Huawei Ascend Y 101 Manual de usuario

Welcome to HUAWEI

Quick Start Guide

HUAWEI Ascend Y 101

Personal Information and Data

Security

The use of some functions or third-party applications on your device

could result in your personal information and data being lost or

becoming accessible to others. Several measures are

recommended to help you protect personal and confidential

information.

• Place your device in a safe area to prevent it from unauthorized

use.

• Set your device screen to lock and create a password or unlock

pattern to open it.

• Periodically back up personal information kept on your

SIM/USIM card, memory card, or stored in your device memory.

If you change to a different device, be sure to move or delete any

personal information on your old device.

• If you are worried about viruses when you receive messages or

emails from a stranger, you can delete them without opening

them.

• If you use your device to browse the Internet, avoid websites that

might pose a security risk to avoid theft of your personal

information.

• If you use services such as Wi-Fi tether or Bluetooth, set

passwords for these services to prevent unauthorized access.

When these services are not in use, turn them off.

• Install or upgrade device security software and regularly scan for

viruses.

• Be sure to obtain third-party applications from a legitimate

source. Downloaded third-party applications should be scanned

for viruses.

• Install security software or patches released by Huawei or third-

party application providers.

• Some applications require and transmit location information. As

a result, a third-party may be able to share your location

information.

• Your device may provide detection and diagnostic information to

third-party application providers. Third party vendors use this

information to improve their products and services.

• If you have concerns about the security of your personal

information and data, please contact mobile@huawei.com.

What is in Your Box

Phone at a Glance

All the pictures in this guide are for your reference only. Your

phone’s actual display features may be different to those

described here, depending on its software version.

• Mobile phone

• USB cable

•Battery

• Charger

• microSD card (Optional)

• Quick Start Guide

Headset jack

Earphone

Volume Keys

micro USB

charging port

Camera

Loudspeaker

Microphone

Power key

(Optional) Installing the microSD

Card

If you want to expand your phone memory, you can also insert a

microSD card.

1. Remove the battery cover.

2. Insert the microSD card into the card slot as shown in the

diagram.

Installing the SIM Card

There are two steps to install the SIM card:

1. Remove the battery cover.

2. Insert the SIM card.

Installing the Battery

1. Angle the edge labeled

(with the contacts) into the bottom end

of the battery compartment.

2. Push the edge labeled

into the compartment until the battery

clicks firmly into place.

Charging the Battery

Before charging the battery, ensure that it has been properly installed

on your phone.

1. Connect the USB cable that came with your mobile phone to

the charger.

2. Connect the other end of the USB cable to your mobile phone.

Then, to start charging, plug the charger into an electrical outlet.

If you charge your mobile phone while it is powered on, the battery

icon on the notification bar indicates the charging status. When the

battery icon changes to , your mobile phone is fully charged.

If you want to charge the battery by connecting the phone to a

computer, use the USB2.0 interface or a USB interface in a higher

version.

Status Indicator

The color of the status indicator tells you the status of your mobile

phone’s battery.

Touchscreen Actions

Using your finger on the touchscreen, you can operate your phone

conveniently.

Powering On Your Mobile Phone

Press the

power key

. The first time you power on your phone,

you will be asked to sign in to your account and set up your mobile

phone.

Status Indicator

Green: Fully charged (when connected to charger).

Orange: Charging in progress (when connected to charger).

Red: Battery low.

Drag

TouchTouch & hold Double touch

Rotate Flick

If personal identification number (PIN) protection is enabled on

your mobile phone, you must enter your PIN before using the

mobile phone.

Power-On Setup

When you turn on your phone for the first time, You can follow the

onscreen instructions to complete the setup, or skip the setup and do

it at another time.

Turning On Fast Boot

1. Touch >

Settings

Applications

2. Select the

Fast boot

check box.

Do not turn on

Fast boot

while on an airplane.

Powering Off Your Mobile Phone

1. Press and hold the

power key

to open the

Phone

options

menu.

2. Touch

Power off

Fast boot

is enabled, the phone will enter the deep sleep

mode. If

Fast boot

is disabled, touch

to shut down the

phone.

Locking the Screen

• When your phone is on, press the

power key

to lock the

screen. When the screen is locked, you can still receive

messages and calls.

• If your phone is idle for a while, the screen will lock

automatically.

Unlocking the Screen

1. Press the

power key

or to wake up the screen.

2. Drag the lock icon from left to right to unlock the screen.

Home Screen

You can set up the Home screen according to your own

preferences, for example by adding a shortcut or a widget to your

Home screen, or changing the wallpaper.

To return to the Home screen from any of its extensions, press .

When a new notification icon appears on the notification bar, place

your finger on the notification bar and flick down to open the

notification panel.

10:23

Flick your finger left or

right across the Home

screen.

Touch to view thumbnails

of the Home screen and its

extensions. Touch a thumbnail

to open the screen.

10:23

Adding a New Home Screen Item

1. Touch and hold a blank area on the Home screen until the

Add

to home screen

menu is displayed.

2. Select an item to add it to the Home screen.

Moving a Home Screen Item

1. Touch and hold an item on the Home screen until the item

expands in size and the mobile phone vibrates.

2. Without lifting your finger, drag the item to the desired position

on the screen, and then release it.

Removing a Home Screen Item

1. Touch and hold an item on the Home screen until the item

expands and the mobile phone vibrates.

2. Without lifting your finger, drag the item to the trash can. When

the item and the trash can turn red, the item is ready to be

removed.

3. Release the item to remove it from the Home screen.

Importing Contacts from a SIM

Card

1. In the contact list, touch >

Manage contacts

2. Touch

Copy from SIM card

10:23 10:23

3. Wait for the SIM card contents to be loaded. Select the contacts

you want to import or touch

Select All

to select all contacts.

4. Touch

Copy

5. If you have more than one account on your phone, touch the

account into which you want to import the contacts.

Adding a Contact

1. In the contact list, touch >

Create contact

2. If you have more than one account with contacts, touch the

account to which you want to add the contact.

3. Enter the contact's name, and then add detailed information

such as phone number and address.

4. When you are finished, touch

Save

to save the contact

information.

Making a Call with the Dialer

Application

On the home screen, touch to open the

Dialer

Your mobile phone supports the SmartDial function, that is, when

you touch numbers on the dialer, the phone automatically searches

among your contacts and lists the matching results ordered

according to the accuracy of the match. If no contacts match the

information entered, the phone will not display any result.

Creating and Sending a

Multimedia Message

On the home screen, touch to open the

Messaging

You can use multimedia messages to make everyday

communications very special. You can record a message and send

it as an audio file, sing 'Happy Birthday' and send it to friend, or send
