Electrician

Installation Manual

Icon 52 inch (132cm) Ceiling Fan

CEILING FAN MUST BE INSTALLED

BY A LICENSED ELECTRICIAN

(NO OTHER PERSONS SHOULD ATTEMPT TO INSTALL THIS FAN)

*After installation, electricians must tick off all items on the

quick checklist and fill out their details onto the back page of

the Fan Owner Warranty & Operations Manual

National Warranty Line

1300 360 280

Monday to Friday from 9am to 5pm EST

Only available within Australia

Hunter Pacific International Pty Ltd, Building 8, 256 New Line Road, Dural NSW 2158 Australia

ABN :18 063 521 666

ELECTRICIANS - TO PROTECT YOUR CUSTOMER’S WARRANTY, PLEASE READ

PAGE 2 OF THIS BOOKLET PRIOR TO THE INSTALLATION OF THIS PRODUCT.

NOTE: The Icon light fitting does not come standard,

however it can be bought as an accessory item.

IMPORTANT INFORMATION

ELECTRICIANS MUST READ PRIOR TO INSTALLATION

1. Distributor and installer details and purchase receipts are essential for on-site warranty claims

and must be presented to repair personnel, make sure you record your details in the Fan Owner

Warranty and Operations Manual.

2. Fans and fixed wiring products must only be installed by persons who are appropriately licensed

by the applicable State regulatory body. Therefore, to protect our repair personnel, on-site

warranty claims will not be accepted if products have been installed by unlicensed persons.

3. Damage caused by incorrect installation, force-majeure, electrical surges, lightning, power grid

fluctuations, water or by connection to alternative power supply sources (such as solar inverters,

etc.) is not eligible for warranty repair.

4. Blades must be replaced only as a complete set. Blades are supplied only as a pre-balanced set

and the replacement of individual blades may void the warranty by causing mechanical

damage to the motor, excessive noise or premature wear.

5. When products are installed in a location requiring special access equipment (such as

scaffolding or scissor lifts, etc) the cost of providing, installing and operating special access

equipment must be borne by the site owner.

For safety, and to protect your customers warranty, the following must be taken into

account when installing and operating the product(s):

IF THERE ARE ANY PROBLEMS WITH THE PRODUCT AT TIME OF

INSTALLATION THE INSTALLER MUST CONTACT THE WARRANTY

HOT LINE NUMBER 1300 360 280. BEFORE LEAVING THE JOB

SITE. PLEASE DO NOT REMOVE THE FAN FROM THE CEILING

ONCE INSTALLED UNLESS INSTRUCTED TO DO SO.

(a) DO NOT USE SOLID-STATE WALL CONTROLLERS. Neither leading nor lagging edge

controllers will give satisfactory performance. Wall controls must only be types approved

for use by Hunter Pacific International.

(b) The fan, light and bracket must be earthed.

(d) Mounting bracket must be firmly screwed to a solid structure such as a concrete ceiling,

steel structure or timber framing. If additional bracing is added it must be firmly secured to

the rafters and not left floating on the ceiling. Special mounts, such as T-hooks, are

available for certain types of installation.

(e) After installation, fan blades must be at least 2.1 m (7 feet) above floor level.

(f) The use of these products by children and the infirm must be under supervision.

Electrician

Installation Manual

Icon 52 inch (132cm) Ceiling Fan

Hanger Bracket

Hex Head Screw

Ball Joint

Canopy Cover

Parts List - Icon Fan

Part Qty Part Qty Part Qty

Blades 4 Base Plate 1 Canopy Cover Screws 2

Blade Screws 12 HPI Wall Controller 1 Canopy Cover 1

Blade Washers 12 Hanger Bracket 1 Motor Housing 1

Wall Speed Capacitor 1 Hex Head Screw 2

Ball Joint 1 15cm Down Rod 1 Reversing Switch Cover 1

Ball Joint Screw 1 Down Rod Pin Screw 1

Ball Joint Pin 1 Down Rod Short Screw 1

Blade

Blade Screw

Base Plate

Motor Housing

Electrician

Installation Manual

Icon 52 inch (132cm) Ceiling Fan

IMPORTANT INFORMATION

The table below contains information that can help you quickly identify the product you are

installing. If you have any difficulties installing our product, we recommend you to call our warranty

line on 1300 360 280 for advice.

Icon Ceiling Fans 132cm (52”)

CODE FAN MODEL NAME COLOUR

420 Icon Timber White Motor & Blades

422 Icon Timber Brushed Aluminium Motor

& Brushed Silver Blades

1. Do not attempt to operate the fan (or optional light kit) with any wall control that is

not approved by Hunter Pacific for use with its fans. DO NOT use solid state

controllers. The use of unapproved controllers will void your warranty.

2. Do not mix blade sets from one fan to another as this may upset the balance of

the fan. If only one blade is damaged you are still required to replace with a new set.

Electrician

Installation Manual

Icon 52 inch (132cm) Ceiling Fan

Icon Lights Kits

CODE COLOUR

940 White

942 Brushed Aluminium

The table below advises accessory items that can be purchased for the Icon fan.

STEP 3 (Fig. 3)

a) Hang the ball joint into the hanger bracket.

Ensure the groove on the hanger bracket is

locked into the slot on the ball joint.

(This is important to ensure the fan will not

wobble and the weight of the fan is supported).

1. Do not attempt to operate the fan (or optional light kit) with any wall control that is

not approved by Hunter Pacific for use with its fans. DO NOT use solid state

controllers. The use of unapproved controllers will void your warranty.

2. Do not mix blade sets from one fan to another as this may upset the balance of

the fan. If only one blade is damaged you are still required to replace with a new set.

Installation Instructions

(Assembling the fan)

STEP 2 (Fig. 2)

a) Drill a hole in the timber nogging for wiring.

b) Secure the hanger bracket onto the timber

nogging, using the two hex head screws

provided. The timber nogging should be supplied

by the installing electrician and must be

supported between the two ceiling joists as

shown in the diagram above.

STEP 1 (Fig. 1)

PERFORM THIS STEP IF THE WIRES HAVE NOT

BEEN FED THROUGH THE DOWN ROD.

a) Loosen the ball joint screw and remove the

ball joint pin to separate the down rod from the

ball joint.

b) Feed wires from motor housing up and

through the down rod.

c) Insert the down rod pin screw through the

connection collar and the down rod (avoid

pinching wires). Tighten down rod pin screw.

Secure down rod with the other shorter down

rod screw provided.

d) Slide on canopy cover and refit the ball joint.

If an extension rod needs to be installed

please go to page 11.

Hanger

Bracket

Down Rod

Fig. 2

Timber Nogging

Hex Head Screw

Hanger

Bracket

Fig. 3

Fig. 1

Down Rod

Down Rod Pin Screw

Canopy Cover

Connection Collar

Motor Housing

Electrician

Installation Manual

Icon 52 inch (132cm) Ceiling Fan

Ball Joint

Installation Instructions

(Assembling the fan )

Fig. 4

Green

Earth Wires

STEP 4 (Fig 4 & 5)

a) Connect wires from the fan with wires in

the ceiling via the terminal block on the

hanger bracket refer to figure 4 and 5.

b) Make sure earth wires are also connected.

c) Connect light wires (red/white) if a light

fitting is going to be used. (Cap seal light

wires if a light fitting is not going to be used).

Wiring Instructions (with and without accessory light)

Brown

Blue

Red/White Earth Wires

1. Do not attempt to operate the fan (or optional light kit) with any wall control that is

not approved by Hunter Pacific for use with its fans. DO NOT use solid state

controllers. The use of unapproved controllers will void your warranty.

2. Do not mix blade sets from one fan to another as this may upset the balance of

the fan. If only one blade is damaged you are still required to replace with a new set.

Supply

E N A

A A

FA LA E N

Green-yellow

Black

Red

Brown

White or Red

Green-yellow

Blue

Fan Wiring

Combi

Control

Separate

Control

Separate terminal

For when 3 pole

Block is fitted.

Wiring for use with 3 pole block

- Colours representative only

- Separate extension terminal for active

for light when 3 pole block fitted.

Fig. 5

Electrician

Installation Manual

Icon 52 inch (132cm) Ceiling Fan

Installation Instructions

(Assembling the fan )

STEP 5 (Fig 6)

a) Slide canopy cover up and over the

hanger bracket.

b) Twist the canopy to locate screws holes

then tighten canopy screws half way.

c) Now twist the canopy cover in the

opposite direction and fully tighten screws

until the canopy cover is stabilized.

Fig. 6

1. Do not attempt to operate the fan (or optional light kit) with any wall control that is

not approved by Hunter Pacific for use with its fans. DO NOT use solid state

controllers. The use of unapproved controllers will void your warranty.

2. Do not mix blade sets from one fan to another as this may upset the balance of

the fan. If only one blade is damaged you are still required to replace with a new set.

Fig. 7

Hanger Bracket

Canopy Cover

STEP 6 (Fig 7)

a) Remove the base plate, you can do this

by spreading out your fingers and pressing

your hand against the base plate. Push

upwards and turn anticlockwise until the

tabs unlock.

b) Once the base plate is removed, the

internal blade carriers will be exposed. Insert

blades and attach them to the motor housing

as shown in figure 8.

c) Tighten the 3 blade screws firmly but do

not over tighten.

d) Install blades for each fan individually, do

not mix blades from different fans as this will

up set the balance of the fan.

Blade

Blade Screws

Motor Housing

Tabs

Base Plate

Electrician

Installation Manual

Icon 52 inch (132cm) Ceiling Fan

Down Rod

Installation Instructions

(Assembling the fan)

1. Do not attempt to operate the fan (or optional light kit) with any wall control that is

not approved by Hunter Pacific for use with its fans. DO NOT use solid state

controllers. The use of unapproved controllers will void your warranty.

2. Do not mix blade sets from one fan to another as this may upset the balance of

the fan. If only one blade is damaged you are still required to replace with a new set.

Fig. 8 STEP 7 (Fig. 8)

a) Once all blades are attached to the motor

housing, refit the base plate by gently

pushing it upwards and turning it clockwise.

The tabs should lock in to place ensuring

the base plate is securely attached to the

motor housing.

STEP 8 (Fig. 9)

a) Reverse switch should be in the down

position for Summer (fan spins anticlockwise)

and in the up position for Winter (fan spins

clockwise).

b) Make the sure reverse switch is not stuck in

its neutral position otherwise the fan will not

spin.

Fig. 9

Tab slots

Tabs

Base Plate

Reverse

Switch

Electrician

Installation Manual

Icon 52 inch (132cm) Ceiling Fan

Installation Instructions

(Attaching an accessory light kit)

1. Do not attempt to operate the fan (or optional light kit) with any wall control that is

not approved by Hunter Pacific for use with its fans. DO NOT use solid state

controllers. The use of unapproved controllers will void your warranty.

2. Do not mix blade sets from one fan to another as this may upset the balance of

the fan. If only one blade is damaged you are still required to replace with a new set.

Electrician

Installation Manual

Icon 52 inch (132cm) Ceiling Fan

Fig. 11

Tabs

Slots

Light

Wires

Light

Assembly Kit

Globe

STEP 2 (Fig. 11)

a) Using the connectors on the wires

connect the light wire from the motor

housing with the light wires on the light

assembly.

b) Attach and secure the light assembly

kit using the 3 screws provided.

c) Plug the light globe into the socket.

DO NOT touch the light globe with

your fingers, use a tissue. It is

extremely important to keep the globe

clean. If the globe is dirty, clean it

carefully with a cloth or tissue. Dirt on

the globe will cause it to fail almost

immediately.

NOTE: Do not use globes other than the

specified ones.

Tabs

Slots

Tabs

Base Plate

STEP 1 (Fig. 10)

a) Remove the base plate, you can do this

by spreading out your fingers and pressing

your hand against the base plate. Push

upwards and turn anticlockwise until the

tabs unlock.

Fig. 10

Screws

Installation Instructions

(Attaching an accessory light kit)

1. Do not attempt to operate the fan (or optional light kit) with any wall control that is

not approved by Hunter Pacific for use with its fans. DO NOT use solid state

controllers. The use of unapproved controllers will void your warranty.

2. Do not mix blade sets from one fan to another as this may upset the balance of

the fan. If only one blade is damaged you are still required to replace with a new set.

Electrician

Installation Manual

Icon 52 inch (132cm) Ceiling Fan

Trouble Shooting Tips - Light

 Light will not turn on - Make sure globe has not blown and it is properly fitted

between the metal prongs. Check all light wires in the light kit, the terminal block

in the canopy cover and the wall switch has been connected together correctly.

 Light is not corresponding to remote control- Make sure globe has not

blown and it is properly fitted between the metal prongs. Check all light wires in

the light kit, the terminal block in the canopy cover and the wall switch has been

connected together correctly. Check dip switch settings in remote hand piece

and remote receiver are corresponding.

 Light wires appear to be missing or too short - Wires may be stuck in the

motor housing. Carefully pull wires out of the motor housing, careful not to strip

the wires as this may cause the fan to short.

 Light flickers or flashes - Check globe is secured between the metal prongs in

the light kit. Make sure you are using the globes specified.

Tab

Slots

Glass Cover

STEP 3 (Fig. 12)

a) Once globe is placed into its socket

properly, the glass cover can be fitted on

to the fan.

b) Gently push the glass cover upwards

and turn it clockwise. The tabs should

lock in to place ensuring the glass cover

is securely attached to the motor

housing.

Fig. 12

Tabs

Tabla de contenidos

Otros manuales de Admirador de Hunter Pacific

Hunter Pacific

Hunter Pacific Majestic Magnum Manual de usuario

Hunter Pacific

Hunter Pacific POLAR DC P3B2571 Manual de instrucciones

Hunter Pacific

Hunter Pacific RADICAL 2 Manual de instrucciones

Hunter Pacific

Hunter Pacific Icon Fan Manual de usuario

Hunter Pacific

Hunter Pacific X-OVER DC Manual de instrucciones

Hunter Pacific

Hunter Pacific Typhoon Timber 42" Manual de usuario

Hunter Pacific

Hunter Pacific Concept Manual de usuario

Hunter Pacific

Hunter Pacific Typhoon Manual de usuario

Hunter Pacific

Hunter Pacific Coolah Manual de instrucciones

Hunter Pacific

Hunter Pacific Majestic Palm Manual de usuario

Hunter Pacific

Hunter Pacific Concept Guía de inicio rápido

Hunter Pacific

Hunter Pacific Majestic Rosewood Manual de usuario

Hunter Pacific

Hunter Pacific Majestic Duo Manual de usuario

Hunter Pacific

Hunter Pacific Typhoon Mach 2 Timber Manual de usuario

Hunter Pacific

Hunter Pacific Attitude Manual de usuario

Hunter Pacific

Hunter Pacific Intercept II Manual de usuario

Hunter Pacific

Hunter Pacific Majestic Penta Manual de usuario

Hunter Pacific

Hunter Pacific Majestic Madagascar Manual de usuario

Hunter Pacific

Hunter Pacific AQUA DC AIP2661 Manual de instrucciones

Hunter Pacific

Hunter Pacific Majestic Coolah Manual de usuario

Hunter Pacific

Hunter Pacific Majestic Micro Manual de usuario

Hunter Pacific

Hunter Pacific VortX V500i Guía de instalación

Hunter Pacific

Hunter Pacific Majestic Everglade Manual de usuario

Hunter Pacific

Hunter Pacific Aurora Alternatives 2 Manual de usuario

Manuales populares de Admirador de otras marcas

ELTA FANS

ELTA FANS H03VV-F Manual de usuario

Hunter

Hunter 20714 Manual de instrucciones

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manual de usuario

Hunter

Hunter Caraway Manual de instrucciones

Panasonic

Panasonic FV-15NLFS1 Manual de usuario

Kompernass

Kompernass KH 1150 Manual de usuario

VES

VES FALA100/12V/TR Manual de usuario

Vertiv

Vertiv Liebert DCD Manual de usuario

Westinghouse

Westinghouse GFP Series Manual de usuario

Venmar

Venmar KUBIX HRV PLUS Series Manual de usuario

Maico

Maico ECR 31 Manual de usuario

Sonnenkonig

Sonnenkonig Dinky Manual de usuario

S&P

S&P ECOWATT HXBR Manual de usuario

Wider

Wider IMP03369BH Manual de usuario

Panasonic

Panasonic F-60DHN Manual de usuario

Hinkley

Hinkley HIGHLAND Manual de usuario

Broan

Broan 766BN Manual de usuario

Premium

Premium PFS16022 Instrucciones de montaje
