GT1

Quick Start Guide ---------------------------------

Instrucciones---------------------------------------

取扱説明書 ------------------------------------------

01

10

19

Content

EN

JP

ES

Product Introduction

Front View:

Paper Outlet

Power Button

Left Cover

Opening Button Right Cover

Opening Button

Paper Inlet

Printer Cover

Upper Cover

Rear View:

USB Type-B Port

Power Port

01

Inside View:

Accessories

Power Adapter*1 USB Cable*1

02

Ribbon Loading

Open covers01

Open the upper cover ﬁrst, and then press the buttons on both sides of the printer

cover at the same time. Lift the printer cover upward.

03

Load ribbon

02

Hold the left and right brackets of the ribbon with both hands and load the ribbon

into the printer.

Make sure that the barcode label position is the same as shown in the picture

when loading.

Press down the printer cover with your hands until hear a "snap" sound.

Close printer cover

03

Barcode Label

！

04

Paper Loading

Load paper

01

Load papers as shown, recommended not to put more than 20 sheets at a time.

05

Power On

Connect power supply

Power On

To turn oﬀ the printer, also hold down the power button for 3 seconds.

01

02

Hold down the power button for 3 seconds to turn on the printer.

Plug one end of the power cord into the printer's power port, and then plug the

adapter into a power outlet.

06

Printing from Mobile Phone

APP Download

01

Connect to printer via Wi-Fi

Connect the mobile phone to a Wi-Fi hotspot (must be 2.4 GHz);

Open App, click “Connect printer”, and “Connect” with “HPRT GT1-XXXX”(XXXX

are last four digits of Bluetooth address);

Enter the Wi-Fi password;

Click “Set” and waiting for the connection result.

Scan the QR code to download the APP.

02

03 Print

Open the document you want to print, and copy/share it to APP. (Or click

“Documents” on Home to choose the document.) ;

Adjust it in Print preview, and click “Print” to print it.

04 Printing from Cloud

The printer is on and have been connected to an available Wi-Fi;

Even though the printer is not around you, you can still choose a document and

print it via our APP by click “Print”in Print preview.

07

Precautions

The best operating temperature is 0℃~40℃, if the environmental temperature

is too low or too high, the print quality may be aﬀected.

Please do not use the unoﬃcial adapter, ribbon or paper to ensure the print

quality.

During printing, the area around the print head is very hot. Do not touch it to

avoid burns.

Do not pull out paper by force during printing, or else it may damage the printer.

Operating this device in a residential environment may cause radio interference.

Printing from Computer

Connect one side of the USB cable to the computer and the other side to the

printer;

Turn on the printer;

Download the printer driver from the website: www.hprt.com/HPRT-GT1

And then install it on the computer;

Choose the document you want to print and print it via printer “HPRT GT1”.

08
