IBASE Technology FWA6504 Manual de usuario

FWA6504

1U 19”Network Appliance

Users Manual

Version A1

FWA6504 User’s Manual

Table of Contents

Chapter 1 Introduction......................................................................................................................3

Chapter 2 System Specification.......................................................................................................4

Chapter 3 Hardware Configuration...................................................................................................5

Chapter 4 Console Mode Information.............................................................................................10

Chapter 5 Opening the Chassis.....................................................................................................12

Chapter 6 Installing CompactFlash Card........................................................................................12

Chapter 7 Installing Memory Module..............................................................................................12

Chapter 8 Installing 2.5” SSD.........................................................................................................13

Chapter 9 Installing Mini PCI-e Module..........................................................................................14

FWA6504 User’s Manual

Foreword

To prevent damage to the system board, please handle it with care and follow the measures below,

which are generally sufficient to protect your equipment from static electricity discharge:

When handling the board, use a grounded wrist strap designed for static discharge elimination grounded

to a metal object before removing the board from the antistatic bag. Handle the board by its edges only;

do not touch its components, peripheral chips, memory modules or gold contacts.

When handling processor chips or memory modules, avoid touching their pins or gold edge fingers.

Return the Network Appliance system board and peripherals back into the antistatic bag when not in use

or not installed in the chassis.

Some circuitry on the system board can continue to operate even though the power is switched off.

Under no circumstances should the Lithium battery cell used to power the real-time clock be allowed to

be shorted. The battery cell may heat up under these conditions and present a burn hazard.

WARNING!

1. "CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.

REPLACE ONLY WITH SAME OR EQUIVALENT TYPE RECOMMENDED BY THE

MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE

MANUFACTURER’S INSTRUCTIONS"

2. This guide is for technically qualified personnel who have experience installing and configuring

system boards. Disconnect the system board power supply from its power source before you

connect/disconnect cables or install/remove any system board components. Failure to do this can

result in personnel injury or equipment damage.

3. Avoid short-circuiting the lithium battery; this can cause it to superheat and cause burns if touched.

4. Do not operate the processor without a thermal solution. Damage to the processor can occur in

seconds.

5. Do not block air vents at least minimum 1/2-inch clearance required.

6. In case explosion, you should change battery with same specification.

FWA6504 User’s Manual

Chapter 1 Introduction

The FWA6504 was specifically designed for the network security &

management market.

Network Security Applications:

•Firewall

•Virtual Private Network

•Proxy Server

•Caching Server

Network Management Applications:

•Load balancing

•Quality of Service

•Remote Access Service

The FWA network appliance product line covers the spectrum from offering

platforms designed for :

•SOHO

•SMB

•Enterprise

Each product is designed to address the distinctive requirements of its

respective market segment from cost effective entry-level solutions to

high throughput and performance-bound systems for the Enterprise level.

FWA6504 User’s Manual

Chapter 2 System Specification

Product Description

FWA6504 incorporates Intel® NM10 chipset. Currently, it is available in the following model:

Model

Intel® Atom Dual Core CPU

Watchdog Timer

FWA6504

Atom D2550

1.86 GHz

Yes

FWA6504 Features

Supports four intel® 10/100/1000 LAN ports

DDR3 SO-DIMM x 1, up to 4GB

Mini PCI-e (USB Signal) slot, Mini PCI slot & Compact Flash socket

LAN bypass Enable / Disable pre-setting by BIOS when power on / off

FWA6504 Specifications

Form Factor

5.25”Disk Size SBC

CPU Type

Operating Frequency

Intel “Cedar view” Processor, 32nm Bulk

Atom D2550 = 1.86 GHz [TDP= 10W], Cores = Dual Core

Chipset

Intel “Tiger Point” PCH, CG82NM10 [TDP = 2.1W, 130 nm]

BIOS

AMI BIOS w/ACPI

Ethernet controller

Intel 82583V PCI Express Gigabit ethernet controller x4

Memory

CPU on-die memory controller supporting up to 4GB

One DDR3-1066 SO-DIMM socket, Non-ECC, unbuffered, 1.5V

LAN

Console: RS-232 @ RJ45

Eth1, 2, 3 & 4: Intel 82583V @ RJ45 with LED

Network Bypass

One segment hardware Bypass (Eth1 & 2, Optional)

Control by GPIO / Watchdog / Electrical Disconnect (Power Off)

Watchdog Timer

Yes (256 segments, 0, 1, 2…255 sec/min)

Storage

Onboard CF Socket x1

22-pin SATA Right Angle Connector Onboard for 2.5” SSD x1

Front Panel

Factory Mode Restore Reset Switch (GPIO control)

RJ45 x1 for Console

RJ45 with LED x4 for Gigabit LAN Ports

USB 2.0 x2

LED: Power (Green) / Alarm (Red) / Status (Yellow)

Rear Panel

AC Inlet

Video

Optional VGA Port on Front Panel

Internal I/O Headers

4-pin Smart Fan Connector x1

2-pin header for DC-in (12V) x1

Keyboard + Mouse ([1x6] Pin Header) x1

Expansion Interface

Mini PCI Socket, Mini PCI-e Socket x1 (USB Signal Only)

Power Supply

Full range 40W supply / 12V

Dimensions

430(W) x 216(D) x 44(H) mm

Operation Temperature

0 ~ 45 ˚C (32 ~ 113 ˚F)

Storage Temperature

-20 ~ 70 ˚C (-4 ~ 158 ˚F)

FWA6504 User’s Manual

Chapter 3 Hardware Configuration

Motherboard (MB837-1U) Layout

FWA6504 User’s Manual

The Jumpers

JP1: Clear CMOS Contents

Use JP1 to clear the CMOS contents.

Note that the power connector or jack should be disconnected from the board before clearing CMOS.

JP1

Setting

Function

Pin 1-2

Short/Closed

Normal

Pin 2-3

Short/Closed

Clear CMOS

JP4, JP5: LAN Bypass & WDT Reboot Setting

JP4

JP5

Setting

Function

Power

OFF

Power

Power ON

OS run software

Normal

Bypass

Normal

Bypass

Normal

Bypass

JP4

1-2 & 3-4

Open

JP5

1-2 Closed

LAN bypass

upon the time

out of WDT.



JP4

1-2 & 3-4

Closed

JP5

1-2 Closed

System will

reboot upon the

time out of WDT.



LAN Always

Bypass

System will

reboot upon the

time out of WDT.

WDT Reboot

System

JP4

3-4 Closed

1-2 Open

JP5

1-2 Closed

LAN bypass &

system reboot

upon the time

out of WDT.



LAN Always

Normal

WDT Reboot

System

JP4

1-2 & 3-4

Open

JP5

2-3 Closed

LAN bypass

controlled by

Super IO GP54

or setting in

BIOS.

BIOS Setting **

GP54 Active:

Low: Bypass

High: Normal

** Note that the Bypass setting in BIOS is only working when JP4 & JP5 are set as this configuration.

Default Setting

FWA6504 User’s Manual

The Connectors

FAN1: System Fan Power Connector

FAN1 is 4-pin header for System fan power. The fan must be a 12V fan.

Pin #

Signal Name

Ground

+12V

Rotation detection

Control

CN1, CN2, CN3, CN4: 10 / 100 / 1000 LAN Ports

CN6: COM1 RJ45 Connector

Pin #

Signal Name (RS-232)

RTS, Request to send

DTR, Data terminal ready

TXD, Transmit data

Ground

RXD, Receive data

DSR, Data set ready

CTS, Clear to send

CN7: SATA SSD Dock

The SATA SSD dock combines a SATA power connector and a SATA interface connector.

Signal Name

Pin #

Signal Name

GND

+3.3V

A+

+3.3V

A-

+3.3V

GND

B+

GND

B-

GND

+5V

P10

GND

P11

GND

P12

GND

P13

+12V

P14

+12V

P15

+12V

J1: SO-DIMM DDR3 Socket

J2: Mini PCI-e Connector (USB signal only)

J3: SPI Debug Port (Factory use only)

FWA6504 User’s Manual

J4: VGA Header

Signal Name

Pin #

Signal Name

DACR

+5VCRT

DACG

GND

DACB

CRT_SPD

GND

HSYNC_C

+5VCRT

VSYNC_C

GND

CRT_SPCLK

GND

J6:PS2 KB/MS Header

Pin #

Signal Name

KBDATA

KBCLK

MSDATA

MSCLK

GND

+5V

J7: Slim Type II Compact Flash Connector

J8: COM2 Serial Port

Pin #

Signal Name (RS-232)

DCD, Data carrier detect

RXD, Receive data

TXD, Transmit data

DTR, Data terminal ready

Ground

DSR, Data set ready

RTS, Request to send

CTS, Clear to send

RI, Ring indicator

No Connect.

J9: AT_12V Connector

J9 is a DC-in internal connector supporting +12V.

Pin #

Signal Name

+12V

Ground

Note: Do not connect J9 and J11 at the same time.

J10: USB Header

Signal Name

Pin #

Signal Name

VCC

Ground

USB1-

USB2+

USB1+

USB2-

Ground

VCC

FWA6504 User’s Manual

LED5: Power, Alarm & Status LED Pin Header

Signal Name

Pin #

Signal Name

PWR LED+

PWR LED-

ALARM LED+

SIO GPIO55

STATUS LED+

SIO GPIO56

SW3: Software Reset Button

Signal Name

Pin #

Signal Name

GND

PCH GPIO7

Note: SW3 is controlled by GPIO only.

JP3: Mini-PCI Connector
