Portable Fan

Owner’s Manual

Model

90390

English

TABLE OF CONTENTS

Introduction ............................................................. 3

Safety and Warnings................................................ 3

Unpacking............................................................... 5

Fan Assembly .......................................................... 5

Base Assembly......................................................... 6

Stand Fan 6

Height Adjustment 6

Table Fan 7

Wall Mount 7

Remote Battery Installation ........................................ 8

Operation - Fan/remote ........................................... 8

Maintenance............................................................ 9

Technical Support................................................... 10

Warranty............................................................... 10

Products ................................................................ 12

INTRODUCTION

READ THIS ENTIRE MANUAL CAREFULLY BEFORE

BEGINNING INSTALLATION. SAVE THESE

INSTRUCTIONS FOR REFERENCE.

To reduce the risk of fire or electrical shock, DO NOT use

this fan with any solid-state speed control device.

When using electrical appliances, basic precautions

should always be taken to reduce the risk of fire, electric

shock and personal injury:

Read all instructions before using this fan.

1. Improper installation may result in the risk of fire,

electric shock or personal injury.

2. To prevent the risk of fire and electric shock, DO

NOT use the unit near windows. Rain and moisture

may create an electrical hazard.

3. The power plug must be removed from the power

socket when not in use, before cleaning, servicing,

maintenance and before moving to another location.

4. This product is intended for indoor use only. DO

NOT place fan in damp locations where humidity

is present.

5. The fan should be placed on a flat, stable surface or

tabletop to avoid overturning.

Thank you for choosing the Hunter 3 in 1 Fan. This

manual gives you complete instructions for assembling

and using your fan. Here are some the features you will

enjoy with your fan:

3An attractive design that enhances any decor

3A powerful motor for maximum air flow

3Three speeds to adjust your comfort level

3Remote controlled for added convenience

33 assembly options: floor stand, table top, or wall

mounted

3Parts of this fan, including the blades and the grill,

have been treated with Hunter’s Dust Armor protection,

making them less likely to attract dust and dirt.

SAFETY AND WARNINGS

6. Use fan only for intended use, as described in this

instruction manual.

7. To protect against electrical shock, DO NOT immerse

unit, plug or cord in water or spray with liquids.

8. Close supervision is necessary when any appliance

is used by or near children.

9. NEVER insert fingers, pencils or any other objects

through the grill when the fan is running.

10. DO NOT operate any appliance with a damaged

cord or plug, after the appliance malfunctions or has

been dropped or damaged in any manner.

11. To disconnect, grip plug and pull from wall outlet.

NEVER pull on cord to disconnect from outlet.

12. ALWAYS use on a dry surface.

13. This product is intended for household use only and

not for commercial or industrial use.

14. DO NOT operate fan in the presence of explosive

and/or flammable fumes.

15. DO NOT place fan or any parts near an open flame,

cooking or any other heating appliances.

16. DO NOT use near curtains, plants, window

treatments, etc.

17. The rubber feet on this product may interact with

wood and cause damage to furniture. Do not place

on fine wood furniture.

18. Do not mix old and new batteries.

19. Do not mix alkaline, standard (carbon-zinc), or

rechargables (ni-cad, ni-mh, etc) batteries

20. This product conforms to UL STD 507 and is certified

to STD C22.2 No.113

FAN ASSEMBLY

Figure 3.

Figure 4.

Figure 5.

1. Remove the Plastic Spinner (1) and the Plastic Nut (2)

from the fan motor housing. Figure 3.

2. Set the Rear Grill (3) against the front part of the

Motor Housing with the handle facing up. The 3 pins

on the motor housing should stick through the back

of the Rear Grill. Figure 4.

3. Screw the Plastic Nut (2) onto the fan and tightenly

firmly. Figure 4.

4. Remove the Plastic Sleeve from the motor housing

shaft and discard.

5. Install the Fan Blade (4) by sliding it over the motor

housing shaft, lining up the cut-outs on the back of

the Blade with the Retaining Pins on the Motor shaft.

Figure 5.

6. Screw the Spinner (1) onto the shaft counterclockwise

until secure. Figure 5.

7. Open the clips on the Front Grill

8. Set the Front Gill (5) into the notch on the bottom

of the Rear Grill (3) So the Hunter logo is facing

rightside up. Figure 6.

9. Close the clips On the Front Grill to hold both Grill

pieces in place. Insert the grill screw on the bottom of

the fan grill and tighten securely.

(1) Spinner

(2) Nut

(3) Rear Grill

(2) Nut

(4) Fan Blade

(1) Spinner

Figure 6.

(5) Front Guard

UNPACKING

As you unpack the fan, save the carton and packing

materials in case you want to move or ship the unit in

the future.

Carefully remove all items from the box.

NOTE: It is best to have someone hold the box while

you lift the fan and the protective packaging out of the

carton.

Make sure all shipping materials are removed from fan

before operating.

Stand Fan

Figure 9.

BASE ASSEMBLY

1. Slide the Telescope Rod (7) into the top of the Stand

Base (8) of the stand fan. The pole is notched so it will

only fit into the base 1 way. Figure 7.

2. Secure the Telescope Rod (7) by screwing the Base

Nut (9) onto it from underneath the base. Figure 8.

3. Slide the Fan Assembly onto the telescope pole of the

base until it rests on the top of the pole. Figure 9.

4. tighten the screw on the back of the fan Assembly

until secure.

Warning: Do not force pole into the Stand Base

as damage to the Telescope Pole may occur. Do not

overtighten the Base Nut or screws.

Figure 7.

(7) Telescope Pole

(8) Stand Base

Figure 8.

(9) Base Nut

Height Adjustment

1. Grip the upper part of the telescope pole and loosen

the Adjustment Knob.

2. Raise or lower the pole to the desired height.

3. Turn the Adjustment Knob until it is secure.

screw

Table Fan

Figure 10.

Figure 11.

1. Align the Fan Assembly over the Table Base (10) and

push together until secure. Figure 10.

2. Turn the Table Fan over and secure the 2 pieces

together using the 3 Table Base Screws. Figure 11. (10) Table

Base

Figure 12.

Figure 13.

Wall Mount

Before installing the Wall Mount Adapter, ensure the fan

location is close enough to a wall adapter that the fan

can be plugged in.

Caution: Due to the weight of this product, it is required

it be mounted into a wall stud. Failure to do so, could

cause the product to fall and/or damage the wall location

it is mounted in.

1. Place the Wall Mount Adapter (11) against the wall

and stud where you want to mount the fan.

2. Level the Wall Mount Adapter (11) for Asthetics.

3. Mark the hole locations on the wall with a pencil.

4. Using a 1/8 drill bit, drill the 2 holes for mounting.

5. Line the holes on the Wall Mount Adapter (11) to the

Wall holes and insert the 2 Wall Mount Screws and

tighten Securely. Figure 12.

6. Remove the phillips head screw from the base of the

Fan Assembly and insert the thumb screw.

7. Insert the Wall Mount Adapter (11) shaft into the Fan

assembly. Figure 13.

8. Tighten the Thumb screw in the back of the Fan

Assembly to secure fan.

(11) Wall Mount Adapter

Thumbscrew

Wall Stud

OPERATION  FAN/REMOTE

Figure 15.

- turns the unit on and off.

- Adjust the speed of the unit between High, medium,

and low.

- Used to set the running time to 1, 2, or 4 hours.

- Indicates the current running speed of the fan.

TIME R

- Shows the number of hours the timer is set to run.

To operate your unit from the controls on the fan, Figure

15 or from the remote control, Figure 16:

1. Ensure the fan is plugged in.

2. Press the button to turn the unit on.

3. Adjust the speed by pressing the button until you

reach the desired speed indicated on the fan base.

4. To set the timer, ensure the unit is on and repeatedly

press the button until the fan console displays the

number of hours you want the unit to run.

5. To start/stop fan oscillation, push or pull the knob on

the back of the fan assembly, or push the oscillation

button on the remote control. Figure 17.

6. To adjust the angle of the fan, grasp both sides of the

grill, and gently tilt up or down.

TIMER

REMOTE BATTERY INSTALLATION

Figure 14.

1. Turn the Remote Control over and Remove the Battery

Cover from the back by gently pressing down on the

tab and sliding down on the tab. Figure 14.

2. Insert 2 “AAA” Batteries into the battery compartment,

ensuring the positive and negative ends of the

batteries are installed correctly.

3. Slide the Battery Cover back and snap into place.

Figure 16.

Oscillation Knob

Figure 17.

MAINTENANCE

This fan is permanently lubricated and will not require

additional lubrication (oil) for the life of the fan.

This fan requires little maintenance and contains

no user serviceable parts. DO NOT try to fix

it yourself. Contact qualified service personnel

if servicing is needed.

Before cleaning, turn fan off and unplug from electrical

outlet. Wipe off excess dust with a lintfree cloth.

To ensure adequate air circulation to the motor, keep vents

located at the rear of the motor housing free from dust

accumulation. A vacuum cleaner hose can be used to

clean these vents.

DO NOT immerse the fan in water or any other liquid.

CLEANING THE GRILL AND BLADE:

1. Turn the fan off and unplug from the electrical outlet.

2. Disassemble the grills by carefully lifting the latches

around the outer ring.

3. Remove the front grill.

4. The blade may be removed by turning the Spinner

Knob clockwise.

3Use a dry or slightly damp lint free cloth to clean

the fan. Do not use a furniture polish or any other

cleaners that leave any residue, as they will damage

the protective Dust Armor.

3DO NOT allow water or any other liquid to get into

the motor housing or base.

3Reassemble the fan after blades and grills have dried

completely.

3DO NOT plug the fan into an electrical outlet until it

has been fully reassembled.

If you have any additional questions or problems with

your Hunter Portable Fan, please call:

USA: 1-888-830-1326

Canada: 1-866-268-1936

Hours of operation are from 7:00 am to 7:00 pm

Monday - Friday and 8:00 am to 5:00 pm on Saturday,

Central Time. You may also contact us over the Internet at

www.hunterfan.com.

TECHNICAL SUPPORT

1. Problem

3Fan will not oscillate.

Solution

3Push down on the knob on top of motor housing to

activate oscillation.

2. Problem

3Can not adjust the angle of the fan.

Solution

3Gentle grasp the grill of the fan and tilt up or down.

3. Problem

3Remote control will not operate.

Solution

3Remove the battery cover and confirm the batteries

are installed correctly according to polarity markings.

Warranty

WARRANTY

The Hunter Fan Company makes the following limited

warranty to the user or consumer purchaser of this Hunter

Portable fan:

If your Hunter Portable Fan motor fails at any time within

one year after the date of sale to you due to a defect in

material or workmanship, labor to repair the defect will

be provided free of charge at our nearest service center

or our Service Department in Memphis, Tennessee. You

will be responsible for labor costs after this one-year

period. The foregoing limited warranty applies only to

the motor itself, and does not apply to electronic controls

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Admirador de Hunter

Hunter

Hunter Waldon Manual de instrucciones

Hunter

Hunter 23412 Manual

Hunter

Hunter Midtown 54211 Manual de usuario

Hunter

Hunter 21101 Manual de instrucciones

Hunter

Hunter 23860 Manual

Hunter

Hunter Type 2A Series Manual de instrucciones

Hunter

Hunter 20179 Manual de instrucciones

Hunter

Hunter Exteriors 90195 Manual de usuario

Hunter

Hunter M3607 Manual de usuario

Hunter

Hunter Warrant Manual de usuario

Hunter

Hunter 59072 Manual de usuario

Hunter

Hunter 22540 Manual de instrucciones

Hunter

Hunter Wilder 51566 Manual de usuario

Hunter

Hunter 45065-01 Manual de instrucciones

Hunter

Hunter 22431 Manual de instrucciones

Hunter

Hunter Hunter Ceiling fans Manual de usuario

Hunter

Hunter Gilrock Manual de usuario

Hunter

Hunter Hunter Ceiling Fan Manual de usuario

Hunter

Hunter 28679 Manual de servicio

Hunter

Hunter 20808 Manual de usuario

Hunter

Hunter 42783-01 Manual de instrucciones

Hunter

Hunter Baseball Manual de instrucciones

Hunter

Hunter 28079 Manual

Hunter

Hunter 28150 Manual

Manuales populares de Admirador de otras marcas

ELTA FANS

ELTA FANS H03VV-F Manual de usuario

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manual de usuario

Panasonic

Panasonic FV-15NLFS1 Manual de usuario

Kompernass

Kompernass KH 1150 Manual de usuario

VES

VES FALA100/12V/TR Manual de usuario

Vertiv

Vertiv Liebert DCD Manual de usuario

Westinghouse

Westinghouse GFP Series Manual de usuario

Venmar

Venmar KUBIX HRV PLUS Series Manual de usuario

Maico

Maico ECR 31 Manual de usuario

Sonnenkonig

Sonnenkonig Dinky Manual de usuario

S&P

S&P ECOWATT HXBR Manual de usuario

Wider

Wider IMP03369BH Manual de usuario

Panasonic

Panasonic F-60DHN Manual de usuario

Hinkley

Hinkley HIGHLAND Manual de usuario

Broan

Broan 766BN Manual de usuario

Premium

Premium PFS16022 Instrucciones de montaje

Litex Industries

Litex Industries E-CGL52CB5C1 Manual de usuario

Lindab

Lindab LTDF Manual de usuario
