . . . . . . . . . . . . . 2-3

Appendix C. Notices . . . . . . . . . . . . . . . . . . . . . 2-6

Part 1. Using the DVD Drive

The UltraslimBay DVD drive (hereafter called DVD drive) supports the

ThinkPad 600 series computer, including the 600 or 600E in the

Windows 95 or Windows 98 environment. To use the DVD drive in

your computer, you need to install the software programs after

inserting the DVD drive into the UltraslimBay. This book explains

how to install the DVD drive and software programs.

DVD Movie Playback

This UltraslimBay DVD drive is available for the ThinkPad 600E

and ThinkPad 600 systems. The ThinkPad 600E systems use the

Pentium II 300-MHz processor with the advanced graphics port

(AGP) and a video chip with motion compensation for DVD

movie playback. To view movies on a ThinkPad 600 model other

than the 600E model, you need a DVD adapter, such as a MARGI

Systems DVD-to-Go MPEG-2 DVD PCMCIA adapter. This

adapter takes advantage of the existing Zoom Video port on the

ThinkPad 600 system.

Before you begin the installation, make sure that the following items

are included in your option package:

DVD drive This user's guide

DVD Software CD-ROM

(includes software programs for

DVD movies)

Display Driver Diskette

(NM2160) for Windows 98/95

(includes the display driver)

Hot/Warm Swap Driver

CD-ROM (includes the hot/warm

swap driver)

Note: You can check which version of Windows 95 you are using by doing

the following:

1. Click on Start, move the cursor to Settings, and then click on

Control Panel.

2. Double-click on System.

Read the numbers under “System.”

4.00.950B means that it is Windows 95 OSR2.0 or OSR2.1.

4.00.950C means that it is Windows 95 OSR2.5.

Installing the DVD Drive in the

UltraslimBay

This section describes how to install the DVD drive. Before you

begin the installation, make sure that the DVD Software CD-ROM,

which includes software programs, was shipped with the DVD drive.

If a device is already installed in the UltraslimBay, go to “Removing a

Device from the UltraslimBay.”

If no device is installed, go to “Installing the DVD Drive in the

UltraslimBay” on page 1-3.

Removing a Device from the UltraslimBay

To remove a device from the UltraslimBay, do as follows:

1 Make sure there is no storage media inserted in the device.

2 Power off the computer, and remove the AC Adapter and

cables; then turn the computer upside down.

3 Push the UltraslimBay device lock to the unlocked position 1;

then remove the device from the bay 2.

You have now finished removing the device.

Notes:

1. If you want to warm swap the device in the UltraslimBay, you

need to install the hot/warm swap driver.

2. Make sure that the bay LED is off. Never remove the

UltraslimBay device when the bay LED is on.

1-2

Installing the DVD Drive in the UltraslimBay

To install the DVD drive in the UltraslimBay, insert the drive into the

UltraslimBay. Make sure you connect the drive firmly.

You have now finished installing the DVD drive.

Installing the Hot/Warm Swap Driver

(ThinkPad 600 Only)

If you are using the ThinkPad 600 computer (rather than a ThinkPad

600E computer) and you want to warm swap the DVD drive, you need

to install the hot/warm swap driver for Windows.

The following table shows the country code that you will need in the

instructions:

To install the hot/warm swap driver, do the following:

1 Start Windows 98 or Windows 95.

2 Insert the Hot/Warm Swap Driver CD-ROM into the DVD

drive.

Country Code Country Code

Denmark DK Netherlands NL

Finland FI Norway NO

France FR Spain SP

Germany GR Sweden SW

Italy IT United States US

Japan JP

Part 1. Using the DVD Drive 1-3

3 Click on Start and move the cursor to Settings; then click on

Control Panel.

4 Double-click on Add New Hardware.

5 Click on Next.

(For Windows 98, click on Next again.)

6 Select No and click on Next.

(For Windows 98, select No again and click on Next.)

7 Click on Other devices, and click on Next.

8 Click on Have Disk....

9 Type X:\YY

10 Click on OK.

11 Select UltraBay Hot/Warm Swap Driver, and click on Next.

12 Click on Finish.

13 Restart the computer.

Installing the Display Driver (ThinkPad

600 Only)

If you are using a ThinkPad 600 computer (rather than a ThinkPad

600E computer), you need to update the display driver before

installing the DVD movie player program.

Installing the Display Driver for Windows 98

To install the ThinkPad display driver for Windows 98, do the

following:

1 Start Windows 98.

2 Click on Start.

3 Move the cursor to Settings; then click on Control Panel.

4 Double-click on the Display icon; then click on the Settings

tab.

5 Click on Advanced....

6 Click on the Adapter tab.

7 Click on Change....

The Update Device Driver Wizard starts.

8 Click on Next.

Note: X is the drive letter of the DVD drive, and YY is the country

code.

1-4

9 Select Search for a better driver than the one your device is

using now. (Recommended) by clicking on it. Then click on

Next.

10 Put a check mark in the Floppy disk drives check box by

clicking on it.

11 Insert the Display Driver Diskette (NM2160) for Windows

98/95 into the diskette drive, and click on Next.

12 When a message appears that Windows has found NeoMagic

MagicGraph 128XD, click on Next.

If you are prompted for the source directory, type A:\

13 Click on Finish.

14 Remove the diskette from the diskette drive, and click on Yes to

restart the computer.

15 When the computer restarts, select screen settings for the color

palette, desktop area, and font size; then click on Close.

16 Click on Start.

17 Move the cursor to Settings; then click on Control Panel.

18 Double-click on the Display icon.

19 Click on the Setting tab.

20 Set the Colors and Screen areas in the “Display Properties”

window.

21 Click on OK to close the window.

Installing the Display Driver for Windows 95

To install the display driver for Windows 95, do the following:

1 Start Windows 95.

2 Click on Start.

3 Move the cursor to Settings; then click on Control Panel.

4 Double-click on Display; then click on the Settings tab.

5 Click on Advanced Properties.

6 Click on the Adapter tab; then click on Change....

7 Click on Have Disk...

8 Insert the Display Driver Diskette (NM2160) for Windows

98/95 into the diskette drive, and click on OK.

9 Click on NeoMagic MagicGraph 128XD; then click on OK.

10 Click on Close.

11 Remove the diskette from the diskette drive.

Part 1. Using the DVD Drive 1-5

12 Select your screen parameters from the color palette, desktop

area, and font size; then click on Close.

13 Specify the type of monitor as follows. (If you do not specify

the type of monitor you want to use, your new settings might

not function correctly.)

a. Open the “Display Properties” window.

b. Click on the Settings tab.

c. Click on Advanced Properties.

d. In the “Advanced Display Properties” window, click on the

Monitor tab.

e. Click on Change....

f. Click on Show all devices.

g. Specify Manufacturers and Models in the next window.

For example,

If you are using the LCD:

Manufacturers: (Standard monitor types)

Models: Laptop Display Panel

(1024x768)

If you are using the external monitor:

Manufacturers: (Standard monitor types)

Models: Plug and Play Monitor

h. Click on OK.

i. Close all windows.

14 Follow the instructions on the screen.

Windows 95 prompts you to restart your computer to make the

display driver change effective.

Installing Programs

If you want to view DVD movies, install the following programs from

the supplied CD-ROM to your hard disk:

DVD Movie Player (DVD Express)

DirectX 5.0

After installing the programs, you need to select the region code.

If you are not going to watch DVD movies—that is, if you are going

to use the DVD drive only for reading DVD-ROMs or

CD-ROMs—you do not need to install these programs.

To install the software programs, do as follows:

Installation Instructions for Windows 98

To install the DVD movie player program for Windows 98, do the

following:

1 Insert the DVD Software CD-ROM in the DVD drive.

2 Click on Start and Run...

3 Type X:\DVDPLAYR\SETUP and press Enter.

1-6
