HTC PH85110 Manual de usuario

Your HTC PH85110

User guide

2011/07/25 for certification review only

Conventions used in this guide

In this user guide, we use the following symbols to indicate useful and important

information:

This is a note. A note often gives additional information, such as what happens

when you choose to do or not to do a certain action. A note also provides

information that may only be applicable to some situations.

This is a tip. A tip gives you an alternative way to do a particular step or procedure,

or lets you know of an option that you may find helpful.

This indicates important information that you need in order to accomplish a certain

task or to get a feature to work properly.

This provides safety precaution information, that is, information that you need to be

careful about to prevent potential problems.

7 Conventions used in this guide

2011/07/25 for certification review only

Getting started

Inside the box

You will find the following inside the box:

§HTC PH85110

§Battery (preinstalled)

§USB cable

§3.5mm stereo headset

§Power adapter

§Quick start guide

§Safety and regulatory guide

HTC PH85110

Front panel

1. Home

2. Menu

3. Back

4. Search

5. Touch screen

6. Notification LED

7. Front camera

Top panel

1. 3.5mm headset jack

2. Power

8 Getting started

2011/07/25 for certification review only

Left and right panels

1. USB connector

2. Volume Up

3. Volume Down

4. Camcorder

5. Camera

Back panel

1. Back cover

2. Dual LED flash

3. Speaker

4. 8 megapixel camera

Bottom panel

1. Release button for the back cover

2. Microphone

9 Getting started

2011/07/25 for certification review only

Back cover

Removing the back cover

Remove the back cover to access the battery compartment, SIM card slot, and

storage card slot.

Make sure to switch off HTC PH85110 before removing the back cover.

1. Securely hold HTC PH85110 facing up.

2. Press and hold the Release button at the bottom of the phone, and then slightly

lift the front panel.

This detaches the bottom part of the phone from the back cover.

3. Gently pull HTC PH85110 out of its back cover.

10 Getting started

2011/07/25 for certification review only

Replacing the back cover

Your phone’s antennas are placed underneath the back cover. To get the best

signal for calls, Internet connection, and GPS navigation, be sure to secure the back

cover tightly to the phone.

1. Securely hold the back cover with the exposed side facing up.

2. Insert the top part of HTC PH85110 into the back cover.

3. Press HTC PH85110 down to lock the cover into place. You’ll hear a click when

the back cover is locked in place.

11 Getting started

2011/07/25 for certification review only

SIM card

The SIM card contains your phone number, service details, and memory for storing

phonebook contacts and/or text messages.

Inserting the SIM card

1. Take the back cover off.

2. Remove the battery.

3. With the SIM card’s gold contacts facing down and its cut-off corner facing out,

insert the SIM card all the way into the SIM card slot.

Removing the SIM card

Make sure to switch off HTC PH85110 before removing your SIM card.

1. Take the back cover off.

2. Remove the battery.

3. With your thumb, slide the SIM card out from the SIM card slot.

Storage card

Inserting the storage card

1. Take the back cover off.

2. Insert the microSD™card into the storage card slot with its gold contacts facing

down and push it until it clicks into place.

12 Getting started

2011/07/25 for certification review only

Removing the storage card

If HTC PH85110 is on, you must first "unmount" the storage card before removing it

to prevent corrupting or damaging the files in the storage card.

1. Take the back cover off.

2. Push the storage card in to eject it from its slot.

3. Slide the storage card out from its slot.

Unmounting the storage card

When you need to remove the storage card while HTC PH85110 is on, unmount the

storage card first to prevent corrupting or damaging the files in the storage card.

1. From the Home screen, press , and then tap Settings.

2. Tap SD & phone storage > Unmount SD card.

13 Getting started

2011/07/25 for certification review only

Battery

HTC PH85110 uses a rechargeable battery. How long the battery can last before it

needs recharging depends on how you use HTC PH85110.The features and accessories

you use can affect battery life. For example, leaving your Bluetooth®connection

always on uses more power. Long phone calls and frequent web browsing use up a lot

of battery power. Also, consider your location: poor signal strength from your mobile

network and extreme temperature make the battery work harder.

Removing the battery thin film

1. Take the back cover off.

2. Pull the flap of the thin film out, and then remove it from the battery

compartment.

Removing the battery

1. Take the back cover off.

2. With your thumb or finger, lift the battery from the battery compartment.

Inserting the battery

Please use only original batteries that came in the box or replacements that we

recommend.

1. Take the back cover off.

2. Insert the battery (with its exposed copper contacts first) into the battery

compartment.

14 Getting started

2011/07/25 for certification review only

Charging the battery

The battery is partially charged when shipped. Before you turn on and start using HTC

PH85110, it is recommended that you charge the battery.

§Only the power adapter and USB sync cable provided in the box must be used to

charge the battery.

§Do not remove the battery from HTC PH85110 while you are charging it using the

power or car adapter.

1. Plug the power adapter into the USB connector.

2. Plug in the power adapter to an electrical outlet to start charging the battery.

As the battery is being charged, the notification LED shows a solid orange light. The

light turns to solid green when the battery is fully charged.

When you charge the battery and HTC PH85110 is on, the charging battery icon is

displayed in the status bar. After the battery has been fully charged, the charging

battery icon turns to a full battery icon .

As a safety precaution, the battery stops charging when it overheats.

Switching the power on or off

Switching the power on

Press the Power button. Easy.

When you turn on HTC PH85110 for the first time, you’ll need to set it up.

Switching the power off

1. If the display is off, press the Power button to turn it back on, then unlock the

screen.

2. Press and hold the Power button for a few seconds.

3. When the Power options menu appears, tap Power off.

15 Getting started

2011/07/25 for certification review only
