I-Tech UltraView iAP1000 Manual de usuario

UserManual

InnovativeLCDDisplaySolutions

10AV Series

ltraView

Jan 05

P.1

AP-10AV / DP-10AV /DP-10AVSeriesUserManual

1.TableofContent Page.1

2.Introduction

A)OverviewPage.2

B)FeaturesPage.2

C)Dimension DiagramsPage.3-5

D)TechnicalSpecificationsPage.6

3.Installation

A)Package ContentsPage.7

B)Cautiontothe userPage.7

C)Cleaning Page.7

D)PrecautionsPage.8-9

4.Using theSystem

A)Product ViewsPage.10-12

B)I/O OutletPage.13

C)Installation ProceduresPage.14

D)Setup Touchscreen(Optional)Page.15

i) ForWindows Page.15

ii) ForDOS Page.16-18

E)OSDSwitchPage.19

F)OSDControl(VGAVersion)Page.20-22

G)OSDControl(Video Version)Page.23-27

1. Tableof Content

Jan 05

P.2

Disclaimer

Thisinformation issubjecttochange withoutnotice.Theproducerofthismanual acceptsno

responsibilityfordamage orclaims,resulting frommisuseormisinterpretation

A.Overview

B.Features

AP-10AV / DP-10AV /DP-10AVSeriesUserManual

2.Introduction

ThisLCDmonitorincorporates10.4 coloractivematrixthin-film-transistor

(TFT)liquidcrystaldisplaytoprovide superiordisplayperformance.Amaxi-

mumresolution of 800 x600 isidealfordisplaying complexgraphics and high

definition images.Otheroutstanding designsthatenhancethisLCD monitor’s

performancearePlug&PlaycompatibilityandOSD(OnScreenDisplay)

controls.

High contrastcolorTFTLCD displaysupportresolution upto800x600.

Advanced OSDcontrolforpicturequalityadjustment.

Detachablestand forwall-mounting application.

OptionalCompositeandS-Video input

Slimand compact size

Wide Viewing Angle

Jan 05

P.3

AP-10AVseries

C.DimensionDiagrams

AP-10AV / DP-10AV /DP-10AVSeriesUserManual

2.Introduction

Jan 05

P.4

DP-10AVseries

C.DimensionDiagrams

AP-10AV / DP-10AV /DP-10AVSeriesUserManual

2.Introduction

Jan 05

P.5

OP-10AVseries

C.DimensionDiagrams

AP-10AV / DP-10AV /DP-10AVSeriesUserManual

2.Introduction

Jan 05

P.6

Technical Specifications

Monitor

Panel10.4" LCD Panel

DisplayType TFT LCD activematrixcolour

Resolutions800 x600

ResponseTimeTr=15ms, Tf=25ms

Contrast Ratio180:1typical

Brightness 350 cd/m2typical

PixelPitch0.264(H)x0.264(V)

PanelColour262,144 displaycolour

Viewing Angle60 / 60 / 55 / 40(L/R/ U/ D)

Storage Temp.-20°to60°C

OperatingTemp.0°to50°C

MTBF50,000 hours

PowerSupply

RemoteAdapter110V-220VACInput

AdapterSize108(L)x60 (W)x30(D)mm

CableLengthfrom

mainsplug toadapter 182cm

CableLengthfrom

adapterUnit 180cm

PowerSocket12V(+)female

Connectors

RCACompositevideoinput(female)x1

S-Video MiniDIN4-pin(female)x1

VGAHDDB15-pin(female)x1

Video StandardsSupportsNTSC, PALorSECAM

Product

Dimension

AP Series: 275(W)x215(H)x41(D)mm

DPSeries: 259(W)x199(H)x37(D)mm

OPSeries:285(W)x225(H)x35(D)mm

Packing

DimensionAP / DP/ OPSeries: 480(L)x362(W)x85(H)mm

AP-10AV / DP-10AV /DP-10AVSeriesUserManual

2.Introduction

Afterunpacking the carton,check and see ifthefollowingitemsareincluded in

good condition.Contactyoursupplierassoonaspossibleforreplacingthe

missing / damaged items.

10.4 TFTLCD monitor

RCACable(OptionalForAV Version only)

S-Video Cable(OptionalForAV Version only)

VGACable(MaletoMale)

DC 12VAdapter(5A)

PowerCord

Mounting Bracket (AP Seriesonly)

UserManual

CD Disc

ToassurecontinuedFCC compliance,pleaseusegrounded powersupply

cordand the provided shielded video interfacecablewithbonded ferritecores.

If aBNC cableisgoingtobe used,useonlyashielded BNC (5)cable.Also,

TheFederalCommunicationsCommissionwarnstheuserthatany

unauthorized changesormodificationstothe unitifnot expresslyapprovedby

thepartyresponsibleforcompliancecouldvoidtheuser'sauthorityof

operatingthe equipment.

1.Gentlywipe screen withaclean camelhairlensbrush,orasoft,clean,

lint-free cloth.Thisremovesdustand otherparticlesthatcan scratchthe

screen.

2.Donotapplyexcessivepressuretothescreensurfacewhen wiping itclean

becausethismaydamage the LCD.

3.Donot pourorsprayanyliquiddirectlyontothescreen orcaseof the LCD

monitor.Chemicalcleanershavebeenreported todamage thescreen or

caseof theLCD monitor.

A.PackageContents

Jan 05

P.7

B.Caution toTheUser

C.Cleaning

AP-10AV / DP-10AV /DP-10AVSeriesUserManual

3.Installation

Jan 05

P.8

Read allof theseinstructionsandsavethemforlateruse. Followallwarnings

and instructionson the product.

Product

Donot coverorblock the vent holesinthe case.

Donotinsertsharpobjectsorspillliquidintothe LCD monitorthrough

cabinet slots.Theymaycauseaccidentfire,electricshock orfailure.

Disconnect thepowerplug fromthe ACoutletif you willnot useit foran

indefiniteperiod oftime.

Donotattempttoservicethisproductyourself,asopening orremoving

coversmayexposeyou todangerousvoltage pointsorotherrisks.

Donottouchthe screendirectlywithyourfingers.You maydamage the

screen, and oilfromyourskinindifficult tomove.

Donot applypressuretoscreen. TheLCD isverydelicate.

D.Precautions

Power

1.Usethe type of powerindicatedon the markinglabel.

Plugs

1.Donotremoveanyof the prongsofthemonitor’sthree-pronged power

plug.

2.DisconnectthepowerplugfromtheACoutletunderfollowing

conditions

If the product willnot be used foran indefiniteperiod time.

Whenthe powercordorplug isdamaged orfrayed.

Iftheproductdoesnotoperatenormallywhentheoperating

instructionsarefollowed.

Adjustonlythosecontrolsthatarecoveredbytheoperating

instructions.Improperadjustment of othercontrolsmayresult in

damageandwilloftenrequireextensiveworkbyaqualified

technician torestoretheproduct tonormaloperation.

If the producthasbeen dropped orthe cabinet hasbeen damaged.

If the productexhibitsadistinctchangeinperformance,indicatinga

need forservice.

AP-10AV / DP-10AV /DP-10AVSeriesUserManual

3.Installation

Jan 05

P.9

D.Precautions(Cont.)

Powerandextensioncords

1.Donot allowanything torest onthe powercord.

2.Donotlocatethisproduct wherepersonswillwalkon the cord.

3.Usethe properpowercordwithcorrectattachmentplug type.If the

powersourceis120VAC,useapowercordthathasULand C-UL

approvals.If the powersourceisa240VACsupply,usethe tandem

(Tblade)type attachmentplug withground conductorpowercordthat

meetsthe respectiveEuropeancountry’ssafetyregulations,suchas

VDEforGermany.

4.Donot overloadwall outletsorpowercords. Ensurethat the totalof all

unitspluggedintothe walloutlet doesnot exceed 10 amperes.

5.Ensurethatthetotalampereratingsonallunitspluggedintothe

extension cordisnotabovethe cord’srating.

6.Ifthepowersupplycord,whichcamewithyourmonitor,istobe

connected tothePCinstead ofthe walloutlet,thisequipmentistobe

usedwithUL/TÜVapprovedcomputerswithreceptaclerated

100~240VAC, 50/60Hz,1.0A(minimum).

Environment

1.Placethemonitoronaflatand leveledsurface.

2.Placethemonitorinawell-ventilated place.

3.Keep the monitorawayfrom Overlyhot, coldorhumidplaces,places

directlyundersunlight, dustysurroundings,equipmentthatgenerate

strong magneticfields.

AP-10AV / DP-10AV /DP-10AVSeriesUserManual

3.Installation
