HTC TOUCH PRO 2 Manual de usuario

Quick Start Guide

Please Read Before Proceeding

THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX.

DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.

YOUR WARRANTY IS INVALIDATED IF YOU DISASSEMBLE OR ATTEMPT TO DISASSEMBLE

THE DEVICE.

PRIVACY RESTRICTIONS

Some countries require full disclosure of recorded telephone conversations, and stipulate that you must

inform the person with whom you are speaking that the conversation is being recorded. Always obey the

relevant laws and regulations of your country when using the recording feature of your PDA Phone.

LIMITATION OF DAMAGES

To the maximum extent permitted by applicable law, in no event shall HTC or its providers be liable to user or

any third party for any indirect, special, consequential, incidental or punitive damages of any kind in contract

or tort, including, but not limited to, injury, loss of revenue, loss of goodwill, loss of business opportunity,

loss of date, and/or loss of profits arising out of, or related to, in any manner, or the delivery, performance

or nonperformance of obligations, or use of the weather information, stock data, data or documentation

hereunder regardless of the foreseeability thereof.

FOR MORE INFORMATION

For health, safety, and regulatory information, see “Appendix: Safety and Other Notices”.

Table of Contents

Contents

1. Welcome to the HTC Touch Pro2 Quick Start Guide .................................. 4

2. Inside the Box .......................................................................................................... 4

3. Get to Know Your HTC Touch Pro2 ................................................................... 5

4. Install the Battery and Storage Card................................................................7

5. Get Started................................................................................................................ 9

6. Personalize Your HTC Touch Pro2....................................................................14

7. Add Contacts..........................................................................................................17

8. Experience People-centric Communication...............................................18

9. Make Calls ...............................................................................................................20

10. Send Text Messages.............................................................................................21

11. Set Up and Use E-mail.........................................................................................21

12. Keep Track of Your Appointments..................................................................23

13. Straight Talk™ .........................................................................................................24

14. Experience Internet Without the Wait...........................................................26

15. Use the Camera .....................................................................................................27

16. Manage Wi-Fi, Bluetooth and Other Connections....................................29

17. Synchronize Your HTC Touch Pro2 with Your Computer ........................30

18. Maintain the Performance of Your Device...................................................32

19. Troubleshooting Tips ..........................................................................................33

Appendix: Safety and Other Notices.....................................................................34

4 Quick Start Guide

1. Welcome to the HTC Touch Pro2 Quick Start Guide

Congratulations on your purchase of the HTC Touch Pro2!

This Quick Start Guide will help you get started with your HTC Touch Pro2. This

guide will walk you through the features we feel you will want to learn right

away when you use your HTC Touch Pro2.

For a more complete guide in using your HTC Touch Pro2, please refer to the

User Manual PDF that is on the Getting Started Disc.

Changing Networks on the Go!

Have you ever traveled to another country or outside your network carrier

service area only to find that you have to purchase or lease another cell phone?

After all, when traveling, you still want to keep in touch with friends and family

back home.

Your HTC Touch Pro2 Global Phone covers all the bases by incorporating a

SIM slot into its CDMA architecture. Now when you travel outside the range

of the Telus CDMA coverage area or roam internationally, you can install a SIM

card to access wireless services to make calls, send e-mail messages, browse

the Internet and more using GSM network technology. Don’t worry—you’re

connected!

Note Contact Telus about acquiring a SIM card for your phone.

2. Inside the Box

You should find the following items inside the box.

HTC Touch Pro2

Battery

AC adapter

Screen protector

•

Wired stereo headset

USB sync cable

Quick Start Guide

•

Extra stylus

Getting Started Disc

•

Quick Start Guide 5

3. Get to Know Your HTC Touch Pro2

Earpiece

Touch Screen

END/POWER

BACK

Zoom

Bar

TALK/SEND

Hardware

Keyboard

START

Light

Sensor

Notification LED

Strap Holder

Back Cover

3.2 Megapixel

Camera

MUTE

Dual Speaker

VOLUME

DOWN

Stylus

Microphone

SLEEP/LOCK

Sync Connector/

Earphone Jack/TV Out

Microphone 3.5 mm Audio Jack

6 Quick Start Guide

Opening the hardware keyboard

To use the hardware keyboard, slide the screen

panel to the right to reveal the keyboard.

The screen orientation automatically switches to

landscape mode when the keyboard is opened.

Adjusting the LCD screen angle

50° angle

The maximum tilting angle

is 50 degrees. Do not force

the screen to tilt further than

the maximum angle as it will

break the device.

Before you retract the screen,

be sure to adjust the screen

angle back to the original

horizontal position.

Quick Start Guide 7

4. Install the Battery and Storage Card

You need to remove the back cover before you can install the battery or storage

card. Also, make sure to always turn off the power before installing or replacing

the battery.

Note Your Global Phone accommodates a GSM SIM card for global coverage. Refer to

the User Manual PDF for instructions on inserting a SIM card. Contact Telus for

information on purchasing a SIM card for your phone.

To remove the back cover

Make sure your device is turned off.

Remove the stylus.

Note You need to temporarily remove the

stylus to be able to remove or replace

the back cover.

Firmly hold the device with both hands

and the front panel facing down.

Push the back cover up with your thumbs

until it disengages from the device and

then slide it up to remove.

8 Quick Start Guide

Battery

To install the battery

Align the battery’s exposed

copper contacts with the battery

connectors at the bottom part of

the battery compartment.

Insert the contacts side of the

battery first and then gently push

the battery into place.

Replace the back cover and insert

the stylus back into the stylus

compartment.

RESET

Groove

To remove the battery

Lift out the battery from the groove at the upper right side of the battery

compartment.

To charge the battery

Connect the USB connector of the AC adapter to the sync connector at the

bottom of your device.

Plug in the AC adapter to an electrical outlet to start charging the battery.

The battery will be fully charged after about 3 hours of charging.

Note Only the AC adapter and USB sync cable provided with your device must be used

to charge the battery.

Quick Start Guide 9

Storage card

To install the microSD card

Remove the stylus and then

remove the back cover.

Locate the microSD card slot on

the upper part of the exposed right

panel.

Insert the microSD card into the

slot with its gold contacts facing

down until it clicks into place.

Note To remove the microSD card, press to

eject it from the slot.

RESET

Storage

card slot

5. Get Started

After installing and charging the battery, you can now power on and start using

your device.

Turning on the power

Press the END/POWER button on front panel of your device.

Switching to Sleep mode

Press the SLEEP button to turn off the display temporarily and switch your

device to Sleep mode. Sleep mode suspends your device to a low power state

while the display is off in order to save battery power.

Your device automatically goes into Sleep mode when you leave the device idle

after a certain period of time. You are still able to receive messages and calls

while your device is in Sleep mode. Your device wakes up automatically when

you receive an incoming call. To wake up your device manually, press the SLEEP

button.

10 Quick Start Guide

Using the Start screen

Touch Start on the top-left corner of the screen

or press the START ( ) button to open the Start

screen. The Start screen gives you one-touch access

to the programs and settings of your device. You can

also add the shortcut icons of your favorite programs

in the Start screen so you can open them quickly.

Using the TouchFLO™3D Home screen

Your device’s main screen is the TouchFLO™ 3D Home screen which allows

finger-touch access to the most important functions such as favorite contacts,

text messages, e-mail, calendar, Internet, and more.

You will find the following tabs that on the TouchFLO 3D Home screen:

Home Music Settings

Weather

Internet Stock

Photos

and Videos

People Calendar

Messages

Mail
