ILLUSTRATED PARTS LIST

MODEL NUMBER LC 153S

PRODUCT NUMBER 961 41 02-90

MFG. ID. NUMBER 96141029000

HUSQVARNA ROTARY LAWN MOWER - MODEL NUMBER LC 153S (96141029000) PRODUCT NO. 961 41 02-90

14 15

2710

HUSQVARNA ROTARY LAWN MOWER - MODEL NUMBER LC 153S (96141029000) PRODUCT NO. 961 41 02-90

NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.

Failure to do so could be hazardous, damage your lawn mower and void your warranty.

1 580 63 87-08 Upper Handle Assembly

(Includes Foam Grip)

2 532 19 72-02 Handle, Lower

3 532 40 54-16 Spring, Rear Door, RH

4 581 90 21-01 Rope Guide

5 581 91 26-01 T-Knob

6 532 06 64-26 Wire, Tie

7 532 19 15-74 Bolt, Handle 5/16-18 x 1.75

8 532 18 23-98 Knob, Handle

9 532 42 68-12 Bar, Control, Operator Presence

10 532 18 88-21 Bolt, Carriage

11 532 75 11-53 Nut, Hex, Centerlock 5/16-18 UNC

12 532 05 17-93 Cotter, Hairpin

13 532 40 54-15 Spring, Rear Door, LH

14 532 17 88-48 Screw

15 532 43 00-34 Bracket, Upstop

16 584 39 59-01 Rear Door Assembly

17 532 18 41-93 Bolt, Rear Door

18 532 19 81-70 Plug, Mulcher

19 532 40 80-00 Kit, Housing

20 532 41 82-39 Handle Bracket Assembly, LH

21 532 41 82-51 Handle Bracket Assembly, RH

22 532 42 88-67 Screw, Hex Washer Head

23 532 16 31-83 Bolt, Hex Head 5/16-18 x 5/8

24 873 80 05-00 Nut, Hex, with Lock Washer

Insert 5/16-18

25 532 16 13-33 Bafﬂe, Side

26 532 16 34-09 Screw 12 x 5/8

29 532 44 03-86 Engine Zone Control Cable

30 532 42 11-76 Blade Adapter / Pulley

31 532 19 93-77 Blade, 21"

32 532 85 10-74 Washer, Hardened

33 532 85 02-63 Lockwasher, Helical Spring 3/8

34 532 85 10-84 Screw, Hex Head 3/8-24 x 1.38

37 532 15 04-06 Bolt, Engine

38 - - - Engine, Briggs & Stratton,

Model Number 126T02-1616-H1

(order parts from Briggs & Stratton)

39 581 00 29-04 Grassbag

40 532 41 19-51 Frame, Grassbag

41 532 18 21-66 Danger Decal

42 817 06 04-10 Screw

45 532 19 05-10 Mulcher Door Assembly

46 532 19 05-12 Deﬂector, Discharge

47 532 08 83-49 Nut, Hex

48 532 42 90-01 Belt Keeper

59 532 18 63-62 Grip, Handle, Foam

- - 115 62 45-20 Operator’s Manual, European

- - 115 62 45-10 Operator’s Manual, Scandinavian

- - 115 62 45-40 Operator’s Manual, East Bloc

- - 115 62 45-50 Operator’s Manual, Baltic

KEY PART

NO. NO. DESCRIPTION

KEY PART

NO. NO. DESCRIPTION

HUSQVARNA ROTARY LAWN MOWER - MODEL NUMBER LC 153S (96141029000) PRODUCT NO. 961 41 02-90

28 29

37 38

HUSQVARNA ROTARY LAWN MOWER - MODEL NUMBER LC 153S (96141029000) PRODUCT NO. 961 41 02-90

NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.

Failure to do so could be hazardous, damage your lawn mower and void your warranty.

1 581 07 68-01 Drive Control Assembly (Includes Cable)

2 580 65 93-03 Bar, Drive Control

8 532 19 17-30 Nut, Hex, Flangelock 1/4-20

11 532 40 65-58 Spring, Return

13 532 41 92-13 Gear Case Assembly, Complete

14 532 40 57-03 Pulley, Drive

15 532 08 83-48 Washer, Flat

16 532 40 71-47 Rod, Connecting

17 532 40 96-16 Spring, Extension

18 532 41 88-66 Spring Selector

19 532 19 00-69 Knob, Selector Spring

20 812 00 00-22 E-Ring

21 532 40 48-38 Bearing Assembly

23 532 16 45-55 Retainer, Drive Assembly, Stamped

24 817 06 04-10 Screw, Tapping, Hex Head 1/4-20 x 3/4

25 532 43 26-72 Drive Cover Assembly (Includes

Mounting Screw and Pushnut)

28 812 00 00-58 E-Ring 7/16

29 581 84 04-01 Cover, Dust, Wheel

31 532 40 48-45 Seal, Friction

32 581 68 51-01 Wheel & Tire Assembly, Rear

33 532 40 91-48 Nut, Hex, Flangelock 3/8-16

34 532 85 12-26 Washer

35 532 41 09-22 Shaft Assembly, Rear

36 532 41 09-33 Shaft Assembly, Front

37 532 16 14-63 Retainer, Front Shaft

38 532 16 34-09 Screw #12 x 5/8

39 532 40 70-59 Bolt, Shoulder, Semi-Gimlet Point

40 532 41 08-31 Wheel & Tire Assembly, Front 8 x 1-3/4

41 532 40 48-35 Pinion

42 532 19 74-80 O-Ring

44 532 40 65-80 V-Belt

47 532 06 77-25 Washer 1/2 x 1-1/2 x .134

50 532 41 31-04 Belt Keeper
