POS Printer

TP Series

Wi-Fi Operation Manual

Rev.1.4

POS Printer Wi-Fi Operation Manual

Contents

1. Manual Information..................................................................................................................................................3

2. Instruction Before Wi-Fi Setting............................................................................................................................... 3

3. Connect Printer to Master Device Through Wi-Fi.................................................................................................... 5

4. Shift Wi-Fi Mode / Set Parameters Through Web or Utility Tool.............................................................................6

4.1 Shift Wi-Fi Mode / Set Parameters Through Web......................................................................................... 6

4.2 Shift Wi-Fi Mode / Set Parameters Through Utility Tool............................................................................. 12

5. Use Printer Driver Through Wi-Fi Connection........................................................................................................ 19

6. Shift Wi-Fi Mode / Set Parameters Through POS App........................................................................................... 26

6.1 Connect printer to mobile device via Wi-Fi..................................................................................................26

6.2 Shift Wi-Fi Mode / Set Parameters Through POS App................................................................................. 31

POS Printer Wi-Fi Operation Manual

1. Manual Information

This Wi-Fi Operation Manual provides information on POS printer’s Wi-Fi settings.

We maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. Product

specifications or user manual content may be changed without prior notice.

2. Instruction Before Wi-Fi Setting

1) Printers with the Wi-Fi module, when the printer is powered on, the power indicator is flashing. After 8-9

seconds when the printer is ready, the power indicator will remain constant light.

2) To set up on a web page or tool after connecting to Wi-Fi, you need to get printer IP information, which

can be obtained in the following two ways:

■Press the FEED button of the printer without releasing, then press the power button to turn on the printer,

when the printer begins to print the self-test page, release the FEED button. Check the IP information in the

self-test page.

■For TP808 (with built-in Wi-Fi module), Shortly press the power button of the printer 3 times, the

printer would print out the IP information automatically;

For other models of POS printers (with external Wi-Fi module), shortly press the Function/Reset Button

(at the interface board) for three times, and the printer would print out the IP information automatically.

3) The Wi-Fi parameters of the printer can be set on web page or the tool of the printer.

■Set on web page

The following browsers are recommended: 360, IE and Firefox.

POS Printer Wi-Fi Operation Manual

■Set on the Utility Tool of the printer

URL for Utility Tool Installation Package: http://www.hprt.com/Downloads.html (Choose the product model

name (take TP806 as an example) under this URL to obtain download page of the Utility Tool Installation

Package)

Regarding the installation method of Utility Tool, please refer to HPRT Utility Tool for POS Instruction_Rev.1.5

( Click this URL to obtain:

http://www.hprt.com/manuals/HPRT_Utility_Tool_for_POS_Ins_Rev.1.5.pdf )

4) The printer Wi-Fi can connect with three master devices at the same time in AP mode, and the default IP

address in AP mode is 192.168.1.1.

The printer Wi-Fi can connect with five master devices at the same time in STA mode.

POS Printer Wi-Fi Operation Manual

3. Connect Printer to Master Device Through Wi-Fi

1) Turn on the printer which is defaulted as AP mode. In the master device, select and click “Connect” at

“POS_WIFI” hot-spot in the list of the wireless network connection. Type in the password (the default

password is 12345678), and the “POS_WIFI” is successful connected.

2) After the printer is successfully connected to the master device through Wi-Fi, the terminal software can

be communicated through the default IP:192.168.1.1.

POS Printer Wi-Fi Operation Manual

4. Shift Wi-Fi Mode / Set Parameters Through Web or Utility Tool

4.1 Shift Wi-Fi Mode / Set Parameters Through Web

1) After the printer is successfully connected to the master device through Wi-Fi, open the browser and type

in the IP address 192.168. 1.1 to enter into the printer setup interface, type in the password (The default

password is 12345678).

POS Printer Wi-Fi Operation Manual

2) Click “Login” and enter into the following interface. In the master right corner, you can switch the

languages of the displayed interface.

3) In “Work Mode”, Change the AP mode to STA mode, click “Save”, but don’t restart the printer.

POS Printer Wi-Fi Operation Manual

4) Enter into “STA Setting”, click “Scan”, select the wireless internet that you want to connect to. For

example, select “prtwireless” and click “OK”, then type in the password of this wireless internet, select

“Enable” in “Obtain an IP address automatically” , and click “Save”.

POS Printer Wi-Fi Operation Manual

5) Click “Restart”, When the interface appears “Rebooting Successful!”, manually restart the printer, so the

STA setting is effective.
