HUROM HG series Manual de usuario

Product Contents

HG Series

HG SerieS MANUAL

HG-2 4PJ12249_V.01.indd 1 2013-08-14 오후 1:50:12

Dear Hurom Customers

General description and parts names

Specific terms for parts

Precautions for safe use

Warnings and cautions

Slow Juicer assembly

Slow Juicer assembly in detail

How to use the appliance

Juice Cap and Extraction Seal

When the Auger is stopped during operation (How to use [Reverse/REV] button)

Important safeguards in use

Disassembly, cleaning and care

Chamber disassembly and wash

Sterilization and Easy Cleaning System

Spinning Brush disassembly and wash

Spinning Brush assembly

Chamber Seal assembly

Juice Cap Seal assembly

Troubleshooting

Appliance specifications

Warranty

Hurom Juicer Manual For Household Use (Warranty Included)

1 Read “Precautions for safe use (Page 4)” carefully and use the appliance properly.

2 Keep the manual within reach anytime and save it for future reference.

3 Check if the voltage indicated on the base of the appliance corresponds to the local voltage before you connect the appliance.

4 Any quality improvements are subject to change without notice.

CONTENTS

HG-2 4PJ12249_V.01.indd 2 2013-08-14 오후 1:50:12

With Hurom’s own Slow Squeezing Technology and the Juice Cap as an additional mixing function,

you can easily make personalized juice in rich tastes and ﬂavors in full preserved valuable nutrients.

1. Much More Nutrients and Taste: Your own personalized juice

Various mixed juice

Not only enjoying single fruit juice but also adding various ingredients to your taste and health, you can simply make

your own HUROM juice.

Hurom juice as an alternative meal

Make Hurom juice as an alternative meal in rich taste and balanced nutrients by mixing banana, corn or boiled potato,

sweet potato and pumkin, etc. supplementing calories with essential nutrients.

Hurom baby food

Mixing grain and vegetables with proper amount of water, you can easily make Hurom baby food for growth phases.

Soybean milk and soy juice

Unlike the traditional method that you must put boiled beans and water together, adjusting its portion while the Juice

Cap is closed, anyone can easily make soybean milk and soy juice in desired concentration.

2. Much More Convenient and User Friendly

Opening and closing the juice cap, you can adjust the amount of juice as desired without any drops when you pour

juice into a container.

3. Much More Advanced Easy Cleaning System (Page 17)

Unlike the method rinsing under tap, it is easier and simpler with the Juice Cap. Just fill up the chamber with water while

the Juice Cap is closed and then operate the appliance for easy washing.

HG-2 4PJ12249_V.01.indd 3 2013-08-14 오후 1:50:12

CLEANING BRUSH

HOPPER

SPINNING BRUSH

BASE

AUGER

02 l

PUSHER

PULP CONTAINER

JUICE CONTAINER

GENERAL DESCRIPTION AND PARTS NAMES

SMALL CLEANING BRUSH

CHAMBER

COARSE STRAINER

FINE STRAINER

HG-2 4PJ12249_V.01.indd 4 2013-08-14 오후 1:50:13

www.hurom.com I 03

NUMBER OF

ATTACHMENT

SPECIFIC TERMS FOR PARTS

1.Hopper front

arrow

8.Juice cap

3.Hopper rear arrow

5.Chamber arrow

6.Operating

switch

7. Juice outlet

9.Power cord

The holes of the strainer are small. Use it when making pure juice with hard fruits, beans or higher fibered

vegetables. It is useful to extract clearer juice.

The bigger hole of the strainer produce thicker juice when tender and soft fruits are extracted such as straw-

berries, kiwis and tomatoes. It is useful to extract more pulpy juice.

10.Grip

4.Base arrow

1 pusher, 1 hopper, 1 auger, 1 fine strainer, 1 coarse strainer, 1 spinning brush, 1 chamber, 1 base, 1 juice container, 1 pulp

container, 1 small cleaning brush, 1 cleaning brush, 1 manual

STRAINER*

COARSE STRAINER

FINE STRAINER

2.Pulp outlet

HG-2 4PJ12249_V.01.indd 5 2013-08-14 오후 1:50:14

All users of this appliance must read and understand this safety precaution before operating.

WARNING Hazards or unsafe practices which could result in serious personal injury or death.

This sign indicates contents of regulating or directing actions.

Specific instructions are written around or in the sign.

This sign indicates prohibited acts.

Specific prohibitions are written around or in the sign.

CAUTION Hazards or unsafe practices which could result in minor personal injury or appliance damage.

This sign indicates contents that may cause risk of a fire or an electrical shock.

Specific warnings are written in the sign.

SIGN ExAMPLES

This sign indicates contents that may cause risk of a fire or an electrical shock.

Specific warning is written in the sign.

PRECAUTIONS FOR SAFE USE

04 l

HG-2 4PJ12249_V.01.indd 6 2013-08-14 오후 1:50:14

WARNING Hazards or unsafe practices which could result in serious personal injury or death.

CAUTION Hazards or unsafe practices which could result in minor personal injury or appliance damage.

www.hurom.com l05

WARNINGS AND CAUTIONS

WARNING Hazards or unsafe practices which could result in serious personal injury or death.

DO NOT PLUG IN OR UNPLUG WITH WET HANDS.

It may cause an electric shock or an injury.

DO NOT USE OTHER THAN 230V - 240V AC.

It may cause an electric shock, a fire or an abnormal performance.

If the voltage is different, it may shorten the life of the motor or cause a failure.

PLUG THE POWER CORD CORRECTLY AND PUSH IT TIGHT IN A WALL

SOCkET.

It may cause an electric shock or a fire.

DO NOT MOISTEN THE bASE OR SPLASH WATER ON THE bASE.

Be careful not to let any liquids or other substances get into the switch on the appliance.

DO NOT OPERATE THE SWITCH WITH WET HANDS.

It may cause an electric shock or a fire.

NEVER ALTER THE APPLIANCE. ALSO, DO NOT DISASSEMbLE OR REPAIR bY YOUR-

SELF. DO NOT INSERT FINGERS, FOREIGN SUbSTANCES OR ObJECTS SUCH AS PINS

INTO GAPS OR HOLES IN THE bASE. It may cause a fire, an electric shock or a failure.

For any technical support, contact the authorized local Customer Care Center.

WHEN THE POWER CORD, WIRE WAS bROkEN OR DAMAGED OR THE PLUG-IN

PART bECAME LOOSE, DO NOT OPERATE IT.

It may cause an electric shock, a fire or an injury.

FOR SAFETY, MUST DO GROUNDING CONNECTION. ALSO, DO NOT DO THE

GROUNDING ON GAS PIPE, PLASTIC WATER PIPE, TELEPHONE WIRE, ETC.

It could cause an electric shock, a fire, a malfunction and an explosion.

Be sure to use the socket with ground connection.

IF THE SUPPLY CORD IS DAMAGED, IT MUST bE REPLACED bY THE MANUFAC-

TURER, ITS SERVICE OR SIMILARLY QUALIFIED PERSONS IN ORDER TO AVOID A

HAZARD.

If the power cord is damaged, it may cause an electric shock or a fire.

HG-2 4PJ12249_V.01.indd 7 2013-08-14 오후 1:50:15

NEVER DISASSEMbLE CHAMbER SET DURING OPERATION OR INSERT FINGERS,

FOREIGN ObJECTS SUCH AS FORkS, SPOONS ETC. INTO HOPPER CHUTE OR

JUICE OUTLET.

It may cause an injury, an accident or a failure.

DO NOT OPERATE WITHOUT LOCkING THE HOPPER PROPERLY.

It may cause an injury or a failure.

WHEN DETECTING A GAS LEAk, DO NOT INSERT THE POWER CORD INTO ITS

SLOT. OPEN THE WINDOW TO VENTILATE FULLY AND IMMEDIATELY.

It may cause an injury or a failure.

NEVER PUT A FINGER, A FORk OR A SPOON, ETC. INTO JUICE OUTLET.

It may cause an injury or a failure.

DURING THE OPERATION, DO NOT ATTEMPT TO MOVE THE bASE, DISASSEMbLE

THE CHAMbER SET OR PARTS AND TRY TO LOCk THEM.

It may cause an injury or a failure.

Any act of event needed, switch off first and unplug the power cord.

WARNINGS AND CAUTIONS

CAUTION Hazards or unsafe practices which could result in minor personal injury or appliance damage.

06 l

REV

IF AUGER ROTATION IS STOPPED IN NORMAL OPERATION, PRESS [REVERSE/

REV] bUTTON AND HOLD FOR 2~3 SECONDS AND THEN AFTER REVERSE OP-

ERATION IS COMPLETELY STOPPED, PRESS [ON] bUTTON AGAIN.

If such a stop event continues during the operation, the parts may be damaged and performance may be

deteriorated due to overheating in a motor.

When the problem continues, immediately stop the appliance and contact the local Customer Care Center.

THIS APPLIANCE IS NOT INTENDED FOR USE bY PERSONS (INCLUDING CHILDREN) WITH

REDUCED PHYSICAL, SENSORY OR MENTAL CAPAbILITIES, OR LACk OF ExPERIENCE

AND kNOWLEDGE, UNLESS THEY HAVE bEEN GIVEN SUPERVISION OR INSTRUCTION

CONCERNING USE OF THE APPLIANCE bY A PERSON RESPONSIbLE FOR THEIR SAFETY.

Children should be supervised to ensure that they do not play with the appliance.

HG-2 4PJ12249_V.01.indd 8 2013-08-14 오후 1:50:16

www.hurom.com l07

WARNINGS AND CAUTIONS

30minute

DO NOT OPERATE THE APPLIANCE FOR MORE THAN 30 MINUTES AT A TIME.

It may cause a motor failure due to overheating.

Cool it down sufficiently about 5 minutes and operate it again.

WHEN PLACING INGREDIENTS INTO THE HOPPER CHUTE, ONLY USE THE

PUSHER PROVIDED.

It may cause an injury or a failure.

DO NOT ALLOW A SEVERE SHOCk TO THE APPLIANCE OR DROP IT.

It may cause an electric shock, a fire or damage.

IF THE APPLIANCE GIVES OFF AN UNPLEASANT SMELL OR ExCESSIVE HEAT-

ING, SMOkE, STOP USING IMMEDIATELY AND CONTACT THE LOCAL CUSTOMER

CARE CENTER.

When using a new appliance, it gives off a smell and the smell disappears naturally over time.

ALWAYS UNPLUG THE APPLIANCE AFTER USE.

WHEN UNPLUGGING THE POWER CORD, MAkE SURE TO HOLD THE POWER

CORD.

If holding the wire to unplug, it may cause an electric shock or a fire.

DO NOT WASH AT HIGH TEMPERATURES OF 800C(1760F) OR MORE.

DO NOT PUT THE APPLIANCE IN A DISHWASHER, A DRYER OR A MICROWAVE

ETC.

It may cause a failure or parts deformation.

THE APPLIANCE WEIGHS AbOUT 5.4kG (11.9Lb).

WHEN MOVING THE APPLIANCE, ENSURE TO MOVE IT HOLDING GRIPS TIGHTLY AT

THE bASE bOTTOM WITH bOTH HANDS.

If attempting to hold chamber or the edge of the base, the base falls causing an injury or a failure.

WHEN USING THE APPLIANCE, bE CAREFUL FOR A NECkTIE, LONG NECkLACE,

SCARF, ETC. NOT TO bE ENTANGLED INTO HOPPER CHUTE.

It may cause an injury, a failure or a breakage.

PLACE THE APPLIANCE ON A FLAT AND STAbLE SURFACE.

It may cause an injury or a failure.

HG-2 4PJ12249_V.01.indd 9 2013-08-14 오후 1:50:18

Align the chamber arrow [ ] with hopper arrow

[ OPEN] and turn the hopper clockwise until

it clicks so that the hopper arrow [ CLOSE]

aligned with chamber arrow[ ].

OPEN

SLOW JUICER ASSEMbLY

Place the chamber in the base.

Make sure to press the auger down into the strainer in

STEP 2. The hopper does not close properly when the

auger does not ﬁt in completely.

Assemble the parts in the following order:

Chamber>Spinning Brush>Strainer.

Make sure chamber arrow [ ] aligns with

strainer arrow [ ].

08 l

A spinning brush can be assembled regardless

of the direction.

STEP

HG-2 4PJ12249_V.01.indd 10 2013-08-14 오후 1:50:18
