Pulse P2DV Series
User Manual
Pulse IP Camera User Manual
Model Number: P2DV Series
Revision: 3.0.1.2
2 | P a g e
Pulse P2DV Series
User Manual
Safety Instruction
These instructions are intended to assist users ith the operation of the P2DV and also to instruct on
ho to avoid dangerous situations or damage to the device.
Warnings: Serious injury or death may be caused if any of the arnings belo are neglected.
Cautions: Injury or damage to the equipment may occur if any of the follo ing caution
messages are neglected.
Warnings
Follow these safeguards
to prevent serious injury or death.
Cautions
Follow these precautions
to prevent potential injury or material
damage.
Warnings:
Input voltage should meet both the SELV (Safety Extra Low Voltage) and
the Limited Power Source with DC 12V according to the IEC60950-1
standard. Please refer to the technical specifications for more details.
Do not use a third-party power adapter or power cord
When the device is installed on the wall or ceiling, make sure that it is
firmly attached.
3 | P a g e
Pulse P2DV Series
User Manual
Notice：
•Make sure that the power supply voltage is correct before using the camera.
•Do not drop the device or expose it to physical shock.
•Do not expose the device to temperatures outside the range of -10 °C to +50°C
when the device is in operation.
•Do not expose the device to damp/wet conditions or high electromagnetism
radiation.
•To avoid heat accumulation, make sure that your operating environment has
proper ventilation.
•Do not attempt to open, disassemble, or modify the device
•
A few parts (e.g. electrolytic capacitor) of the equipment shall be replaced
regularly according to their average life time. The average life time varies from
the differences between operating environments and usage history. Regular
maintenance checks are recommended for all users. Please contact your dealer
for more details.
4 | P a g e
Pulse P2DV Series
User Manual
Contents
Welcome …………………………………………………………………………………………………………………
Package Contents ………………………………………………………………………………………………… 6
Product Overview ………………………………………………………………………………………………… 7
Configuring the P2DV via Web Browser ……………………………………………………… 10
Access P2DV Web Configuration Menu ……………………………………………… 10
Connect The Camera to DHCP server …………………………………………………………… 10
Connect to the Camera using Static IP …………………………………………………………… 11
Home Web Page …………………………………………………………………………………………… 12
System Page ………………………………………………………………………………………………… 14
Video & Audio Page …………………………………………………………………………………….. 1
Networking Page…………………………………………………………………………………………… 16
DDNS Page……………………………………………………………………………………………………. 19
SIP Page…………………………………………………………………………………………………………. 21
Status Page ………………………………………………………………………………………………….. 23
User Management Page ………………………………………………………………………………….. 2
Maintenance Page ………………………………………………………………………………………… 26
SMTP Page ……………………………………………………………………………………………………. 27
FTP Page ………………………………………………………………………………………………………. 28
Alarm HTTP Server Setting……………………………………………………………………………. 29
Motion Detection Page ………………………………………………………………………………… 30
System Log …………………………………………………………………………………………………… 32
5 | P a g e
Pulse P2DV Series
User Manual
Welcome
The
P2DV
is a next generation mini IP dome camera for remote monitoring and
surveillance over your LAN or internet.
The
P2DV
combines best in class IP video technology and SIP protocols for a robust IP
surveillance solution. The product features H.264 video streams ith up to 30 frames per
second in full D1, delivering rich image clarity at rapid transmission rates. Integrated SIP can
pass alarms to the PSTN, mobile phones, SIP IP phones, SIP videophones and enables
2- ay VoIP communication.
The
P2DV
ensures ease of use, integration and deployment ith a multilingual graphical
user interface. The
P2DV
can be quickly installed and connected to your net ork and
accessed from any here over the internet. i-Flash Technology flexible video management
soft are enables users to monitor multiple environments in one easy to use application. The
intuitive eb interface lets users easily access, manage, vie and record live video streams
from the device.
The
P2DV
is a po erful solution for small to medium sized offices, homes and storage
facilities looking to safeguard their valuables.
6 | P a g e
Pulse P2DV Series
User Manual
Package Contents
Items in the package:
•P2DV IP Camera
•Quick Installation Guide and Soft are CD
P2DV IP Camera
Quick Installation Guide
and Soft are CD
7 | P a g e
Pulse P2DV Series
User Manual
Product Overvie
P2DV Camera
Connectors and Cables
Network: 10/100 S itch LAN Port for connecting to Ethernet
Power – 12V DC Po er Jack
Reset Button – Reset the Camera
Connectors and Cables (With Audio)
Audio: Audio Input
Network: 10/100 S itch LAN Port for connecting to
Ethernet
Power – 12V DC Po er Jack
Reset Button – Reset the Camera
8 | P a g e
Pulse P2DV Series
User Manual
P2DV Key Features
Video Compression H.264 HP、JPEG, Motion JPEG
Image Sensor 1/3.2”, 2-Megapixel CMOS, 1,600Hx1,200V
Lens 1/3", M12 MEGA, f=3.6 mm, F=1.8 (Selectable）
Day/Night IR Light and IR-CUT control (Optional)
Min. illumination 0.5Lux
Min. illumination Response 1.0V/lux-sec (550nm)
Max Video Resolution 1600x1200
Max Frame Rate 6 fps 1600x 1200, 25fps at 1280x720, 30fps at
800x460, 640x360, 480x270, 320x180 and 240x135
Pixel Dynamic Range 71dB, ith ( SNRMAX = 42.3dB)
Video Output NTSC or PAL Complex video signal
Frame Rate 10-30fps
Video Compression Type Video Stream / Complex Video Stream
Compressed Video Output rate 16Kbps - 2Mbps
Audio Input MIC IN (optional)
Audio Output Linear output (LINEOUT，600Ω, Optional)
Audio Compression Standard G.711
Audio Compression Rate 16-96kbps，support8-16KHz
Net ork Connection RJ45 10M/100M Ethernet
Po er 12VDC or PoE ith Splitter
Operation Temperature -10°C – 45°C
Operation Humidity 10–90%（non-condensing）
Dimension 107 mm diameter
Weight ~ 450g
9 | P a g e
Pulse P2DV Series
User Manual
Installation Guide
Minimum Recommended System Requirement
• Windo s 2000 Server Professional, Windo s XP, Windo s Vista, Windo s 7
• CPU: Intel Pentium 4 or higher, 2 GHz.
• RAM: 1 GB (4 GB recommended for larger systems).
• Support for DirectX 8.0 and above.
Connect your P2DV
Using the Po er adapter as po er supply
• Connect an RJ-45 cable to the NETWORK port of the P2DV.
• Connect the other end of the RJ-45 cable to your net ork or PC.
• Connect the po er supply to the DC 12V po er jack on the back of the P2DV.
• Connect the other end of the po er supply ith 12VDC 1A minimum to a all outlet (not included)
Using PoE as power supply with PoE Splitter (not included in Package):
• Connect an RJ-45 to the NETWORK port of P2DV.
• Connect the other end of the RJ-45 cable to a PoE s itch.
NOTE: If you are going to connect the device to a hub/s itch/router, please use a straight-through cable.
A cross over cable should be used if you are going to connect the device directly to a PC.
10 | P a g e
Pulse P2DV Series
User Manual
Configuring the P2DV via Web Browser
The P2DV’s embedded Web server responds to HTTP/HTTPS GET/POST requests.
Embedded HTML pages allo you to configure your IP camera through Microsoft Internet Explorer.
Access P2DV Web Configuration Menu
Connect the Camera to DHCP server.
1. Run the Search tool provided in Soft are CD
2. Click on button in order to begin device detection
3. The detected devices ill appear in the Output field
4. Start Internet Explorer on your computer
5. Enter device IP in the address bar of the bro ser or double click the camera in Search tool
6. Enter the administrator user name and pass ord to access the Web Configuration Interface
7. The default user name and pass ord are both set to admin.
8. IE ill indicate that “This ebsite ants to install the follo ing add-on:
9. Install this add-on by follo ing the instructions in IE.
10. You ill see the home page.
