HyperX Pulsefire Dart HX-MC006B Manual de usuario
Document No. 480HX-MC006B.A01
HyperX Pulsefire DartTM
Page 1 of 7
HyperX Pulsefire DartTM
Part Number
HX-MC006B
Document No. 480HX-MC006B.A01
HyperX Pulsefire DartTM
Page 2 of 7
TABLE OF CONTENTS
Overview .................................................................................................................................... 3!
Specifications ........................................................................................................................... 4!
Installation ................................................................................................................................. 5!
Wireless Mode ......................................................................................................................................................... 5!
Wired Mode .............................................................................................................................................................. 5!
Charging .................................................................................................................................... 6!
Wireless Charging .................................................................................................................................................. 6!
Wired Charging ....................................................................................................................................................... 6!
Function Keys ........................................................................................................................... 7!
HyperX NGENUITY Software ................................................................................................... 7!
Using with Console .................................................................................................................. 7!
Factory Reset ............................................................................................................................ 7!
Document No. 480HX-MC006B.A01
HyperX Pulsefire DartTM
Page 3 of 7
Overview
A. Left click button
B. Right click button
C. Mouse wheel
D. DPI button
E. Forward click button
F. Backward click button
G. USB-C port
H. Mouse skates
I. Power switch
J. Optical gaming sensor
K. Built-in wireless charging receiver module
L. USB receiver
M. USB cable adapter
N. USB-C to USB-A extension cable
Document No. 480HX-MC006B.A01
HyperX Pulsefire DartTM
Page 4 of 7
Specifications
Ergonomic: Ergonomic
Sensor: Pixart PMW3389
Resolution: Up to 16000 DPI
Speed: 450ips
Acceleration: 50G
Buttons: 6
Left / Right buttons switches: Omron
Left / Right buttons durability: 50 million clicks
Light effects: Per-LED RGB lighting1
Onboard memory: 1 profile
Connection type: 2.4GHz wireless / wired
Battery life2: 90 hours – LED off / 50 hours – Default LED lighting
Charging type: Wireless Qi charging3 / wired
Polling rate: 1000Hz
Cable type: Detachable charging/data cable
Weight (without cable): 112g
Weight (with cable): 130g
Dimensions (L x W x H): 124.8mm x 73.9mm x 43.6mm
Cable length: 1.8m
1Per-LED RGB lighting customizable with HyperX NGENUITY Software.
2Battery life varies based on usage and computing conditions.
3Qi wireless charger sold separately.
Document No. 480HX-MC006B.A01
HyperX Pulsefire DartTM
Page 5 of 7
Installation
Wireless Mode
Connect your USB receiver to USB cable adapter, and USB-C to USB-A extension cable to a
PC USB port. For optimal placement, please keep the USB receiver within 20 cm of the
mouse.
Wired Mode
Connect your USB-C to USB-A extension cable to your mouse and to a PC USB port.
Document No. 480HX-MC006B.A01
HyperX Pulsefire DartTM
Page 6 of 7
Charging
Wireless Charging
*Charging base not included
Wired Charging
Document No. 480HX-MC006B.A01
HyperX Pulsefire DartTM
Page 7 of 7
Function Keys
Function Keys
Secondary Feature
DPI button
Change between DPI presets. Default values are:
- 800 DPI (blue).
- 1600 DPI (yellow).
- 3200 DPI (green).
HyperX NGENUITY Software
To customize lighting, DPI, and macro settings, download the HyperX NGENUITY Software here:
hyperxgaming.com/ngenuity.
Using with Console
Connect to PS4 or Xbox One using the included USB cable or dongle attachment.
Factory Reset
If you are experiencing any issue with the mouse, you can perform a factory reset. Onboard memory
will be cleared, and all settings will revert back to default.
Function Keys
Secondary Feature
Hold DPI button + mouse wheel
button down for 5 seconds
Perform a factory reset on the mouse.
Questions or Setup Issues?
Contact the HyperX support team at: hyperxgaming.com/support/
