Hyundai ImageQuest L17T Manual de usuario

FCC ID : PJIL17A00001

HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD.

SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA

TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr

Report No. : HCT-FO5-0903 1/1

ATTACHMENT E.

- USER’S MANUAL -

User’s Guide

Type No. L17A00000 / L19A00000

Model. L17T/L19T

TFT LCD Color Multi Function Monitor

U.S.A.

U.S.FEDERAL COMMUNICATIONS COMMISSION

RADIO FREQUENCY INTERFERENCE STATEMENT

INFORMATION TO THE USER

NOTE : This equipment has been tested and found to comply with the limits for a

Class B digital device pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet of a circuit different from that to which

the receiver is connected.

Consult the dealer or an experienced radio/TV technician for assistance.

Changes or modification not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

Connecting of peripherals requires the use of grounded shielded signal cables.

WE Hyundai ImageQuest CO., LTD.

Ami-ri Bubal-Eub Ichon-Si Kyungki-Do

467-860 KOREA

declare under our sole responsibility that the product:

to which this declaration relates is in conformity with the

following standard(s) or other normative document(s)

following the provisions of the Low Voltage Directive 73/23/EEC,

93/68/EEC and the EMC Directive 89/336/EEC.

KOREA / September. 09, 2005

BYUNG SUHN, AHN

(Place and date of issue) (Name and signature of

authorized person)

DECLARATION OF CONFORMITY

Kind of equipment : LCD MONITOR

Type-Designation : L17A00000 / L19A00000

Safety : EN60950-1:2002

EMC : EN 55013:2001+A1:2003

EN 55020 :2002+A1:2003

EN 55022 :1998+A1:2000+A2:2003

EN 55024 :1998+A1:2001+A2:2003

EN 61000-3-2:2000

EN 61000-3-3:1995+A1:2001

Accredited testlaboratory:

TÜV Rheinland

Am Grauen Stein

51105 Köln

L17T/L19T

TFT LCD Color Multi Function Monitor

Contents 1. Introduction ...................................1/35

2. Safety Information ........................1/35

3. Installing the monitor ...................4/35

3-1. Packing List .........................................4/35

3-2. Selecting a suitable location ..............5/35

3-3. Connecting the monitor .....................5/35

3-4. Connecting the TV ..............................5/35

3-5. Setting the refresh rate ......................8/35

Preset Timing Table ............................9/35

3-6. User’s Environment ...........................10/35

4. Adjusting the picture(Monitor) .12/35

4-1. Using the On Screen Display ...........13/35

4-2. Direct access buttons .......................13/35

4-3. OSD Adjustments .............................14/35

5. Adjusting the picture(TV) ...........17/35

5-1. Direct access buttons .......................17/35

5-2. OSD Adjustments .............................18/35

6. TV Functions ................................21/35

7. Display power management ......29/35

Reducing power consumption ..............29/35

8. Troubleshooting ..........................31/35

9. Specifications ..............................34/35

L17T/L19T

TFT LCD Color Multi Function Monitor

1. Introduction

2. Safety Information

1/35

This manual contains instructions for installing and operating

Hyundai ImageQuest L17T/L19T.

Hyundai ImageQuest L17T/L19T is a highly ergonomic color display unit.

• 17"/19” viewable SXGA LCD

• High quality screen re-scaling capability

• 100-240V AC input voltage, DC 12V 3.5A Adapter

• VESA DPMS (Display Power Management Signaling)

• VESA DDC1/2B compatibility

• Advanced digital On-Screen-Display controls

• Fast and accurate auto adjustment

• Most advanced image scaling

• Supporting VESA Flat Panel Monitor Physical Mounting Interface

This Monitor has been engineered and manufactured to assure your safety.

You can prevent serious electrical shock and other hazards by keeping in mind

the following:

Do not place anything wet on the monitor or the power

cord. Never cover the ventilation openings with any

material or touch them with metallic or

inflammable materials.

L17T/L19T

TFT LCD Color Multi Function Monitor

2/35

Avoid operating the monitor in extreme heat,

humidity or areas affected by dust.

Temperature : 5~35°C

Humidity : 30~80RH

Be sure to turn the monitor off before plugging the

power cord into the socket. Make sure that the power

cord and the other cords are securely and rightly

connected.

Overloaded AC outlets and extension cords are

dangerous, as are frayed power cords and broken

plugs, which may cause electric shock or fire. Call

your service technician for replacement.

Do not use sharp tools such as a pin or a pencil near

the monitor, as they may scratch the LCD surface.

Do not use any solvent, such as benzene, to clean the

monitor, as it will damage the LCD surface.

L17T/L19T

TFT LCD Color Multi Function Monitor

Cleaning and Maintenance

• To avoid risk from electric shock, do not disassemble the cabinet of the unit.

The unit is not user-serviceable. Remember to unplug the unit from the power

outlet before cleaning.

• Do not use alcohol (methyl, ethyl or isopropyl) or any strong dissolvent. Do not

use thinner or benzene, abrasive cleaners or compressed air.

• Do not wipe the screen with sponge/cloth that could scratch the surface.

• To clean your antistatic screen, use water and special microfiber-screen-

cleaning tissue-used in optical lens cleaning, or a lightly dampened piece of

soft, clean cloth with water or mild detergent.

• If the instructions above do not help in removing stains, contact an authorized

service agent.

3/35

L17T/L19T

TFT LCD Color Multi Function Monitor

4/35

The following items should be found in the package.

The power cord above can be changed upon different voltage areas. Please

contact your dealer if anything is missing or damaged.

Other power cord’s except the original packed in the product especially cards

longer than 3m may affect EMC of the product in operating condition.

3. Installing the

monitor

3-1. Packing List

America/Canada

Japan

Australia

Korea

Europe

South Africa

MUTE

P-CHEDIT PRE,P

–

PCS-VIDEOVIDEOT

SOURCEINFOAIR/CABLESEARCH

VOLEXIT P-CHANNEL

AUTOBRIGHTNESSCONTRAST

POWER

TTX/MIX LIST/FLOFSTOREHOLD

SIZEREVEALSUBPAGEINDEX

Power Cord

Signal Cable

Audio Cable

Compact Disc

Remote Conrtol wuth

Batteries(AAA x 2) Installation

Guide

AC/DC Power

adapter

L17T/L19T

TFT LCD Color Multi Function Monitor

5/35

3-2. Selecting a suitable

location

3-3. Connecting the

monitor

• Place the monitor at least 30cm from other electrical or heat-emitting

equipment and allow at least 10cm on each side for ventilation.

• Place the monitor in a position where no light shines directly onto or is

reflected on the screen.

• To reduce eye strain, avoid installing the display unit against a bright

background such as a window.

•

Position the monitor so that the top of the screen is no higher than the eye level.

• Position the monitor directly in front of you at a comfortable reading distance

(around 45 to 90cm)

Before you start cabling your monitor, check that the

power is off on all units. To avoid any possibility of

electric shock, always connect your equipment to

properly earthed outlets.

1. Insert the other 15-pin signal cable connector into the 15-pin VGA connection

on your computer and screw it.

2. Plug the power cord connection to the connection on the monitor.

3. Plug the other end of the power cord to your computer's main supply or to a

100V-240V earthed electrical outlet.

4. Turn on the monitor using the power switch and check that the power LED is

on. If not, repeat steps 1,2,3 and 4 or refer to the Troubleshooting section of

this guide.

5. Turn on the power of the computer. The picture will appear within about 10

seconds. Adjust the picture to obtain optimum picture quality. See section

Adjusting the picture in this guide for more information.
