HTC KIWI Manual de usuario

HTC Confidential

HTC confidential

Service Manual

for KIWI/H1915/H1920

HTC Proprietary

Confidential Treatment Requested

Rev. A02

March 12, 2004

HTC Corp.

Engineering Mobility

HTC Confidential

HTC confidential

TITLE: Service Manual

REV.

DATE CO TE TS DEP. REVISED APP

D STGE.PER.

AX01

Mar,18

2003

Fist Draft

Technical

Support

Vince

Huang

A01

Mar,27

2003

First Release

Technical

Support

Vince

Huang

A02

Mar,12

2004

Add shipping mode and

backup battery inspection

SOP

Technical

Support

Vince

Huang

HTC Confidential

HTC confidential

Table of contents

1. I TRODUCTIO ･･･････････････････････････････････････････････ 4

2. PRODUCT CO FIGURATIO ………………………………………………… 4

3. LABLE PLA ･･････････････････････････････････････････････････ 7

4. ASSEMBLI G A D DISASSEMBLI G ･･････････････････････････････ 11

4.1 DISASSEMBLI G ･･･････････････････････････････････････ 11

4.2 ASSEMBLI G ･････････････････････････････････････････ 15

5. PROBLEM DIAG OSTICS ･･･････････････････････････････････････ 20

5.1 TOOLS REQUIRED･･････････････････････････････････････ 20

5.2 HOW TO E TER DIAG OSTIC ･････････････････････････････ 20

5.3 LIST OF DIAG OSTICTEST ITEM ･･････････････････････････ 20

5.4 TEST ITEM OPERATIO ･･････････････････････････････････ 21

5.5 SHIPPI G MODE･･･････････････････････････････････････ 22

5.6 BACKUP BATTERY ISPECTIO ･･･････････････････････････ 24

6. DIAG OSTICS PROGRAM ･･･････････････････････････････････････ 26

6.1 LIST OF TEST JIGS ･････････････････････････････････････ 26

6.2 TROUBLESHOOTI G A D REPAIR ･････････････････････････ 27

6.3 FAULTY TREE ･････････････････････････････････････････ 30

7. REFLASH PROCEDURE ････････････････････････････････････････ 31

8. SPARE PARTS LIST ･･･････････････････････････････････････････ 33

9. MB MAJOR COMPO E T ･･････････････････････････････････････ 32

HTC Confidential

HTC confidential

1. Introduction

This manual provides the technical information to support the service activities of the KIWI.This

document contains highly confidential information, so any or all of this document should not be

revealed to any third party.

2. Product Configuration

Platform

• Windows CE Merlin OS – English, French, German, Italian, Spanish, Traditional Chinese, Simplified Chinese, Japanese.

• A low cost PDA built with optimized number of key elements

• Dimensions: Main unit

70mm(W) x 113.6mm(L) x 12.7mm (T)

• Weight (Main Unit) ->115g

Processor

• Intel Cotulla 200 Hz

Memory

• ROM:

16MB and Flash ROM

Boot ROM :4M Bit (Bootloader)

RAM:

64 B SDRA (46MB user accessible)

LCD Module

• Philip LCD 3.5” , reflective type TFT Color with 6pcs LED back light & 64K colors

• Touch sensitive screen

ASIC

• HTC ASIC 3 (TC222C56)

Stylus

• Around 100 mm

Hardware Buttons/reset button

• One power button

• One recording button

• One soft reset switch

• Four software programmable AP buttons with wake up function

HTC Confidential

HTC confidential

• One 5-way joy stick

Notification

• One bi-color LED for Event Alarm or PDA charging status

• otification by Sound and Message on the display

Audio

• Microphone

• Speaker

• One 2.5mm Earphone Jack, with stereo sound

• MP3 stereo (through audio jack)

Power

• Battery

 Rechargeable 900mAH, Lithium Ion battery

 User Swappable Battery

 Battery life: >8 hrs

 Back up battery

 Data retention time: 72 hrs

 Battery fully charge time: 4 hours

• AC Adapter

 AC input: 100~240 Vac, 50/60Hz

 AC input current: 0.2 Aac max.

 Output voltage: 5Vdc (typical)

 Output current: 2A (typical)

 Same as H38XX/H39XX serious

SD Slot

• Support both memory and IO

• Support SD/MMC type standard

Environment

• Operating temp.: 0 ~40 degree C. Humidity : 80% RH

• Storage temp.: -20 ~ 60 degree C. Humidity : 80% RH

Peripheral Interfa e

• Infrared Port IrDA SIR x 1, Transceiving range: 30cm

• Combo Port for USB and power

• Audio Jack (2.5mm)

• SD slot connector

A essories

• USB sync. Cable: 22 pins USB connector + DC Jack

HTC Confidential

HTC confidential

• AC adapter

• Stylus

• Ear plug

Options

• Stylus

• Battery

• USB Cradle (Battery Charger Included) – 22 pins Combo Port

 Main-Battery Charger

 PDA + Sled Slot for Active sync. And Battery Charger

 Rechargeable 900mAH, Lithium Ion battery

 DC-In Jack

 LED Indicator

Regulatory

• EMC / EMI: CE, FCC

• Safety: UL

• Pocket PC Logo

Appli ations

• Power Management

• Data Backup

• Back Light Control

HTC Confidential

HTC confidential

3.Label Plan

3.1 iPAQ H1915 Agency Label (on back housing under battery)

HP P/N: 311578-001

HTC P/N: 77H00067-00

Image file: See below

Size: 32.00 mm x 48.30 mm

Barcode Type: Code 39

FG barcode printing of area: 32 mm x 12mm

3.2 iPAQ H192 Agency Label

HP P/N: 331579-001

HTC P/N: 77H00068-00

Image file: See below

Size: 32.00 mm x 48.30 mm

Barcode Type: Code 39

FG barcode printing of area: 32 mm x 12mm

Reserve for FG barcode printing of area.

HTC Confidential

HTC confidential

3.3 SKU S/N Format (1 digit format)

S/N: CCSYWWZZZZ

CC: Country of anufacture

2 capital alpha (A-Z) characters, ISO 3166 Alpha-2 Code list. (Ex: TW=Taiwan)

S: Site Code

1character, pre-assigned by HP (ex: C=HTC TW)

YWW: Date of anufacture

The date of manufacture is expressed alpha-numerically by year counting from the base year, 2000, and week of

manufacture

ZZZZ: Sequence Number

Alphanumic, Base 31(0 through 9 and B through Z (A, E, I, O and U are disallowed characters), unique identifier that

identifies the exact unit, which was manufactured in the lot, produced within the date of manufacture. This number is the

serialization identifier which is essential to track the shipped, delivered, invoiced, installed, inventoried, repaired and

possibly returned or written off or scrapped, item itself, throughout the life cycle of unit. (ex: An example of a serial

number using all sub-elements above would be: DE=produced in Germany; B-At the HP Boeblingen/Sindelifingen Plant;

2-In the year 2002; 38-Week of September 9; B2H4-For the actual unit per that weekly lot of number 300, 301 (B=10

which gives 10×313=29,7910; 2=2 which gives 2×312=1,922; H=15 which gives 15×311=465; 4=4 which gives 4×

310=4). Therefore this unit is the 300, 30 1st units produced of this product in week 38 of 2002.

HTC Confidential

HTC confidential

3.4 Key Component Label Plan (Used for LCM/MB/Battery)

Barcode Serial number requirement (14 digits)

Barcode symbology use Code 128

For S/N: VPPRRY DZZZZZZ

V: Vendor Code (defined by FG)

PP: Part Number Code (defined by FG)

RR: Revision Code

Y: anufacture Year

Lowest one digit of A.D

example: 2002 = 2

: anufacture onth

1, 2, 3, …., 9, A, B, C

D: anufacture Day

1st dight of serial number and represent the DAY

Use base 31 (ex: 1, 2, 3…….., 9, A, B, C……. Z, exclude I, O, Q, U, please note day start from 1)

Z: Remaining 6 digitals of serial number (reset every day)

Use base10 (000001 ~ 999999)

Component revision code

RR code

A01 A1

A02 A2

……. …..

AX01 X1

AX02 X2

……. …..

B01 B1

B02 B2

……. …..

S/N :

P/N :

HTC Confidential

HTC confidential

3.5 FRU Date Code Label

P/N: 77H30010-10

Digit 1 ,2: Site Code.( t )

Digit 3,4: Year. anufactured , last 2 digits

Digit 5: onth of production , Jan to Dec(1-9,A-C).

Digit 6: Type of Warranty: ”1”

Date Code Label will apply on following FRU:

1. ain unit.

2. Cradle

3.6 Warranty Seal

HTC P/N: 77H00036-00

Dimension: 10.00mm x 12.00mm

Logo: PANTONE 653C

Ink: PANTONE 193C

10mm

Warranty void

if broken.

1 2 3 4 5 6

Size define by FG
