Hunter 30836 Manual de usuario

Total Air PurificationTotal Air PurificationTotal Air Purification

Form# 44029-01

20091215

HEPA

Air Purifier

Owner’s Manual

Models

30836

English

TABLE OF CONTENTS

Introduction ............................................................. 3

Safety Instructions..................................................... 3

Setting Up Your Air Purifier ....................................... 5

How The System Works ............................................ 6

Operating Your Air Purifier ....................................... 7

Air Purifier Maintenance........................................... 7

Check or Clean Your Pre-Filter 7

Check or Replace Your Filter 8

Replace The UVC Bulb 8

Clean the Unit 9

Troubleshooting...................................................... 10

Technical Support................................................... 10

Filter Ordering....................................................... 11

Warranty............................................................... 11

Products ................................................................ 11

Filter and UVC Calendar ........................................ 14

Notes .................................................................... 14

3High Particulate Efficiency: The HEPA filter

will remove up to 99.9% of particles as small as 0.3

micron particles from the air that passes through the

filter.

3Washable Pre-Filter: The washable pre-filter is

permanent and can be cleaned and reused.

3UVC Lamp: This Hunter Air Purifier is equipped

with a UVC germicidal lamp. UVC technology is a

proven germicide that is accepted by the FDA and

EPA as having the ability to kill pathogens in air that

are exposed to UVC light.

3Photocatalitic Oxidation: Reduces the amount

of toxic VOCs in the air caused by household cleaners

and products.

3Oxygenating Catalyst: Converts ozone and

smog into oxygen for cleaner air and peace of mind.

SAFETY INSTRUCTIONS

1. WARNING: This Air Purifier emits UVC radiation that

may cause eye and/or skin irritation. RG-3. Avoid

exposing eyes and skin to unshielded UVC Lamp.

2. CAUTION: The UVC Lamp may shatter and cause

injury if it is dropped or sustains impact. Wear safety

glasses and gloves when handling the UVC Lamp.

Do not use excessive force when handling the UVC

Lamp. Dispose of the UVC bulb in accordance with

local or State guidelines as trace amounts of Mercury

are present.

IMPORTANT!

READ ALL INSTRUCTIONS BEFORE USING THIS AIR

PURIFIER.

INTRODUCTION

Thank you for purchasing the Total Air Purification System

from Hunter Fan Company. You have purchased our

latest development in Portable Air Purification Systems.

This system has been developed to improve the quality of

the air you breathe.

Our HEPA Air Purification System out performs other air

purification systems by quickly and effectively removing

dust, smoke, and pollen particles as small as .3 microns

in size. The following innovative features are included in

your Hunter Air Purifier.

3. This Air Purifier is designed for use on a level floor and

may not work properly on an uneven floor. ALWAYS

place the Air Purifier on a firm, level floor. ALWAYS

place the Air Purifier at least six (6) inches away from

walls and heat sources such as stoves, radiators, or

heaters.

4. Place the Air Purifier in an area that is out of the reach

of children.

5. Before using the Air Purifier, extend the cord and

inspect for any signs of damage. DO NOT use the

product if the cord has been damaged.

6. To reduce the risk of electric shock, this product has

a polarized plug (one blade is wider than the other)

as a safety feature. This plug will fit into a polarized

outlet only one way. If the plug does not fit fully into

the outlet, reverse the plug. If it still does not fit, contact

a qualified electrician. DO NOT attempt to defeat or

override this safety feature.

7. ALWAYS UNPLUG the Air Purifier while it is being

cleaned.

8. DO NOT move or tilt the Air Purifier while it is in

operation. Turn off and unplug before moving.

9. DO NOT immerse the Air Purifier in water at any time

because permanent damage will occur. To properly

clean your Air Purifier, follow the instructions in the

Maintenance section of this manual “Air Purifier

Maintenance” on page 7.

10. This equipment should be inspected frequently and

collected dirt removed from it regularly to prevent

excessive accumulation that could result in flashover

or risk of fire.

Figure 1.

SETTING UP YOUR AIR PURIFIER

1. Take the Air Purifier out of the box and remove the

clear plastic protective bag and place the unit on a

firm, level surface.

2. Before turning on the Air Purifier, you need to confirm

that the filters are firmly in place and have not become

loose during shipping. To check the filters, push down

on the tab under the handle. Figure 1.

3. Gently pull the rear grill away from the unit and lift

away. Figure 2.

4. The washable Pre-Filter is mounted inside the back

grill of the unit. Confirm that it properly covers the

grill vents.

5. The HEPA Filter will be resting inside the unit. If

present, remove the plastic bag surrounding the filter

and place the filter back into the Air Purifier. The filter

should have arrows on the side to indicate air flow

and the direction the filter should be placed back into

the unit. Figure 3.

6. Set the tab on the bottom of the rear grill into the slot

in the base of the unit and rock the grill up until the

top tab snaps into place. Figure 4.

7. Plug the unit into a 120V electrical outlet.

Figure 2.

Figure 4.

Figure 3.

HEPA Filter

Tab

HOW THE SYSTEM WORKS

Dust and other irritants are pulled into the Air Purifier by the fan. The Washable Pre-

Filter attracts larger particles like pet dander, hair and traps them on the Pre-Filter. Smaller

particles such as dust, mold, and pollen pass through the Pre-Filter and are captured by the

HEPA filter. Up to 99.9% of particles can be captured.

The UVC Light helps kill particles not trapped on the HEPA Filter and the Photocatalytic

Oxidation screen removes harmful VOC’s. Clean, purified air is then released into the

room through the front grill as the Oxygenating Catalyst converts smog and ozone back

into oxygen. Figure 5.

Figure 5.

Grill

HEPA Filter

Washable

Pre-Filter

Unit

UVC

Light

Photocatalytic

Oxidizer

Oxygenating

Catalyst

Filter Block

AIR PURIFIER MAINTENANCE

It is necessary to periodically check your Air Purifier

for performance. If the Pre-Filter and/or HEPA Filter

are covered in dust and other captured particles, it will

be necessary to clean or replace one and or both. The

Pre-Filter and Filter should be checked at least every 6

months. The UVC Light should be replaced every year.

NOTE: Some environments may require more frequent

cleaning of each filter. In these situations, adjust the time

you check your filters to ensure the filters stay clog free to

optimize performance.

Figure 7.

Press

Down

OPERATING YOUR AIR PURIFIER

OFF Unit off

Low speed - Recommended for use when soft

background noise is unwanted.

Medium speed - Typical usage setting. Soft

background noise is not an issue.

High speed - Use when quick, efficient results

to a room’s air quality are desired.

The fan speed can be adjusted at any time by rotating the

dial so the indicator light aligns with the desired speed.

Press the UVC Light Button to turn on and off the UVC

function of your Air Purifier.

NOTE: The ON/OFF Indicator and the UVC Indicator

will stay lit while the fan and/or UVC is running.

Figure 6.

UVC ON/OFF

Speed

control

ON/OFF

Indicator

UVC

Indicator

Check or Clean Your Pre-Filter

1. Turn the Air Purifier off and disconnect from the wall.

2. Remove the rear grill on the back of the unit by

pressing the tab at the top of the unit, under the

handle and pull the rear grill outward. Figure 7.

3. Turn the Rear grill over and gently remove the Pre-

Filter from the grill.

4. Check the Pre-Filter side facing the grill for particle

coverage.

Figure 9.

Replace The UVC Bulb

The UVC light should be replaced once yearly. Follow

these instructions to remove and replace the UVC bulb.

1. Unplug the unit from the wall outlet and turn it over, so

the bottom of the unit is visible.

2. Using a small phillips screwdriver remove the 2 screws

holding the UVC Cover in place. Figure 9.

3. Gently push the tab on the UVC Cover and lift it away.

Figures 9. and 10.

4. Locate the UVC Bulb Carrier and turn it 45ocounter-

clockwise. Figure 11.

Figure 10.

Figure 11.

Tab

Screws

5. If the Pre-Filter needs to be cleaned, It may be

submerged in warm soapy water to clean. Gently lift

and submerge the filter several times to clean.

6. When complete, rinse the filter with warm water and

allow to dry completely.

Note: Wet parts placed into the unit can cause damage

to the filters and or the motor of the Air Purifier.

Check or Replace Your Filter

1. Turn the Air Purifier off and disconnect from the wall.

2. Remove the rear grill on the back of the unit by

pressing the tab at the top of the unit, under the

handle and pull the rear grill outward. Figure 7.

3. Remove the HEPA Filter from the unit.

4. Check the Filter for particle build-up.

5. The HEPA filter should be removed every 12 months

of use and matched to the color indicator on the inside

of the filter compartment. When the filter matches the

dark, charcoal gray indicator, it should be replaced.

Figure 13.

5. Lift the UVC Bulb Carrier out of the unit. Figure 12.

6. Unscrew the UVC Bulb From the carrier and dispose

of the UVC bulb in accordance with local or State

guidelines as trace amounts of Mercury are present.

7. Partially remove the new UVC Bulb from it’s packaging

being careful not to let the bulb come in contact with

your skin.

Note: Oils from your skin can cause damage to the bulb

and will prevent it from working.

8. Using the bag the bulb came in to prevent skin contact

with the bulb, screw the bulb into the Carrier socket.

Figure 13. Do not over tighten. Discard the bag.

9. Reinsert the Bulb carrier into the unit at a 45oangle

and turn clockwise to lock into the Air Purifier.

Note: If the UVC Bulb door is not re-installed correctly,

the unit will not run.

10. Reattach the UVC cover by inserting the back tabs

into the Air Purifier and snapping the tab back into

place. Figure 14.

11. Reinsert the 2 screws securing the UVC Cover into

place. Refer to Figure 9.

Figure 14.

Tabs

Clean the Unit

Clean the outside of the unit with a soft, damp cloth.

The rear grill can be cleaned in soapy water after it has

been removed from the unit and the pre-filter has been

removed.

NOTE: Ensure the grill is completely dry before

reinstalling it on the unit. Failure to do so could cause

damage to the filters or motor.

Figure 12.

TROUBLESHOOTING

Problem:

No Operation.

Solution:

3Confirm that the unit is plugged in.

3Check the installation of the Rear grill.

3Check the installation of the UVC Lamp Cover.

Problem:

Unit has reduced air flow or increased noise.

Solution:

3The filter may be clogged and needs to be

cleaned. See “Check or Replace Your Filter” on

page 10.

Problem:

The UVC Lamp is not operating.

Solution:

3Check the installation of the UVC Bulb.

3Replace the UVC Bulb. See “Replace The UVC Bulb”

on page 8.

If you have any additional questions or problems with

your Hunter Air Purifier, please call:

USA: 1-888-830-1326

Canada: 1-866-268-1936

Hours of operation are from 7:00 am to 7:00 pm

Monday - Friday and 8:00 am to 5:00 pm on Saturday,

Central Time. You may also contact us over the Internet at

www.hunterfan.com.

TECHNICAL SUPPORT

Otros manuales para 30836

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Purificador de aire de Hunter

Hunter

Hunter 30115 Manual de usuario

Hunter

Hunter 37711 Manual de usuario

Hunter

Hunter HEPAtech 30055 Manual de usuario

Hunter

Hunter EcoSilver HP850UV Manual de usuario

Hunter

Hunter QuietFlo 30145 Hoja de especificaciones

Hunter

Hunter QuietFlo 30130 Manual de usuario

Hunter

Hunter HEPAtech 30060 Manual de usuario

Hunter

Hunter QuietFlo 30401 Manual de usuario

Hunter

Hunter HEPATECH 30057A Manual de usuario

Hunter

Hunter HEPAtech 30010 Manual de usuario

Hunter

Hunter HEPAtech 30078 Manual de usuario

Hunter

Hunter PermaLife 37750 Manual de usuario

Hunter

Hunter HEPAtech 380 Manual de usuario

Hunter

Hunter HEPATECH 30378 Manual de usuario

Hunter

Hunter HEPAtech 30721A Manual de usuario

Hunter

Hunter 30709 Manual de usuario

Hunter

Hunter Argenius 30580 Manual de usuario

Hunter

Hunter 30715 Manual de usuario

Hunter

Hunter HEPAtech 30057 Manual de usuario

Hunter

Hunter HEPAtech Plus 30710 Manual de usuario

Hunter

Hunter 30895 Manual de usuario

Hunter

Hunter QuietFlo 30095 Manual de usuario

Hunter

Hunter PermaLife 30707 Guía del usuario

Hunter

Hunter permalife 30023 Manual de usuario

Manuales populares de Purificador de aire de otras marcas

IKEA

IKEA UPPÅTVIND Manual de usuario

Nash

Nash AP-1 PureSmart Manual de usuario

LG PH-U450 Series Manual de usuario

DeLonghi

DeLonghi DDSX 220WFA Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manual de usuario

Sharp

Sharp FU-40SE Manual de usuario

Philips

Philips AC2721 Manual de usuario

Hitachi

Hitachi EP-A3000 Manual de usuario

TruSens

TruSens Z-2000 Manual de usuario

Motorola

Motorola MBP87SN Manual de usuario

Beko

Beko ATP 7100I Manual de usuario

Carrier

Carrier INFINITY 1620 Manual de usuario

AtmosAir

AtmosAir P2002 Manual de usuario

Winix

Winix NK300 Manual de usuario

Friedrich

Friedrich C-90A Instrucciones de funcionamiento e instalación

Surgically Clean Air

Surgically Clean Air JADE2.0 Manual de usuario

Base aire

Base aire 555 Pro Manual de usuario

Champion

Champion CP25 Manual de usuario
