HTC One (M8) Manual de usuario

•

5-0007 Plasc Triangle Opening Tool

5-0013 T5 Torx Screwdriver

5-0016 Small Phillips Screwdriver

5-0022 Nylon Spudger

5-1342 SIM Card Ejecon Tool

5-1370 Fine Tip Curved Tweezers

5-1387 Precision Knife Set

5-1665 Mul-Purpose Heat Gun

HTC One (M8)

DISASSEMBLE GUIDE

Page 1 of 10

Recommended Tools

hp://www.ﬁxez.com/

This step-by-step guide walks you through how to completely disassemble your new HTC One (M8) smartphone.

Following the detailed instrucons we have provided will help you safely replace, or repair, not only a broken

M8 display assembly (LCD and touch screen), but also any other internal components (i.e. rear-facing camera,

lightning connector and headphone jack assembly, power buon cable, etc.) that may have become damaged.

You can ﬁnd a full archive of ﬁxez.com disassemble guides and HD repair videos, for numerous makes and

models of smartphones and tablets, by vising hp://www.ﬁxez.com.

HTC One (M8) – Disassemble Guide

Page 2 of 10

hp://www.ﬁxez.com/

Rear Cover

There are two front grills on either side of the

smartphone’s display. The grills are secured in place

with a small amount of adhesive.

Use a heat gun or blow dryer to soften the adhesive.

This will make it easier to remove the grills from the

M8.

Insert the sharp edge of the precision knife in the gap

between the HTC One (M8) display assembly and the

first (top) grill.

Use the precision knife to carefully lift the grill from its

adhesive. Continue the same process to remove the

second (bottom) grill.

Now, locate and remove the two small Phillips screws

(#00) that secure the display assembly to the body of the

smartphone (marked with orange circles).

HTC One (M8) – Disassemble Guide

Page 3 of 10

hp://www.ﬁxez.com/

Next, locate and remove the four torx screws (T5) on

the other side of the M8 that also secure the display

assembly to the body/housing of the smartphone

(marked with orange circles).

Insert the precision knife between the rear cover and

the M8’s display assembly to free the first of many clips

that secure the LCD and touch screen assembly in

place.

Once there is separation between the rear cover and

display assembly, use the triangle plastic opening tool

to work around the perimeter of the smartphone until

the rear cover is completely removed.

HTC One (M8) – Disassemble Guide

Page 4 of 10

hp://www.ﬁxez.com/

First, locate and remove the two small Phillips screws

(#00) that secure the connection for the battery terminal

(marked with solid orange circles).

Next, locate and remove the two coaxial cable connec-

tions that are also secured to the motherboard (marked

with open orange circles).

There are two pieces of protective tape over the top of

the motherboard. Use the heat gun to help soften and

peel up the tape.

Now, locate and remove the three T5 torx screws that

secure the motherboard down to the center of the M8.

(marked with solid orange circles).

Next, locate and remove the three coaxial cable

connections. There are two near the rear-facing camera

and the one by the loudspeaker (marked with open

orange circles).

Six locking sockets secure the motherboard’s ribbon

cables in place. Release their locks by flipping the

opposite side of the ribbon cable up 90 degrees, and

then gently slide the cables out their sockets (marked

with orange rectangles).

Motherboard

HTC One (M8) – Disassemble Guide

Page 5 of 10

hp://www.ﬁxez.com/

You can now lift the motherboard up and out of the

HTC One (M8). Be careful when maneuvering it through

the cables and tape so that no damage occurs.

10.

Next, remove the remainder of tape that is protecting

the ribbon cables on the smartphone. Use heat, if

necessary, to make it easier to remove the tape.

11.

Do not forget about the volume rocker portion of the

ribbon cable, and be careful not to damage it when

removing the remaining tape (marked with orange

arrow).

12.

HTC One (M8) – Disassemble Guide

Page 6 of 10

hp://www.ﬁxez.com/

Vibrator

Use additional heat to soften the securing adhesive

holding the volume button in place and then with the

curved tweezers remove the volume button from the

HTC One (M8).

13.

First, locate and follow the wire coming off the back of

the vibrator. Pull its small plug from the locking socket.

Next, use the fine tip curved tweezers to remove the

vibrator from its housing and lift it out of the HTC One

(M8).

14.

The wafer connection for the front-facing camera is

slightly covered by a plastic cover. Remove the cover and

use the fine tip curved tweezers to release the wafer

connector (marked with orange arrow).

15.

HTC One (M8) – Disassemble Guide

Page 7 of 10

hp://www.ﬁxez.com/

Front-Facing Camera

Now, locate and remove the four small Phillips screws

(#00) that secure the daughterboard to the back of the

display assembly.

Next, release the ribbon cables in the two locking

sockets that are located on either side of the daughter-

board (marked with orange rectangles).

16.

You can now carefully remove the board from the M8.

There are two wafer connections on the bottom of the

board that might need additional maneuvering to

completely remove the board from the M8.

17.

Use the fine tip curved tweezers to lift the front-

facing camera from its housing and remove it from

the M8 smartphone.

18.

HTC One (M8) – Disassemble Guide

Page 8 of 10

hp://www.ﬁxez.com/

Loudspeaker

Rear-Facing Camera

Earpiece Speaker

Locate and remove the single small Phillips screw

(#00) that secures the rear-facing camera in place

(marked with an orange circle).

Now use the fine tip curved tweezers to lift the

rear-facing camera from its housing and remove it from

the HTC One (M8).

19.

The earpiece speaker is held in place with adhesive.

Use a small amount of heat to soften the adhesive, if

necessary. Then use the fine tip curved tweezers to lift

the earpiece speaker from its housing and remove it

from the HTC One (M8).

20.

The loudspeaker is also held in place with adhesive. Use

a small amount of heat to soften the adhesive, if

necessary. Then use the fine tip curved tweezers to lift

the loudspeaker up and out of the HTC One (M8).

21.

HTC One (M8) – Disassemble Guide

Page 9 of 10

hp://www.ﬁxez.com/

Baery

Micro-USB Dock Port and Headphone Jack Assembly

The dock port and headphone jack assembly is held in

place with adhesive. Use a small amount of heat to

soften the adhesive, if necessary.

Then use the fine tip curved tweezers to lift the

micro-usb dock port and headphone jack assembly

up and out of the HTC One (M8) smartphone.

22.

The battery is held in place with two strips of heavy-duty

adhesive. To avoid damage to the battery, use the heat

gun or blow dryer to soften the adhesive before trying to

remove the battery.

23.

Use the nylon spudger to gently pry the battery up and

out of the HTC One (M8).

24.

Breakdown

HTC One (M8) – Disassemble Guide

Page 10 of 10

hp://www.ﬁxez.com/

1. HTC One (M8) Display Assembly (LCD and Touch Screen)

2. HTC One (M8) Rear Battery Cover

3. HTC One (M8) Display Assembly Grills

4. HTC One (M8) Motherboard

5. HTC One (M8) Battery

6. HTC One (M8) Micro-USB Dock Port and Headphone Jack

7. HTC One (M8) Daughterboard

8. HTC One (M8) Loudspeaker

9. HTC One (M8) Rear-Facing Camera

10. HTC One (M8) Front-Facing Camera

11. HTC One (M8) SIM Card Tray

12. HTC One (M8) MicroSD Card Tray

13. HTC One (M8) Vibrator

14. HTC One (M8) Earpiece Speaker

1 2

Noce/Warning:

FIXEZ.COM DOES NOT ACCEPT ANY LIABILITY FOR DAMAGE, OR INJURY CAUSED, WHILE YOU ARE

FOLLOWING OUR DISASSEMBLE GUIDES. WE MAKE NO REPRESENTATIONS, WARRANTIES, OR

CONDITIONS OF ANY KIND, EXPRESS OR IMPLIED. UTILIZING THESE GUIDES TO HELP ASSIST YOU IN

REPAIRING YOUR MOBILE DEVICES WILL VOID YOUR WARRANTY. FIXEZ.COM STRICTLY PROHIBITS

ALTERING OR MODIFYING OUR DISASSEMBLE GUIDES FOR COMMERCIAL USE, REPRODUCTION, OR

PUBLICATION.
