Husqvarna YTH184T Guía de configuración

581 51 85-27 Rev. 4

ILLUSTRATED PARTS LIST

MFG. ID NO. 96041030600

CUSTOMER CATALOG NO. YTH184T

PRODUCT NO. 960 41 03-06

TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06

DECALS

NOTE: All component dimensions given in U.S. inches

1 inch = 25.4 mm

KEY PART

NO. NO. DESCRIPTION

wheel_art_1-vgt

WHEELS AND TIRES

KEY PART

NO. NO. DESCRIPTION

KEY PART

NO. NO. DESCRIPTION

16 16

1 532 05 91-92 Cap, Valve, Tire

2 532 06 51-39 Stem, Valve

3 532 13 83-36 Rim Assembly, Front

4 532 05 99-04 Tube, Front (Service Item Only)

5 532 10 62-22 Tire, Front

6 532 12 49-57 Fitting, Grease (Front Wheel Only)

7 532 12 49-59 Bearing, Flange (Front Wheel Only)

8 532 17 50-39 Cap, Axle (Front Wheel Only)

9 532 12 20-82 Tire, Rear

10 532 12 49-26 Tube, Rear (Service Item Only)

11 532 13 83-37 Rim Assembly, Rear

- - 532 14 43-34 Sealant, Tire (10 oz. Tube)

1 532 18 21-66 Decal, Cutfinger Warning

3 532 19 63-57 Decal, Warning Symbol

4 532 14 08-37 Decal, Brake Parking

5 532 40 03-89 Decal, Warning Symbol CE

6 532 18 04-32 Decal, Fender DB/CE

7 532 15 97-37 Decal, Brake/Clutch Symbol

8 532 16 03-96 Decal, Mower Sch.

9 532 14 50-05 Decal, Battery Dnge/Poi

10 532 15 97-36 Decal, Hot Muffler

12 532 19 68-41 Decal, Warning Eng. Symbol

14 532 44 74-37 Decal, Panel Side

16 581 62 73-01 Emblem

17 581 51 73-01 Decal, Replacement

- - 532 16 69-60 Decal, Bypass

- - 532 16 25-98 Decal, Load Limit

- - 532 43 98-82 Pad, Footrest, LH

- - 532 43 98-81 Pad, Footrest, RH

- - 581 51 85-40 Manual Oper. Euro

- - 581 51 85-50 Manual Oper. Scand

- - 581 51 85-20 Manual Oper. E-Bloc

- - 581 51 85-30 Manual Oper. Baltic

10 10

NOTES

FUSE

STARTER

SOLENOID

BATTERY

ELECTRIC CLUTCH

CLUTCH/BRAKE

(PEDAL UP)

REVERSE SWITCH

(NOT IN REVERSE)

SEAT SWITCH

(NOT OCCUPIED)

SHORTING

CONNECTOR

CHASSIS

HARNESS

IGNITION

UNIT

HOUR

METER

REGULATOR

CHASSIS HARNESS

CONNECTOR

(MATING SIDE)

DASH HARNESS

CONNECTOR

(MATING SIDE)

LIGHT

SWITCH

HEADLIGHTS

STATOR

FUEL

LINE

FUEL SHUT-OFF

SOLENOID

(IF EQUIPPED)

JUNCTION

CONNECTOR

PTO SWITCH

(DISENGAGED)

SPARK

PLUGS GAP

(2 PLUGS ON

TWIN CYL. ENGINES)

28 VOLTS AC @ 3600 RPM (REGULATOR DISCONNECTED)

CHARGING SYSTEM OUTPUT

9-16AMPDC@3600 RPM

(OPTIONAL)

NON-REMOVABLE

CONNECTIONS

REMOVABLE

CONNECTIONS

WIRING INSULATED CLIPS

NOTE: IF WIRING INSULATED

CLIPS WERE REMOVED FOR

SERVICING OF UNIT, THEY

SHOULD BE RE-INSTALLED TO

PROPERLY SECURE YOUR

WIRING.

SCH12

IGNITION SWITCH

CIRCUITPOSITION

OFF

B+A1

RUN/OVERRIDE

B+S+A1

START

M+G+A1

B+A1

RUN

“MAKE”

L+A2

POWER OUTLET

(OPTIONAL)

12V

AMMETER

(OPTIONAL)

BLACK

BLACK /WHITE

ORANGE

RED

BROWN

BLUE

BLACK

BLACKBLACK

BLACK

RED

WHITE

GRAY

BLACK

PTO SWITCH

BLUE BLACK

TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06

SCHEMATIC

100

227

79 21

With Service Minder Option

4646

With 12V Outlet Option

103

T11S

102

105

With Charge Indicator Option

142

(+) (-)

143

TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06

ELECTRICAL

KEY PART

NO. NO. DESCRIPTION

1 532 16 34-65 Battery

2 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4

8 532 18 64-91 Battery Box

16 532 17 61-38 Switch Interlock

21 532 40 02-52 Harness Socket Light /w 4152J

22 532 00 41-52 Bulb, Light #1156

24 532 40 02-53 Cable Battery

25 532 41 28-95 Cable Starter

26 532 17 51-58 Fuse

27 873 51 04-00 Nut Keps Hex 1/4-20 unc

28 532 14 54-91 Cable Ground 21" Blk 6 Ga.

29 532 40 15-45 Switch Seat

30 532 19 33-50 Switch Ign

33 532 41 19-35 Key/Chain

34 532 11 07-12 Switch Light/Reset

40 581 02 28-01 Harness Ign Dash

41 817 72 04-08 Screw Thd Cut 1/4-20 x 1/2

42 532 13 15-63 Cover Terminal Red

43 532 19 25-07 Solenoid

46 532 40 17-63 Gauge Hourmeter

50 532 17 46-51 Switch PTO

55 817 06 05-12 Screw Thdrol 5/16-18 x 3/4

71 532 19 42-76 Harness Ign. Chassis/Lift

79 532 17 52-42 Socket Asm. Bulb

90 532 43 53-95 Cover Terminal Battery

91 532 19 02-70 Strap Battery

99 817 67 04-12 Screw Hexwsh Thdrol 1/4-20 x 3/4

100 819 09 14-16 Washer 9/32 x 7/8 x 16 Ga.

102 532 40 75-68 Switch Pigtail Tex ROS Tufftorq

105 532 40 44-54 Harness Pigtail

NOTE: All component dimensions given in U.S. inches

1 inch = 25.4 mm

TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06

ELECTRICAL

182

176

177

175

150

130

159

152

217

chassis-tex_GT HUSQ II_135_r2

178

183

236

235

161

162

196

221

213

218

165

228

194

180

189

194

162

199

159

195

202

203

205 151

206

137

214

204

229

208

207

297

191

130

234

335

176

336

350

176

306

125

146

TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06

CHASSIS AND ENCLOSURES

TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06

CHASSIS AND ENCLOSURES

KEY PART

NO. NO. DESCRIPTION

3 532 44 44-81 Applique

5 532 43 74-84 Dash

14 532 44 11-77 Hood

15 532 43 97-33 Lens LH

18 532 43 77-62 Grille

25 532 44 33-85 Lens RH

34 580 91 08-01 Plate Engine

36 817 06 05-12 Screw 5/16-18 x 3/4

37 532 44 12-08 Fender

52 873 68 05-00 Nut Crown Lock 5/16-18

58 532 41 22-81 Drawbar Upper

68 817 49 05-08 Screw 5/16-18 x 1/2

125 581 68 48-01 Clip Fuel Line

130 532 41 63-58 Screw #10 x 0.750 BOS Thread

137 532 40 75-90 Bumper Hood/Dash

146 581 85 79-01 Bolt

150 532 43 97-31 Duct Air

151 532 43 66-70 Bracket Pivot

152 532 43 98-70 Shield Browning

159 817 00 06-12 Screw Hexwsh Thdr 3/8-16 x 3/4

161 532 43 99-29 Console Fuel Window

162 532 14 24-32 Screw Hex Wsh Hi-Lo 1/4 x 1/2

165 532 19 68-26 Bracket Support Tank

175 532 19 63-04 Crossmember

176 532 40 07-76 Screw 10-24 x 5/8 Rnd Qdrx

177 532 19 52-27 Bushing Steering

178 532 19 97-82 Cargo Asm. Net

180 532 41 50-64 Chassis

182 532 40 68-59 Dash Lower

183 874 52 05-20 Bolt Hex 5/16-18 x 1-1/4

189 817 00 05-12 Screw 5/16-18 x 3/4

191 532 43 74-55 Insert Reflective RH

NOTE: All component dimensions given in U.S. inches

1 inch = 25.4 mm

KEY PART

NO. NO. DESCRIPTION

194 873 90 05-00 Nut Lock Hex Flange 5/16-18

195 532 40 41-37 Plug 12v Adapter

196 532 43 97-16 Console Asm. Deck Lift

199 532 19 82-59 Plate Deck Lift

202 532 43 97-28 Vent Side Hood RH

203 532 43 97-27 Vent Side Hood LH

204 532 44 06-65 Vent Hood Top

205 532 43 97-30 Skirt Hood Side RH

206 532 43 97-29 Skirt Hood Side LH

207 532 43 97-34 Bezel RH

208 532 43 97-35 Bezel LH

213 874 76 05-12 Bolt Hex Hd 5/16-18 unc x 3/4

214 532 19 91-45 Clip Retainer

217 532 40 91-67 Rod Pivot

218 532 19 63-95 Hood Stop

221 532 19 89-09 Reflector LH

228 532 19 51-61 Stud Fastner

229 532 44 14-63 Lid Ext. Fill

234 532 40 47-42 Bumper Hood

235 532 40 61-29 Spacer Fender

236 873 93 05-00 Nut Center Lock 5/16-18 unc

297 532 43 74-56 Insert Reflective LH

306 873 90 06-00 Nut Lock

335 532 44 82-04 Cover Dash RH

336 532 44 53-09 Cover Dash LH

350 532 44 51-43 Clip X-mas Tree

- - 532 40 09-44 Bumper Kit

TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06

DRIVE

125

226

227

125

80 125

170

216

143

171

213

221

160

206

207

209

92 125

116

197

196

161

225

125

116

205

116

230

183

205

drive-tex_K46_pedal_54_r3

186

189

187

185

188

184

167

160

221

159

211

220

208

210

214

125

215

153

166

211

222

163

153

190

TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06

DRIVE

KEY PART

NO. NO. DESCRIPTION

KEY PART

NO. NO. DESCRIPTION

NOTE: All component dimensions given in U.S. inches

1 inch = 25.4 mm

1 – – – – – – Transaxle, TUFFTORQ K46 BT

(426120) (Order parts from trans-

axle manufacturer.)

2 532 12 35-83 Key

15 819 13 13-16 Washer 13/32 x 13/16 x 16 Ga.

17 532 41 36-78 Spring Brake

26 532 19 96-79 Spring Return Cruise

29 532 40 38-06 Rod, Brake

33 812 00 00-01 Ring E

35 583 86 45-01 Rod Brake Park

42 532 12 48-72 Cover Foot Pedal

49 872 11 06-14 Bolt

50 532 19 43-27 Pulley Idler Flat

51 873 90 06-00 Lock Nut 3/8-16

52 532 19 43-26 Idler V-Groove

56 532 13 09-69 V-Belt Drive

64 532 19 78-65 Shaft Asm. Pedal Brake Control

70 532 43 96-61 Console Asm.

73 874 49 05-40 Bolt 5/16-18 x 2-1/2 Gr. 5

74 532 14 24-32 Screw 1/4 x 1/2

80 532 44 06-19 Strap Torque

92 874 76 05-20 Bolt 5/16-18 unc x 1.25

99 532 41 57-42 Rod Bypass

116 873 90 05-00 Nut Lock Hex Flange 5/16-18

125 817 00 05-12 Screw 5/16-18 x 3/4

143 817 49 05-08 Screw 5/16-18 x 1/2

153 532 12 47-88 Retainer Spring

159 876 02 04-12 Pin Cotter 1/8 x 3/4

160 532 16 94-84 Retainer Clip

161 532 10 57-09 Spring Return Clutch

163 532 44 82-75 Rod Control Pedal

166 532 42 91-64 Nut Push

167 532 40 52-57 Latch Brake Parking

170 532 19 43-22 Keeper Belt Centerspan

171 872 11 06-16 Bolt RDHD SQNK 3/8-16 unc x 2

183 532 13 70-57 Spacer Split

184 532 44 14-55 Handle Parking Brake

185 872 11 06-22 Bolt Rdhd Sqnk 3/8-16 x 2-3/4 Gr. 5

186 532 19 43-21 Spacer Retainer

187 819 13 32-10 Washer

188 532 19 43-23 Link Clutch Ground Drive

189 532 19 43-17 Bellcrank Ground Drive

190 532 19 43-18 Keeper Bellcrank Ground Drive

196 817 00 06-16 Screw 3/8-16 x 1

197 532 19 58-04 Link Clutch Anti-Rotation

205 532 12 17-48 Washer

206 532 19 78-67 Bracket Mount Latch

207 532 19 78-68 Latch Control

208 532 19 78-69 Gear Sector Control

209 532 19 95-92 Rod Control Cruise

210 532 19 78-60 Rocker Asm. Pedal

211 532 12 01-83 Bushing Brake Shaft

213 532 40 31-19 Knob Control Cruise

214 532 42 12-63 Pedal Forward

215 532 40 17-23 Pedal Reverse

216 532 19 61-31 Bracket Pulley Idler

220 532 19 89-08 Reflector RH

221 532 40 31-87 Retainer Spring Clip Handle

222 879 21 20-10 Washer 21/32 x1-1/4 10 Ga.

225 532 40 33-19 Keeper Belt Trans.

226 532 40 15-64 Bracket Mount Torque

227 817 49 05-12 Screw 5/16-18 x 3/4

230 532 18 89-67 Washer Hardened

TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06

ENGINE

SPARK ARRESTER KIT

engine-tex_7-kawa_r1

Tabla de contenidos

Otros manuales de Cortacésped de Husqvarna

Husqvarna

Husqvarna CTH 141 Manual de usuario

Husqvarna

Husqvarna RIDE MOWER 96043005200 Manual de usuario

Husqvarna

Husqvarna LB 146i Manual de usuario

Husqvarna

Husqvarna LC56 Manual de usuario

Husqvarna

Husqvarna LB 348V Manual de usuario

Husqvarna

Husqvarna 917.289540 Manual de usuario

Husqvarna

Husqvarna R 318X Manual de instrucciones

Husqvarna

Husqvarna YTH1848XP Manual de usuario

Husqvarna

Husqvarna LC 247iX Manual de usuario

Husqvarna

Husqvarna Rider 112C Manual de usuario

Husqvarna

Husqvarna AUTOMOWER 320 NERA Manual de usuario

Husqvarna

Husqvarna 917.374456 Manual de usuario

Husqvarna

Husqvarna LT126 Manual de usuario

Husqvarna

Husqvarna 532 42 57-62 Manual de usuario

Husqvarna

Husqvarna 967 844701-00 Manual de usuario

Husqvarna

Husqvarna 6522CH Manual de usuario

Husqvarna

Husqvarna HUSQVARNA LGT2554 Manual de usuario

Husqvarna

Husqvarna Ride-on Lawnmower with Petrol engine-62 cm... Manual de usuario

Husqvarna

Husqvarna WH3616 / 966638601 Manual de usuario

Husqvarna

Husqvarna Rider ProFlex 21 AWD Manual de usuario

Husqvarna

Husqvarna AUTOMOWER 105 Manual de usuario

Husqvarna

Husqvarna M53-150ARP Guía del usuario

Husqvarna

Husqvarna TS 354 Manual de usuario

Husqvarna

Husqvarna YTH22V42LS Manual de usuario

Manuales populares de Cortacésped de otras marcas

RHINO

RHINO 1958 Manual de usuario

Wolf Garten

Wolf Garten Compact plus 40 B Manual de usuario

Cub Cadet

Cub Cadet LTX 1045 Manual de usuario

Craftsman

Craftsman 917.378461 Manual de usuario

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manual de usuario

Challenge

Challenge CH18V2 Instrucciones de operación

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manual de usuario

DEWEZE

DEWEZE ATM-725 Manual de operación

Weed Eater

Weed Eater 180083 Manual de usuario

Better Outdoor Products

Better Outdoor Products Quick Series Manual de usuario

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manual de funcionamiento

MTD

MTD 795, 792, 791, 790 Manual de usuario

Toro

Toro Groundsmaster 3505-D Manual de usuario

Dennis

Dennis FT 610 Manual de usuario

AIRFORCE

AIRFORCE F-15 Gen 3 Manual de usuario

MTD

MTD 126-220-000 Manual de usuario

Toro

Toro 74806 Manual de usuario

Stihl

Stihl RMA 443 PV Manual de usuario
